• LED indicators for each source channel.
• Auto- switching with remote control
• Auto sensing inputs
• Extends the range of the HDMI compliant device by equalizing
and relocking the HDMI

Packing Contents

• proSwitch.H5
• Power Adapter-UK
• Remote Control
• User Guide
Appearance & Interface Description
Front View
Side View
Back View
SIGNAL
OUTPUT
HDMI
INPUT 5
DC 5V
L 1 L 2 L 3 L 4 L 5
INPUT 4 INPUT 3
HDMI
MANUAL POWER
SELECT
INPUT 2 INPUT 1
