Pioneer DEH-P2550 Installation Manual

DEH-P2550
This product conforms to new cord colors.
Los colores de los cables de este producto se
conforman con un nuevo código de colores.
As cores dos fios deste produto seguem um novo
padrão de cores.
Æ...b¹b'« „öÝô« Ê« uë lÄ "UN'« «c¼ r− M¹
Printed in China
<CRD3692-A/U> ES <KSNNN/02H00000>
5
6
60°
Fig. 1 Fig. 3
± qJAë ≥ qJAë
7
2
1
182
53
3
4
Fig. 2 Fig. 4
≤ qJAë ¥ qJAë
11
8
9 13
12
Fig. 5 Fig. 7
∑ qJAë
µ qJAë
10
Fig. 6
∂ qJAë
Installation <ENGLISH>
Note: Removing the Unit (Fig. 3) (Fig. 4)
• Before finally installing the unit, connect the
5. Frame
wiring temporarily, making sure it is all connect-
6. Insert the release pin into the hole in the bottom
ed up properly, and the unit and the system work
of the frame and pull out to remove the frame.
properly.
(When reattaching the frame, point the side with
• Use only the parts included with the unit to
a groove downwards and attach it.)
ensure proper installation. The use of unautho-
7. Insert the supplied extraction keys into the unit,
rized parts can cause malfunctions.
as shown in the figure, until they click into place.
• Consult with your nearest dealer if installation
Keeping the keys pressed against the sides of the
requires the drilling of holes or other modifica-
unit, pull the unit out.
tions of the vehicle.
• Install the unit where it does not get in the dri-
DIN Rear-mount
ver's way and cannot injure the passenger if there
is a sudden stop, like an emergency stop.
• The semiconductor laser will be damaged if it
Installation using the screw holes on
overheats, so don't install the unit anywhere hot
the side of the unit (Fig. 5) (Fig. 6) (Fig. 7)
— for instance, near a heater outlet.
• If installation angle exceeds 60° from horizontal,
1. Remove the frame.
the unit might not give its optimum performance.
8. Frame
(Fig. 1)
9. Insert the release pin into the hole in the bottom
of the frame and pull out to remove the frame.
DIN Front/Rear-mount
(When reattaching the frame, point the side with
a groove downwards and attach it.)
This unit can be properly installed either from
2. Fastening the unit to the factory
"Front" (conventional DIN Front-mount) or
"Rear" (DIN Rear-mount installation, utilizing
radio mounting bracket.
threaded screw holes at the sides of unit chassis).
10. Select a position where the screw holes of the
For details, refer to the following illustrated
bracket and the screw holes of the head unit
installation methods.
become aligned (are fitted), and tighten the
screws at 2 places on each side. Use either truss
screws (5 × 8 mm) or flush surface screws
DIN Front-mount
(5 × 9 mm), depending on the shape of the screw
holes in the bracket.
Installation with the rubber bush (Fig. 2)
11. Screw
1. Dashboard 12. Factory radio mounting bracket
2. Holder 13. Dashboard or Console
After inserting the holder into the dashboard,
then select the appropriate tabs according to the
thickness of the dashboard material and bend
them.
(Install as firmly as possible using the top and
bottom tabs. To secure, bend the tabs 90
degrees.)
3. Rubber bush
4. Screw
