Page 1: Meeboss Multimedia Player
MeeBoss Multimedia Player User Manual Mee-M100 © 2013 MeeBoss Technology Inc. - Page 2 MeeBoss Multimedia Player FCC Regulations: 15.19(a)(3): This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 3: Table Of Contents
MeeBoss Multimedia Player Table of Contents 1. MeeBoss Multimedia Player ..................... 5 1.1 Device Overview ...................... 5 2. Quick Installation ......................6 3. System Settings ........................ 8 3.1 Network ........................8 Language ....................... 10 3.3 System ........................10 4. Media Playback ......................12 Playback from USB Storage ................... - Page 4 MeeBoss Multimedia Player © 2013...
-
Page 5: Meeboss Multimedia Player
MeeBoss Multimedia Player MeeBoss Multimedia Player 1.1 Device Overview Package Content: Multimedia Player Dongle x1 Micro USB Cable x1 USB Power Adapter x1 Remote Control Receiver x1 Remote Control x1 Installation Guide x1 1. Power – power on/off the device 2. -
Page 6: Quick Installation
Quick Installation Quick Installation To get started with your MeeBoss Multimedia Player, please follow the instructions below: 1. Connect the micro-USB cable to the MeeBoss Multimedia Player (dongle), and the power adapter to a power outlet. M100: 2. Connect the MeeBoss Multimedia Player dongle to an HDMI port on your TV. - Page 7 5. A MeeVideo main menu shall appear immediately. Use the MeeBoss remote control to switch between functions in main menu on screen. Once installation is complete, please proceed with the following settings: 1. Wi-Fi network setup. (see Chapter 3: System Settings > Network for more details) 2.
-
Page 8: System Settings
System Settings System Settings Once your device is correctly installed, use the MeeBoss remote control to toggle Settings on the MeeVideo main menu to make further configurations: 3.1 Network 1. In Settings page, select Network to complete network connection via Wi-Fi. - Page 9 4. Toggle on screen to return to previous menu page, or press OK on remote control to change a network to connect to. 5. Once you’re connected to the selected network, a Wi-Fi icon will appear on the right upper corner of the main menu, while the name of connected network is shown on the left bottom corner of the main menu.
-
Page 10: Language
1. In Settings page, select System to see system settings. 2. Change system name: this option allows you to change or type in a preferred name for your MeeVideo system. Update system: this option allows you to update the firmware of your MeeBoss multimedia player online. © 2013... - Page 11 3. Basic system information is also displayed in this page, e.g. Software Version, Firmware Version. © 2013...
-
Page 12: Media Playback
Media Playback Media Playback With MeeBoss multimedia player, you can play media files from a USB storage, an iOS mobile device (i.e. iPhone, iPad), or an Android phone. Media Type Supported Media Format MP4 / MPEG / MPG / MKV / WMV / RM / RMVB (optional) / AVI / FLV / TS... -
Page 13: Playback From Ios Mobile Device
Note: An iOS mobile device is capable of streaming media content to TV screen via MeeBoss Multimedia Player due to its built-in AirPlay function. AirPlay is a trademark of Apple Inc., registered in the US. -
Page 14: Playback From Android Phone
2. Open the app, browser through various video channels, and select a video you’d like to play back. PPTV YouTube 3. Tap on to select an output device (e.g. MeeApple [system name]). PPTV YouTube 4. The selected video will then be streamed to the selected output device for playback. 4.3 Playback from Android Phone Playback from Local Files 1. - Page 15 2. Connect your Android phone to the network where MeeBoss Multimedia Player is connected to. 3. Open MeePlayer Lite app on your Android phone, and you’ll be presented with two options: Controller and Local File. 4. Select Controller on the main menu to turn your phone into a remote control. You can then access MeeVideo functions on TV directly.
- Page 16 6. Then you’ll see all local multimedia files organized in three categories: Video, Audio and Picture. 7. Toggle between Video, Audio and Picture to select the type of media file you’d like to play. Select a media file, and select MeeAir ([system name]) as your output device. ©...
- Page 17 8. The selected media file will then be streamed to the selected output device for playback. Playback from Mobile Apps (PPTV or iMediaShare) 1. Please make sure you have PPTV or iMediaShare apps previously downloaded on your Android mobile device. 2.
- Page 18 3. On selected video, select your output device (e.g. Mee [system name]). PPTV iMediaShare Tap on to select an output to select an output device. Tap on device. 4. The selected video will then be streamed to the selected output device for playback. With iMediaShare app, you may also choose to play back media files from local folders in your Android mobile device.
-
Page 19: Miracast
2. Browse through local folders, and select a media file (e.g. photo, video) you’d like to play back. 3. Tap on to select an output device. 4. The selected media file will then be streamed to the selected output device for playback. 4.4 Miracast Miracast can mirror a display from one device (the source) to a second device (the display) without cables or a connection to an existing Wi-Fi network. - Page 20 To start Miracast, please follow the instructions stated below: 1. On the main menu of MeeVideo on TV, press Miracast to start. 2. On your Android phone, go to: Settings > Display > turn on Wireless Display. From available devices listed under Wireless Display, select the name of your output device (Supposedly, it should be the name of your TV where MeeVideo system is installed, e.g.
- Page 21 4. To disconnect from Miracast, simply just turn off Wireless Display on your phone to end the connection. © 2013...
-
Page 22: Meevideo App
- Search - Video Source - Standard: Return to Standard mode MeeVideo can serve as a remote control for the MeeBoss Multimedia Player. 1. Tap on your iOS device screen, and select OK from the pop-up reminder message dialog. © 2013... - Page 23 2. Select MeeAir as your destination output. 3. Then you’ll enter the main page of the remote control. The user interface of this remote control resembles the physical remote control. See more details about its operation in 1.1 Device Overview. ©...
-
Page 24: Troubleshooting
Troubleshooting Troubleshooting Q1: Why is there no screen after connecting MeeBoss Multimedia Player to my TV? A: Please make sure your TV supports 720p/1080p resolution. You may check if the HDMI cable is connected to the multimedia player and to your TV. Next, check the ports on the back of your TV, and make sure you have correct TV input source.
