Seaward
LPG STOVE OWNER'S MANUAL
Model Number
Serial Number
IMPORTANT SAFETY INSTRUCTIONS
Seaward Products recommends that a qualified person or electrician install this product.
Seaward Products accepts no responsibility or liability for damage to equipment, injury, or
death that may result from improper installation or operation of this product. When using
electrical appliances, basic safety precautions to reduce the risk of fire, electrical shock, or
injury to persons should be followed.
1. READ ALL INSTRUCTIONS THOROUGHLY BEFORE USING THIS GAS STOVE.
2. Save the Owner's Manua l/Installation instructions for local inspector's use. INSTALLER:
Provide this manual to the vehicle owner. VEHICLE OWNER: Keep this manual for future
reference.
3.
NEVER USE FLAME TO CHECK FOR LEAKS. LPG is heavier than air and if allowed to
settle or accumulate, and if ignited, IT W ILL CAUSE AN EXPLOSION!!
4. Install or locate this stove only in accordance with the provided installation instructions.
5. Use this stove only for its i ntended use as described in this manual.
6.
As with any appliance, close supervision is necessary when used by children
7. THE FEATURES COVERED IN THIS MANUAL ARE FOR VARIOUS MODEL STOVES.
PLEASE DISREGARD PORTIONS PERTAINING TO FEATURES THAT ARE NOT ON
YOUR PARTICULAR MODEL STOVE.
Products
PRINCESS GOURMET SERIES
INCLUDES 2 & 3 BURNER CONFIGURATIONS
WARNING
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Seaward LPG
Summary of Contents for Seaward LPG
-
Page 1: Model Number
Provide this manual to the vehicle owner. VEHICLE OWNER: Keep this manual for future reference. NEVER USE FLAME TO CHECK FOR LEAKS. LPG is heavier than air and if allowed to settle or accumulate, and if ignited, IT W ILL CAUSE AN EXPLOSION!! 4. - Page 2 NOTE: LPG is heavier than air and if allowed to settle or accumulate, and if ignited, IT WILL CAUSE AN EXPLOSION!! 2. The LPG tank should be securely bolted down by the tank feet and in the position in which the tank was designed. LPG is a two-phase (liquid/vapor) fuel and only vapor withdrawal from the tank is safe.
- Page 3 SUMMARY FOR CHECKING LPG SYSTEM AND LPG APPLIANCE 1. After the LPG tank has been installed, the regulation system connected, the hose run and connected to both the appliance and the regulator, slowly crack open the LPG tank valve and observe the pressure gauge on the regulation system. The gauge should read approximately 110 psi at 70°...
- Page 4 If leak cannot be repaired, close the tank valve immediately and do not use this system. Remember LPG is heavier than air and if allowed to reach bilges, machinery space or other enclosed spaces, it can be extremely dangerous.
- Page 5 MODELS: 2575 & 3575 Replacement Parts Replacement parts listed herein may be ordered through Seaward Products, Seaward Distributors and Dealers, or Dealer’s Authorized Service Centers. All parts will be shipped at prevailing prices. W hen ordering repair parts, please give the following information:...
- Page 6 STOVE INSTALLATION 1. CUT COUNTER TO THE APPROPRIATE SIZE FOR YOUR MODEL STOVE. 2. SLIDE STOVE INTO COUNTER AND HOOK UP FUEL LINE. 3. SECURE STOVE TO COUNTER USING 4 MOUNTING SCREWS PROVIDED. STAINLESS STEEL SCREWS PROVIDED TO SECURE COOK TOP TO COUNTER. MOUNTING HOLES 1/2"...
- Page 7 CARE AND CLEANIN G Regular cleaning with a soft cloth and a warm detergent solution is generally enough to keep your oven clean and beautiful. This is done when the range is cool. Use a dry cloth or paper towel to clean splatters and spills when surfaces are warm. PORCELAIN ENAMEL - Porcelain enamel is glass fused on steel at very high temperatures.
- Page 8 The foregoing warranty and condition shall apply to any repaired, reworked, or replaced products, part or component supplied by SEAWARD and shall in no event be liable to BUYER or BUYER’S customers for any incidental or consequential damages, or loss of use, or other losses, however occasioned.
