1. 110v grounded outlets
2. Green LED Indicators: Indicators will illuminate when corresponding channel is activated.
3. LCD Display: This multifunction will display the setting and running mode of the unit.
4. 110V/220V Switch:
connecting your unit to the main power and turning it on.
5. Built-in microphone for sound control
6. Audio Sensitivity
7. Mode Button: This button will switch the unit between "A" DMX mode "P" program mode "C"
manual mode (dimming) and "H" manual mode (switching)
8. MENU Button: This button will activate different functions in DMX mode, program mode or
manual mode.
9. Button: This button will increase the value of the function you are controlling.
10. Button: This button will decrease the value of the function you are controlling.
11. Power Cord: Make sure the unit is set to the proper voltage setting prior to connecting your
unit to the main power and turning it on.
12. Power Switch: This switch controls the unit's main power.
13. DMX Input: This connector allows the input of DMX control signal.
14. DMX Output: This connector allows the output of DMX control signal to the next DMX device.
15. ROPE LIGHT Connector
16. External Fuse Holders

OPERATION

The unit has four working modes:
1. DMX mode as a single channel, two channel or four channel Dimmer or switching pack.
2. 4-channel chaser in auto mode or music mode
3. Manual dimming of any channel
4. Manual ON and OFF of any channel

POWER SUPPLY

Before plugging your unit to the main power please make sure the source
voltage in your area matches the required voltage for your device. Because
line voltage may vary from venue to venue, make sure to plug your power
supply into a compatible wall outlet before attempting to operate your
device.
Make sure the switch is set to the proper voltage setting prior to
