Entone 3 mode Quick Reference Manual page 3

11. RESERVED USE KEYS 19. NAVIGATION KEYS
Reserved for future use. Navigates right, left, up, down
in the on-screen guide.
12. POWER Switches the power
on/off for the currently selected 20. SPECIAL FUNCTION
device. Reserved buttons. Ask your
service provider for more info.
13. DEVICE KEYS Selects the
21. NUMBERED BUTTONS Allow
device which you would like to
control. direct access to specific
channels and menu items.
14. MENU Displays the on-screen
menu. 22. MUTE Turns the volume of the
currently selected device off.
15. EXIT Exits the current menu
item. 23. MEDIA Reserved for future
use.
16. CH Changes channel up/down.
24. MUSIC Displays available
17. LAST Changes channel to the
music channels (where
most recently viewed channel.
available)
18. VOL Raises or lowers volume
25. HELP Displays the on-screen
of the currently selected
help menu.
device.
6. Programming Remotes For Use With Hydra
First, you must program your remotes for use with your Hydra. The Hydra
comes with 3 URC remotes. Each remote can be programmed for use with
a different TV/Room. (Refer to the "Hydra Installers Guide" for more
information on in-home configurations).
Press and hold the OK button on the Hydra front panel for about 5
seconds. When the OK button is released, the Hydra front panel
Standby/On LED blinks twice (alternates red and green), then stays lit
red to indicate that the Hydra is now in remote registration mode.
Identify the remote control, which is labeled with a number 1, 2, or 3
on the battery cover plate on the bottom of the remote, as shown
below:
Press and hold the STB button (Myrio button) on the remote control
for about 4 to 5 seconds. The "STB" button backlight LED will light to
indicate that the remote control is in registration mode.
URC Quick Reference Guide 3
V2.0
