- Page 1 BUILT IN HOBS NSTRUCTIONS FOR USE AND INSTALLATION Gas cooktop CH80X (stainless steel) CH80W (white) CH80E (black) MANUFACTURED BY...
-
Page 2: Table Of Contents
Congratulations on purchasing one of our hobs. To get the best from your new appliance we advise you to read very carefully the information contained in this instruction booklet. It is in two parts: FOR THE USER FOR THE INSTALLER PART 1 PART 2 ENERAL INFORMATION... -
Page 3: Part 1 For The User
The layout of your hob “A ” • LL GAS HOBS ARE PRE ADJUSTED FOR NATURAL GAS Recommendations 1. Burner / control hob • Use of a gas cooking appliance leads to the production of semi-fast heat and humidity in the premises in which it is installed. •... -
Page 4: Using The Gas Burners P
Using the gas burners Ignition with gas safety device • Each burner is controlled by a tap with a safety locking device which, in the event of accidental extinction of the flame (spillage, draught...) quickly cuts off the gas supply and prevents any from escaping. -
Page 5: Which Pans To Use On The Gas Burners
Using the gas burners • Your appliance is equipped with a removable Which pans to use on the gas burners support grid for small pans. • Suggested pan diameters It can be used on all the burners of your ap- Small burners Medium burner Large burners... -
Page 6: Cleaning Your Hob P
Cleaning your hob • Never clean your hob while it is in operation; however, Precautions for use cleaning your hob will be made easier if you do this before it has completely cooled. • Do not store CLEANING PRODUCTS or INFLAM- MABLE ITEMS in the unit under your hob. -
Page 7: Part 2 For The Installer
General information Installation Building in • As a general rule, installation should be carried out by This hob is rated type X (under standard EN 60.335.2.6) insofar qualified installers and technicians. as the heating of units is concerned. • Before installation, make sure that local distribution conditions (gas type and pressure) are compatible with the appliance's adjustment. -
Page 8: Preliminary Remarks
General information Preliminary remarks • The hob should be fitted into the work surface of a supporting unit. The work surface must be a minimum of 3 cm thick and made of heat resistant material or covered with such a material. •... - Page 9 General information Installing the hob Fixing the hob in place • Glue on the seal supplied in the wallet before installing You can immobilise your hob in the worktop in accordance with the illustration below using the 4 fixing brackets and the hob: screws supplied in the wallet.
-
Page 10: Electrical Connection P
Electrical connection ROSS SECTION OF CABLE TO BE USED • These hobs are supplied with a power supply cable (ty- pe H05VVF-T105 or type H05V2V2F-T90, with a cross-sec- tion of 1 mm 2 ) with 3 cores (2 phase + earth) and should be 230 V - 50 Hz connected to the 230 V mains supply by means of a 2 pha-... -
Page 11: Gas Connection P
Gas connection Preliminary remarks Connection options Mains gas (natural gas) or LPG. • • If the hob is installed above an oven or if the proximity of other heating elements might cause the connection to Back right hand corner 1/2 inch male BSP thread. •... -
Page 12: Changing Gas P
Changing gas Preliminary remarks • This hob is supplied pre-adjusted for natural gas.The injec- Head tors required for adapting it to butane/propane are in the wallet with the instruction booklet. • Each time the gas is changed, tick the new gas setting on the la- bel to be found in the wallet. - Page 13 Changing gas (cont.) • Using the small screwdriver, supplied in the bag, , located un- ADJUST THE LOW FLAME SETTING OF THE TAPS screw fully the brass, adjustment screw (yellow) (see fi- der the knobs, proceeding as follows: gure below) clockwise. •Remove the control knobs by pulling them upwards.
-
Page 14: Changing From Lpg To Natural Gas
Changing gas (cont.) Changing from LPG to natural gas 3 - A , located un- DJUST THE LOW FLAME SETTING OF THE TAPS der the control knobs, proceeding as follows: To carry out this operation you must do the following in order: Working on each burner in turn. - Page 15 In the interests of product quality, screw we reserve the right to carry out any necessary changes and improvements without prior notice. Réf. : CH80X Don’t forget me CH80W Page 11 CH80E...
-
Page 16: Warranty And Service P
Please complete the enclosed warranty card and post it to us fied free of charge for parts and labour, provided that all service or phone our After Sales Service. is performed during normal working hours by Kleenmaid or their designated Agents. Where the appliance is installed outside the SERVICE ASSISTANCE...
