Model IEP-2024
Wall Fixed Electric Room Heater
INDOOR / OUTDOOR NON-RESIDENTIAL USE
INSTALLATION / OWNER'S MANUAL
instructions thoroughly before installing or servicing this equipment.
Improper installation, operation, adjustment, alteration, service or mainte-
nance can result in the risk of fire and electrical shock, and may cause
property damage, injury or death.
SAFETY ALERT:
This heater must be serviced only by a qualified electrician. Failure to com-
ply could result in personal injury, death, fire and/or property damage.
Do not operate this heater unless it is properly installed.
Always disconnect the heater from the power source prior to servicing.
Do not store or use gasoline or other flammable vapours and liquids in
the vicinity of this or any other hot surface appliance.
Do not use or locate this model where it could fall into a bathtub or other
water container.
Do not cover or block any surface of this appliance.
Do not touch this appliance while in operation
- Allow to cool after use.
Read the IMPORTANT INFORMATION section of
this manual before using this appliance.
SAVE THESE INSTRUCTIONS
INSTALLER: PRESENT THIS MANUAL TO THE END USER
Record the following information for future reference if service is required:
Model #:
IEP-2024
Serial #:
InfraSave IEP-2024 Manual
Read all instructions before using this heater.
WARNING
Read and understand all installation and maintenance
. Keep this manual in a secure place.
(located on heater rating label)
3154365
Conforms to ANSI/UL 2021
Certified to CAN/CSA C22.2 No.46
IM110810
RD: AUGUST 2011
RL; 1A
BA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IEP-2024 and is the answer not in the manual?

Questions and answers

Summary of Contents for infrasave IEP-2024

  • Page 1 . Keep this manual in a secure place. INSTALLER: PRESENT THIS MANUAL TO THE END USER Record the following information for future reference if service is required: Model #: IEP-2024 Serial #: (located on heater rating label) IM110810 RD: AUGUST 2011 InfraSave IEP-2024 Manual RL; 1A...
  • Page 2 This publication is the intellectual property of Schwank. This publication, or parts thereof, may not be reproduced in any form, without prior written consent from Schwank. Unauthorized use or distribution of this publication is strictly prohibited. Schwank Group Schwank and InfraSave brands 5285 Bradco Boulevard Mississauga, Ontario,L4W 2A6 2 Schwank Way Waynesboro, Georgia 30830 Customer &...
  • Page 3: Table Of Contents

    11. Warranty Statement...........18 FIGURE 1: Recommended Mounting: Comfort Area Coverage ..8 FIGURE 2: Minimum Required Clearances........10 FIGURE 3: Mounting Bracket ............11 FIGURE 4: End View & Heater Bracket..........11 FIGURE 5: Heater Parts ..............14 IM110810 RD: AUGUST 2011 InfraSave IEP-2024 Manual RL; 1A...
  • Page 4: Important Instructions

    14. Do not insert or allow foreign objects to enter the heater or any ventilation or exhaust opening as this may cause an electric shock, fire, or damage the heater - death, personal injury or property damage could result. continued ... IM110810 RD: AUGUST 2011 InfraSave IEP-2024 Manual RL; 1A...
  • Page 5: Save These Instructions

    21. After use, allow the heater to cool down before touching, moving, or storing. 22. These instructions belong with the heater for ready reference. Keep this manual in a safe place near the heater. “SAVE THESE INSTRUCTIONS” IM110810 RD: AUGUST 2011 InfraSave IEP-2024 Manual RL; 1A...
  • Page 6: Heater Dimensions, Wiring, Specifications

    2. HEATER DIMENSIONS, WIRING, SPECIFICATIONS - IEP 2024 IM110810 RD: AUGUST 2011 InfraSave IEP-2024 Manual RL; 1A...
  • Page 7: Project Design Guidelines

    Provide heat from at least two sides wherever possible  Contact Schwank Design Services for assistance at design@schwankgroup.com. IM110810 RD: AUGUST 2011 InfraSave IEP-2024 Manual RL; 1A...
  • Page 8 15 [4.6] 14.4 [4.4] 17.7 [5.4] 32 [9.8] 360 [33.4] 16.7  Refer to design guidelines on previous page.  Refer to Required Minimum Clearances: Table 2 & Figure 2, Page 10 IM110810 RD: AUGUST 2011 InfraSave IEP-2024 Manual RL; 1A...
  • Page 9: Installation Instructions

    10. Do not use heater on a soft surface, like a bed, where air openings may become blocked. 11. A heater has hot surfaces and potentially arcing or sparking parts inside. Do not use in areas where gasoline, paint, or flammable vapors or liquids are used or stored. IM110810 RD: AUGUST 2011 InfraSave IEP-2024 Manual RL; 1A...
  • Page 10: Minimum Required Clearances

    U.S.A. and PART 1 CSA C22.1 in Canada. 5. Never allow an electrical cord to pass in front of the heater or to come into contact with any hot surface of the heater. continued ... IM110810 RD: AUGUST 2011 InfraSave IEP-2024 Manual RL; 1A...
  • Page 11 12. Read and follow all warnings, and the following section on Operation to enjoy safe op- eration of the heater. IM110810 RD: AUGUST 2011 InfraSave IEP-2024 Manual RL; 1A...
  • Page 12: Electrical Connection

    10. High heat is generated from the front of the heater. 11. Do not allow children to touch or play with the heater. 12. Do not use the heater to dry wet materials or clothing. IM110810 RD: AUGUST 2011 InfraSave IEP-2024 Manual RL; 1A...
  • Page 13: Maintenance Instructions

    Inspect the electrical cord for damage or fraying.  Do not operate the heater with a damaged cord  Have damaged parts replaced by a qualified electrician  IM110810 RD: AUGUST 2011 InfraSave IEP-2024 Manual RL; 1A...
  • Page 14: Heater Parts

    9. Connection Box Face Plate 10. Connection Box 11. Terminal Block for electrical connections 12. Power Cord 13. Heater Mounting Bracket 14. Lamp Retainer Clips 15. Heat Lamp - 2000 Watts - Part # JE-2000-XX IM110810 RD: AUGUST 2011 InfraSave IEP-2024 Manual RL; 1A...
  • Page 15: Heat Lamp Replacement

    Remove the screws and end cover to secure storage. Step 3 Remove 4 Phillips screws that hold connection box to heater. Slide out the face plate at each end of heater to expose both ends of the heat lamp. IM110810 RD: AUGUST 2011 InfraSave IEP-2024 Manual RL; 1A...
  • Page 16 Step 8 Loosen plastic collar on second Liquid Tight Connector that secures red wires through connection box end plate. Slide red wires out of connection box. Set connection box aside. Heater Body IM110810 RD: AUGUST 2011 InfraSave IEP-2024 Manual RL; 1A...
  • Page 17 The heat lamp is fragile! Carefully slide old heat lamp out of heater through rectangular slot in end of reflector. Carefully install new heat lamp and clip in place. Reverse steps above to reassemble the heater. IM110810 RD: AUGUST 2011 InfraSave IEP-2024 Manual RL; 1A...
  • Page 18: Warranty Statement

    Limited Warranty will be based upon the date of unit manufacture, plus thirty (30) days. Do not ship a heater back to InfraSave for repair. Contact your local supplier / installer of the heater, or a local qualified electrician for warranty service or repair.
