- Page 1 22cc Hedge Trimmer Model No 101PHT22 Operator’s Manual WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual. Save this manual.
- Page 2 We would like you to be completely satisfied with your new product, so feel free to contact an authorized service dealer listed at the back of this manual, for help with service, genuine Pope parts or other information you may require. Or phone the Pope Customer Service Centre for details of your nearest dealer on 1300 134 880.
-
Page 3: Table Of Contents
Contents Safety Rules ............................. Symbols ..............................Specifications ............................Applications ............................. Features ..............................Unpacking ..............................Operation ..............................Mixing the Fuel ........................... Filling the Tank ........................... Starting the Product – To Start a Cold Engine ................Operating the Hedge Trimmer ....................... Maintenance ............................ -
Page 4: Safety Rules
Safety Rules WARNING: Read and understand all instructions. Failure to follow all instructions may result in serious personal injury as well as damage to product. ■ ■ Physical Condition of the Operator. Do Use of product. Never allow children or not operate this product when tired, ill or infirm persons to use the tool. -
Page 5: Symbols
Save These Instructions Symbols The following symbols are located on the product. Please study them and learn their meaning. Proper interpretation of these symbols allows you to operate the product better and safer. Symbol Name Explanation Safety Alert Indicates danger, warning or caution. Attention is required in order to avoid serious personal injury. -
Page 6: Specifications
Specifications Engine: 22.5 cc Full Crank Model 101PHT22 22cc Hedge Trimmer Blade Cutting Length: 600 mm Cutting Style: Dual action Weight (Dry): 5.6 kg Fuel Tank Capacity: 0.6 litres Maximum Cutting Diameter: 25 mm Applications Use this product for the following applications: ■... -
Page 7: Features
Features Before using the product, familiarize yourself with all operating features and safety requirements. However, do not let familiarity with the product make you careless. WARNING: Exercise caution when using the product. Careless actions, for even a fraction of a second, can result in serious or fatal injury. -
Page 8: Unpacking
Unpacking Instructions Packing List ■ Carefully remove the product from the box. 22.5cc Hedge Trimmer ■ Inspect the product carefully to make sure 2 Blade Safety Guards no breakage or damage occurred during Fuel Mixing Bottle shipping. Assembly Tools – 1 bag including: ■... -
Page 9: Operation
Operation Mixing the fuel Filling the Tank DANGER: WARNING: Always stop the engine before filling Petrol is extremely flammable and the tank. Never add fuel to a explosive. A fire or explosion from machine with a running or hot petrol will burn you and others. engine. -
Page 10: Starting The Product - To Start A Cold Engine
Operation – continued Starting the Product Starting the product depends on whether the engine is cold or warm. WARNING: The recoil starter can be damaged by abuse. Never pull the starter cord to its full length. Always engage the starter before cranking the engine. Always rewind the starter cord slowly. -
Page 11: Operating The Hedge Trimmer
Operation – continued Operating the Hedge Trimmer Do not cut any material other than hedges and shrubs. The hedge trimmer must only be used for the operations described in this Operator’s Manual. See Figs 1 and 2 Follow these steps to use the Hedge Trimmer: 1. -
Page 12: Maintenance
(includes Fuel Lines, Fuel Cap and Fuel Filter) Clean Air Filter Replace Spark Plug WARNING: When replacing parts other than engine or emissions parts, use only Pope replacement parts. Use of any other parts may create a hazard or cause product damage. -
Page 13: Cleaning The Product
Maintenance – continued BEFORE EACH USE: Maintaining the Blades ■ Remove dirt and debris from the product ■ Use a resin solvent on the cutter blades. exterior. Resin solvent protects the blades and has anti-corrosive properties. Use the resin ■ Inspect the engine, tank and hoses for solvent before and after work. -
Page 14: Cleaning The Air Filter
Maintenance – continued Cleaning the Air Filter See Fig. 3 Follow these steps to clean the air filter. Filter Filter Cover Knob Fig. 3 1. Stop the engine. 2. Remove the spark plug boot. 3. Loosen the air cleaner cover by turning the knob counter clockwise. -
Page 15: Replacing The Spark Plug
CAUTION: head area. Never store this product with any fuel The Pope Hedge Trimmer 101PHT22 uses remaining in the tank, fuel lines or an NGK BPMR7A spark plug. Use an exact carburettor. Your warranty does not replacement and replace annually. -
Page 16: Troubleshooting
Troubleshooting: Problem Possible Cause Solution Engine will not start 1. Switch set to OFF 1. Set switch to the ON position. position. 2. Remove the spark plug. Re-attach the spark plug 2. No spark. and lay the spark plug on the metal cylinder. Pull the starter cord and watch for a spark at the spark plug 3. -
Page 17: Warranty
Instructions for Obtaining Warranty Service Any part of the Pope Product found in the reasonable judgement of Toro Australia Pty Limited to be defective in material or workmanship will be repaired or replaced by an Authorised Service Dealer for this product without charge for parts or labour. - Page 18 Authorised Pope Service Dealers Macarthur Mowers Dover & Sons Oaklands Road Mower Magic Mowers APITAL ERRITORY Mitchell Lawnmower CAMDEN BEAUDESERT Centre MILDURA Centre (02) 4655 7793/ (02) 4655 6242 (07) 5541 1977 SOMERTON PARK (03) 5022 7088 MITCHELL (08) 8294 9799 Dover &...
