- Page 1 241-9885 3/8” ANGLE DRILL Operator’s Manual SAVE THIS MANUAL You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.
- Page 2 IMPORTANT SAFETY INSTRUCTIONS WARNING : When using electric tools, machines or equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and personal injury. READ INSTRUCTIONS BEFORE USING THIS TOOL 1. KEEP WORK AREA CLEAN. Cluttered areas invite injuries. 2.
- Page 3 IMPORTANT SAFETY INSTRUCTIONS 13. USE THE RIGHT TOOL. Don’t force a small tool or attachment to do the work of a larger industrial tool. Don’t use a tool for a purpose for which it was not intended. 14. DRESS PROPERLY. Don’t wear loose clothing or jewelry; they can be caught in moving parts.
- Page 4 SPECIFICATIONS Voltage: 120 volts AC, 60Hz. Current rating: 3.8 amps No load speed: 0-1400 rpm 3/8”-10 mm keyless chuck Trigger-controlled variable speed Convenient above-the-trigger reverse switch Lock-on button FUNCTION DESCRIPTION Variable speed trigger Forward / Reverse / Neutral switch 3/8”...
- Page 5 OPERATING PROCEDURES Metal Drilling Use a sharp drill bit especially designed to cut the material you are working on. It is recommended you use a cutting luid on the metal surface to avoid heat build-up. MAINTENANCE CAUTION! Always be sure that the tool is switched off and unplugged before at- tempting to perform inspection or maintenance.
- Page 6 PARTS LIST Part # Description Qty. Part # Description Qty. ) t f l l i r Motor Housing Ball Bearing (626) l l a l l a l l a Ball Bearing (626) Power Cord/Plug Ball Bearing (625) Trigger Lock Gear Housing Cover Forward/Reverse Switch Motor Housing Cover...
