infrasave IEP 6024 Installation & Owner's Manual

Wall or ceiling mount fixed electric room heater
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model IEP 6024
Wall or Ceiling Mount Fixed Electric Room Heater
INDOOR / OUTDOOR COMMERCIAL/INDUSTRIAL NON-RESIDENTIAL USE
INSTALLATION / OWNER'S MANUAL
instructions thoroughly before installing or servicing this equipment.
Improper installation, operation, adjustment, alteration, service or mainte-
nance can result in the risk of fire and electrical shock, and may cause
property damage, injury or death.
SAFETY ALERT:
This heater must be serviced only by a qualified electrician. Failure to com-
ply could result in personal injury, death, fire and/or property damage.
Do not operate this heater unless it is properly installed.
Always disconnect the heater from the power source prior to servicing.
Do not store or use gasoline or other flammable vapours and liquids in
the vicinity of this or any other hot surface appliance.
Do not use or locate this model where it could fall into a bathtub or other
water container.
Do not cover or block any surface of this appliance.
Do not touch this appliance while in operation
- Allow to cool after use.
Read the IMPORTANT INFORMATION section of
this manual before using this appliance.
SAVE THESE INSTRUCTIONS
INSTALLER: PRESENT THIS MANUAL TO THE END USER
Record the following information for future reference if service is required:
IEP 6024
Model #:
Serial #:
InfraSave IEP-6024 Manual
Read all instructions before using this heater.
WARNING
Read and understand all installation and maintenance
. Keep this manual in a secure place.
(located on heater rating label)
3154365
Conforms to ANSI/UL 2021
Certified to CAN/CSA C22.2 No.46
IM111221
RD: DEC 2011
RL: 1B
BA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IEP 6024 and is the answer not in the manual?

Questions and answers

Related Manuals for infrasave IEP 6024

Summary of Contents for infrasave IEP 6024

  • Page 1 Model IEP 6024 Wall or Ceiling Mount Fixed Electric Room Heater INDOOR / OUTDOOR COMMERCIAL/INDUSTRIAL NON-RESIDENTIAL USE INSTALLATION / OWNER’S MANUAL Read all instructions before using this heater. WARNING Read and understand all installation and maintenance instructions thoroughly before installing or servicing this equipment.
  • Page 2 NOTICE: This contents of this manual are current for this product at the date of manufacture. Occa- sional revision of the product Certification Standard may require changes to the product and/ or the content in the product manual. The product must be installed according to the content of this manual, and/or all local and national code requirements.

  • Page 3: Table Of Contents

    Model IEP 6024 Wall or Ceiling Mount Fixed Electric Room Heater INDOOR / OUTDOOR COMMERCIAL/INDUSTRIAL NON-RESIDENTIAL USE Table of Contents 1. IMPORTANT INSTRUCTIONS: ........4 Read First !! 2. Heater Dimensions, Wiring, Specifications ....6 3. Project Design Guidelines..........7 4. Installation Instructions: General Information ..........9...

  • Page 4: Important Instructions

    1. IMPORTANT INSTRUCTIONS When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, injury to persons or death, and property damage including the following : Read all instructions before using this heater 2.

  • Page 5: Save These Instructions

    IMPORTANT INSTRUCTIONS continued 14. To prevent a possible fire, do not block air intakes or exhaust in any manner. Do not use on a soft surface, like a bed, where openings may become blocked. 15. A heater has hot and arcing or sparking parts inside. Do not use it in areas where gasoline, paint, or flammable liquids are used or stored.

  • Page 6: Heater Dimensions, Wiring, Specifications

    2. HEATER DIMENSIONS, WIRING, SPECIFICATIONS - IEP 6024 IM111221 RD: DEC 2011 InfraSave IEP-6024 Manual RL: 1B...

  • Page 7: Project Design Guidelines

    The activity level of the people: seated at rest, hard physical labor, etc.  Outdoor application: Any area heated outdoors is ‘Spot heat’  NOTE: Model IEP 6024 is for INDOOR or OUTDOOR NON-RESIDENTIAL use  Ensure that the heater model is suitable and approved for outdoor use ...
  • Page 8 27.5 [8.4] 275 [25.4] 14.5 Min. 12 [3.7] 14 [4.3] 15 [4.6] 29.5 [9.0] 315 [29.2] 19.0 IEP 6024 6000 Max. 15 [4.6] 14.4 [4.4] 17.7 [5.4] 32 [9.8] 360 [33.4] 16.7  Refer to design guidelines on previous page.

  • Page 9: Installation Instructions

    4. INSTALLATION INSTRUCTIONS : READ ALL INSTRUCTIONS AND PLAN THE INSTALLATION General BEFORE PROCEEDING This appliance conforms to ANSI/UL 2021 and is certified to CAN/CSA C22.2 No.46. This ap- pliance is approved for outdoor and indoor non-residential use. Do not use this heater in envi- ronments such as bathrooms and laundry rooms.

  • Page 10: Minimum Required Clearances

    To Wall ‘B’ Floor ‘F’ Spacing ‘D’ Inches [cm] Inches [cm] Inches [cm] Inches [cm] Inches [cm] IEP 6024 6000W More than 4” [10] 4” [10] 72” [180] 36” [90] 36” [90] FIGURE 2: MINIMUM Required Clearances to Combustibles CLEARANCE ‘C’:...
  • Page 11 The IEP 6024 weighs 13.2 lbs (6 kg). It is recommended to fasten the mounting brackets to a structural member (wall studs, ceiling joists, etc.) or to a field supplied support that is fastened to structural members.

  • Page 12: Electrical Connection

    5. ELECTRICAL CONNECTION Connect each lamp circuit heater to a 230 - 240 Vac, 60Hz, 9 Amp copper wire circuit that is properly grounded. Electrical connection must be performed by a qualified electrical trades- person. Installation must conform with the latest edition Electrical Code ANSI/NFPA N0 70 in the U.S.A.

  • Page 13: Maintenance Instructions

    7. MAINTENANCE INSTRUCTIONS WARNING Heater service should only be performed by a qualified electrician. Fail- ure to comply could result in personal injury, death, fire and/or property damage. Tampering with the heater by an unqualified person will void the warranty. WARNING Always disconnect the heater from the electrical power supply prior to any cleaning, maintenance or service work.

  • Page 14: Heater Parts

    9. HEATER PARTS - IEP 6024 FIGURE 5: 15-3 15-1 15-2 Electrical Connection Box end of heater 1. Heater Body - cast aluminum 2. Polished Aluminum Reflector Assembly 3. Protective Screen 4. End Covers with Mounting Bracket Knob Fasteners 5. Heater Face Plates 6.

  • Page 15: Heat Lamp Replacement

    10. HEAT LAMP REPLACEMENT A Heat Lamp will operate for approximately 5000 hours under normal conditions. If one lamp requires replacement due to life use failure, we recommend changing both lamps at that time. WARNING Heater service should only be performed by a qualified electrician. Failure to comply can result in personal injury, death, fire and property damage.
  • Page 16 Heat Lamp Replacement … continued Step 4 Remove the 2 Phillips screws that fasten the electrical con- nection box front face plate in place. Step 5 Slide the connection box front face plate out from the electri- cal connection box. Step 6 Slide power cord retainer plate from electrical connection box (top surface).
  • Page 17 Heat Lamp Replacement … continued Step 9 Complete this step only to replace Lamp #1 To replace only Lamp #2, go to Step Remove interior end plate from heater: 6 Phillips screws fas- ten the heater body end plate in place. Step 10 Slide top cover plates out each end of top side of heater.

  • Page 18: Warranty Statement

    InfraSave IEP SERIES HEATERS - LIMITED WARRANTY CERTIFICATE The Manufacturer warrants to the original consumer that this product is free from defects in material and/or workmanship under normal use and service for a period of one year (12 months) from the date of pur- chase, and subject to the conditions and limitations stated herein.
