IBC Technologies SL 20-115 Installation And Operating Instructions Manual

Modulating gas boiler (natural gas or propane)
Hide thumbs
Table of Contents

Advertisement

Quick Links

Modulating gas Boiler
WARNING: If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury, or loss of life.
Do not store or use gasoline or other flammable vapours and liquids or other
combustible materials in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a nearby phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service
agency or the gas supplier.
this Manual is also available in French - contact iBC or visit our web site www.ibcboiler.com
SL 20-115
(Natural Gas or Propane)
www.ibcboiler.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SL 20-115 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IBC Technologies SL 20-115

Summary of Contents for IBC Technologies SL 20-115

  • Page 1 SL 20-115 Modulating gas Boiler (Natural Gas or Propane) WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury, or loss of life. Do not store or use gasoline or other flammable vapours and liquids or other combustible materials in the vicinity of this or any other appliance.

  • Page 2: Specifications

    SL 20-115 MODULATING GAS BOILER SAFETY CONSIDERATIONS Installation, start-up and servicing of IBC boilers must be done with due WARNING care and attention, and should only be performed by competent, qualified, licensed and trained heating technicians. If the information in this...

  • Page 3: Table Of Contents

    SL 20-115 MODULATING GAS BOILER CONTENTS INSTALLATION........... . 1-1 general .
  • Page 4 SL 20-115 MODULATING GAS BOILER The Installer must carefully read this manual to ensure that all installation details can be adhered to. Special attention is to be paid to clearances and access, vent travel and termination, gas supply, condensate removal and combustion air supply.

  • Page 5: Installation

    2 3/4” x 1 1/2” Water outlet 1” nPt-F Water inlet 1” nPt-F Knock-outs (6) 1/2” gas inlet 1/2” nPt-F Condensate outlet 3/4” Hose Table 1: Connections Figure 1b: Dimensions / Connections for SL 20-115 Figure 1a: Dimensions / Connections for SL 20-115 INSTALLATION...

  • Page 6: Code Requirements

    SL 20-115 MODULATING GAS BOILER Code reQuireMents The SL 20-115 model was tested to and certified under CSA 4.9-2010 / ANSI Z21.13-2010. installation must conform to local codes, or in the absence of these, with the latest editions of Can/Cga B149 and the Canadian electrical Code Part 1 Csa C22.2 no. 1. in the us, installations must conform to the current national Fuel gas Code ansi Z223.1 and the national electrical Code ansi/nFPa 70.

  • Page 7: Exhaust Venting And Air Intake

    SL 20-115 MODULATING GAS BOILER contaminants; combustion air should be drawn from a CLEAN source WARNING (e.g. outdoors) and the boiler should be isolated from interior dust sources. Exposed water piping and associated components (relief valves, circulators, etc.) DISTANCE FROM...
  • Page 8 SL 20-115 MODULATING GAS BOILER all venting must be installed in accordance with the requirements of the WARNING jurisdiction having authority: in Canada, Part 8, Venting Systems of the B149.1- 10 Code and any other local building codes are to be followed. in the usa Venting, condensate the national Fuel gas Code, ansi 223.1, latest edition, prevails.
  • Page 9 SL 20-115 MODULATING GAS BOILER • any improper operation of the common venting system should be corrected so the installation conforms with the national Fuel gas Code, ansi Z223.1 - latest edition. in Canada, all installations must conform with the current Can/ Cga - B149.1-10 installation Code and/or local codes.
  • Page 10 CPVC or PPs (rigid single Wall) piping is the standard venting option; with this, the sl 20-115 boiler, for example, can be sited up to 100 equivalent feet from the vent termination using 2” or up to 240’ using 3”. the actual vent travel allowance is reduced for fittings in accordance with Table 3.
  • Page 11 SL 20-115 MODULATING GAS BOILER overcome gravity on 1/4” / foot vent slope – leaving a pool of condensate at the next upturned elbow. Pooling can impair the achievement of full high-fire rating plate performance. Exhaust piping is inserted directly into the 3” female stainless steel fitting on the top, left side of the boiler and run horizontally or vertically to the outdoors.
  • Page 12 SL 20-115 MODULATING GAS BOILER 1.4.5 Rooftop vent Termination rooftop vents must terminate as follows: • the exhaust pipe can terminate in an open vertical orientation without concern WARNING about rain infiltration; rain will drain away through the condensate trap. • if used, the intake air pipe is not typically drained, so it must be terminated Condensate can cause with a down-turned elbow (see Figure 4).
  • Page 13 SL 20-115 MODULATING GAS BOILER • use a 45° elbow on the exhaust termination to launch the plume up and off WARNING the sidewall, for protection of wall. It is extremely important • Bird screen of 1/4” stainless steel or plastic mesh (iPeX system 636 drain to maintain at least the grate) is useful to guard against foreign objects.
  • Page 14 SL 20-115 MODULATING GAS BOILER Figure 9: Sidewall vent termination - multiple vent piping configuration Vent terminal clearance minimums are as follows: • Clearance above grade, veranda, porch, deck or balcony – 12” (0.3m), but check local code also (anticipated snow levels may supersede).
  • Page 15 • Clearance under veranda, porch, deck or balcony: - 12” (0.3m) IBC strongly recommends a minimum of 24” with the SL 20-115 to avoid damage to the structure. Note: Prohibited unless fully open on a minimum of two sides below the floor.
  • Page 16 SL 20-115 MODULATING GAS BOILER INTAKE PIPE SIZE MAxIMUM EqUIvALENT LENGTH Sched.40; Rigid PPs 2” 100’ 3” 240’ 90° long sweep elbow allow 5’ equivalent 90° vent elbow allow 8’ equivalent 45° elbow allow 3’ equivalent PPs 87-90° elbows use 8’ equivalent air intake Filter (Part #103) allow 8’...

  • Page 17: Closet Installations

    SL 20-115 MODULATING GAS BOILER an “indoor Combustion air installation”, as described herein, is one in which air for combustion is taken from the ambient air around the boiler. To support combustion, an ample air supply is required. This may require NOTE direct openings in the boiler room to the outside.

  • Page 18: Condensate Removal

    SL 20-115 MODULATING GAS BOILER Condensate reMoVal IBC’s specified vent configuration promotes the safe drainage of moisture from WARNING the boiler and exhaust venting without flowing liquids back through the heat exchanger (as done by some other condensing boilers). Fill trap with water before reliable system operation requires (1) proper design and installation of exhaust boiler is first fired to prevent venting to allow condensate to run back to the drain/trap;...
  • Page 19 SL 20-115 MODULATING GAS BOILER 1.5.3 Condensate Trap Assembly - cleaning procedure turn off the power to the boiler and allow it to cool down. remove the trap from the boiler (reverse the installation procedure above). remove the trap Cleanout assembly (H), from the trap Body and clean and flush the debris out.
  • Page 20 SL 20-115 MODULATING GAS BOILER Figure 17: Condensate trap disassembly for cleaning Figure 18: Condensate trap drainage WARNING If condensates are to be discharged into building drain piping materials that are subject to corrosion, a neutralization package must be used.

  • Page 21: Water Piping

    Water PiPing 1.6.1 General Piping Issues the sl 20-115 boiler was designed to be easy to install in almost any application. its unique multi-port piping design allows connection from either side or both sides at once. With the purchase of the optional bottom connection kit, available from iBC, piping can be routed below the unit for connection to system piping or primary loop.
  • Page 22 SL 20-115 MODULATING GAS BOILER the sl modulating series boilers are designed for use within a closed loop, forced circulation, low pressure system. a 30 psi pressure relief valve (3/4” nPt) is supplied for field installation at one of the locations shown in the following illustrations. relief valve discharge piping must terminate between 6” (15cm) and WARNING 12” (30cm) above the floor or per local Code.
  • Page 23 & controls. if needed, create a shield over the top of the cover, but allow clearance for airflow and service access. For best results, use a Primary: Secondary piping system, with a pumped boiler loop using 1” piping for the sl 20-115. Heat exchanger head is only 1’ at 4 usgpm and approximately 9’ at 10 usgpm. The minimum flow rate required through the heat exchanger is 2 USgpm with a maximum of 14 usgpm allowed.
  • Page 24 SL 20-115 MODULATING GAS BOILER the sl series modulating boilers are designed to supply three different WARNING heating loads with temperatures within the range 34°F to 180°F - to meet three Water quality has a significant separately piped loads. use closely spaced tees to connect each pumped “load”...
  • Page 25 SL 20-115 MODULATING GAS BOILER schematics for several piping layouts are provided herein, and additional NOTE drawings are available at www.ibcboiler.com. installers shall conform the piping design to one of the provided configurations to simplify the control application, This piping drawings in this promote good loads and flow management. manual are simple schematic guides to a successful installation.
  • Page 26 SL 20-115 MODULATING GAS BOILER Figure 27: Basic Primary/Secondary piping with hydraulic separator concept Figure 28: Important Primary/Secondary piping details with hydraulic separator 1-22 INSTALLATION AND OPERATION INSTRUCTIONS...
  • Page 27 SL 20-115 MODULATING GAS BOILER Figure 29: Primary/Secondary piping to a hydraulic separator / distribution manifold Figure 30: Parallel piping connection to one side 1-23 INSTALLATION...
  • Page 28 SL 20-115 MODULATING GAS BOILER Figure 31: Parallel piping connection to two sides WARNING Propylene glycol solution is commonly used in a closed loop where freeze protection is required. its density is lower than that of water, resulting in Do not use automotive-type lower thermal performance at a given flow and pressure. As a rule of thumb,...
  • Page 29 SL 20-115 MODULATING GAS BOILER For optimal performance, place pumps on the supply side of secondary loops to facilitate air evacuation. use pumps with internal check valves to avoid ghost flows and thermal siphoning. the primary loop temperature may need to transition from a 180°F domestic water heating load to a 100°F radiant floor requirement. The secondary pumps...
  • Page 30 SL 20-115 MODULATING GAS BOILER PARALLELL LOAD PIPING - bENEFITS AND INSTALLATION RULES Compared with the Primary/secondary approach, the design below saves one pump. Lost is the simplicity of constant head and flow at the boiler. Figure 33: Two pump, two load - parallel piping concept Wiring: in a parallel piping application, disconnect the wire from the Pump Block, terminal 11 (P/V Power - l), and isolate it using a wire nut, crimp connector or other secure means to prevent the bare wire from contacting anything.
  • Page 31 SL 20-115 MODULATING GAS BOILER MULTIPLE bOILER PIPING - bENEFITS AND INSTALLATION RULES NOTE Multiple iBC boilers can be installed in a single heating system to provide For further information and redundancy, increased output, and greater heating plant turn-down capabilities.

  • Page 32: Gas Piping

    SL 20-115 MODULATING GAS BOILER 1.7 gas PiPing the boiler requires an inlet gas pressure of at least 3.0" w.c. for natural gas or WARNING propane. For either fuel, the inlet pressure shall be no greater than 14.0" w.c. This boiler model can burn Confirm this pressure range is available with your local gas supplier.

  • Page 33: Electrical Connections

    SL 20-115 MODULATING GAS BOILER eleCtriCal ConneCtions all electrical wiring to the boiler (including grounding) must conform to local electrical codes and/or national electrical Code, ans/nFPa no. 70 – latest edition, or the Canadian electrical Code, C22.1 - Part 1.
  • Page 34 SL 20-115 MODULATING GAS BOILER 1.8.2 Power quality and Electrical Protection NOTE in areas of unreliable power, appropriate surge protectors and or power The IBC boiler (like any conditioning equipment should be installed in powers supply wiring circuits. modern appliance that...

  • Page 35: Thermostat Heat Anticipator

    SL 20-115 MODULATING GAS BOILER 1.8.6 Thermostat Heat Anticipator iBC “therm.” contacts draw no power, so an anticipator setting for the thermostat is not applicable with the sl modulating series boilers. in the case of a single temperature / heat load where zone valves are used to manage individual thermostatically controlled zones, each room thermostat’s heat anticipator should...
  • Page 36 SL 20-115 MODULATING GAS BOILER 1-32 INSTALLATION AND OPERATION INSTRUCTIONS...

  • Page 37: Boiler Systems And Operation

    SL 20-115 MODULATING GAS BOILER 2.0 bOILER SYSTEMS AND OPERATION general residential sl series modulating boilers are designed to service three separate, WARNING directly piped heating loads using different pre-selected water temperatures and If the boiler can become heat regulation routines. external controls can extend applications.

  • Page 38: Access Levels

    SL 20-115 MODULATING GAS BOILER 2.3.2 LCD Display Upon power-up, the LCD screen initially flashes a software release number then switches to a Standby- display mode, showing real time data plus key temperature target settings. When there is a call for heat from any load, that load is identified at the Status line (e.g. Heating – RFL (for radiant floor) in place of Standby). the target temperature for the relevant load is conspicuously displayed while that load is being handled.

  • Page 39: Advanced Setup

    SL 20-115 MODULATING GAS BOILER 2.4.1 User setup the occupant has access to a number of practical settings. the most meaningful include adjustment of the indoor temperature target plus the temperature setback and occupied / unoccupied modes. the user Menu also provides access to the time & date fields, provides the means to toggle between C° / F° plus allows...

  • Page 40: Sequence Of Operation

    SL 20-115 MODULATING GAS BOILER seQuenCe oF oPeration the control module has 5 cycles during normal operation, as well as an error mode for problem detection: standby cycle Purging ignition cycle Heating cycle Circulating cycle error mode Each state is explained below. A flow chart for the sequence of operation can be found in the back of the manual.
  • Page 41 SL 20-115 MODULATING GAS BOILER the pump remains on for 5 minutes (adjustable) after the heating cycle ends. if the heating cycle ends as a result of water temperature exceeding the load specific band limit, the postpurge will continue as normal, but the boiler will enter the circulating mode.

  • Page 42: Other Operating Features

    SL 20-115 MODULATING GAS BOILER until the loop drops ½ the differential below the new load target temperature. note: if there is no place to sink heat during such Circ. mode, this phase will continue indefinitely, affecting heat delivery. thermal shock avoidance is key. Wherever two or more loads are used, and settings could permit supply temperature differences greater than 20°F, external...
  • Page 43 SL 20-115 MODULATING GAS BOILER running of a radiant floor. The large throttle turndown range coupled with outdoor reset means that several loads can receive heat in-turn, with less on/off duty cycling than would occur with other heat sources. the boiler is shipped with default values for each type of declarable load (e.g.
  • Page 44 SL 20-115 MODULATING GAS BOILER Figure 37: Outdoor reset curves Contacts are provided for connection of an outdoor sensor (a tekmar 070 or similar sensor is shipped with each boiler) to be placed in an appropriate outdoor position. The temperature management algorithm flexes the boiler supply temperature according to characterized heating curves that are automatically called up through the load declaration process.
  • Page 45 SL 20-115 MODULATING GAS BOILER if outdoor reset is selected and there is no signal received from the sensor, the controller assigns a provisional 0°C value and will adopt the appropriate temperature target from the relevant reset curve. See Section 2.7 Set Up & Load Definition for activation procedure.

  • Page 46: Set Up & Load Definition

    SL 20-115 MODULATING GAS BOILER From the main installer setup Menu, select “Heat Load Configuration”, then “Configure Load (use the load number tagged as Space Heating)”, and drop down to “summer shutdown”. Press enter to select, then use the keys to move the threshold temperature to the desired level, and press the centre key again to record.
  • Page 47 SL 20-115 MODULATING GAS BOILER Each of the boiler’s 3 Load positions can be configured for any type of heating. sl boilers are factory shipped with default settings as follows: load 1 set as Space Heating or Reset Heating, with High Mass Radiant Floor set as the terminal type; load 2 as set Point; and load 3 as dHW. the factory defaults can be changed using the Define Load 1-2-3 lines to reverse the order, turn off a load or do whatever the installer desires.
  • Page 48 SL 20-115 MODULATING GAS BOILER avoid situations where the Maximum is close or below the potential target, or the boiler will cycle off its (software) water high limit. Priority:- where more than one load is present, it is critical that a value be entered to allow reasonable load scheduling (see Section 2.6.1).

  • Page 49: Startup And Commissioning

    SL 20-115 MODULATING GAS BOILER STARTUP AND COMMISSIONING 3.1 ligHting and sHutting doWn tHe Boiler STARTUP AND COMMISSIONING...

  • Page 50: Prior To Start-Up

    CoMMissioning the sl 20-115 modulating boilers are factory calibrated to operate with natural gas (or propane if so ordered) at sea level. the Zero-offset valve adjustment cap has been factory sealed using red paint-seal compound. This cap must not be tampered with.
  • Page 51 SL 20-115 MODULATING GAS BOILER To verify the proper operation of the gas valve in the field, the following procedure WARNING can be carried out by a qualified technician (see Figure 38). Check the rating plate of the With a small (1/8” or 3 mm) flat screwdriver, open the inlet gas supply boiler to ensure it is configured pressure test port by turning its center-screw 1 full turn counterclockwise. for the fuel you are using. If attach a manometer to the pressure test port and turn on gas to appliance.
  • Page 52 SL 20-115 MODULATING GAS BOILER 3.3.1 Gaining access to combustion chamber, burner NOTE removal instructions The safety warning regarding remove fan and gas valve assembly. See “Fan and gas valve removal burner refractory on page instructions” on page 4-6 of this manual.

  • Page 53: Maintenance

    SL 20-115 MODULATING GAS BOILER MAINTENANCE Boiler MaintenanCe 4.1.1 General Care CAUTION • Keep combustible materials and flammable liquids and vapours away from the The owner is responsible for boiler. general care of the boiler. • Keep vent terminals clear of obstructions (snow, dirt, etc.). Improper maintenance of the boiler may result in a hazardous condition.

  • Page 54: Heat Exchanger

    SL 20-115 MODULATING GAS BOILER 4.1.6 Heat Exchanger CAUTION during annual inspection (with the burner removed), examine the heat exchanger The heat exchanger has a small for signs of contamination and clean if necessary. in areas of poor gas quality, amount of combustion chamber there may be a buildup of black plaque (typically sulfur).

  • Page 55: Freeze Protection

    SL 20-115 MODULATING GAS BOILER 4.1.11 Freeze Protection WARNING Check freeze protection. Use only antifreeze made specifically for hydronic Do not use automotive-type systems. inhibited propylene glycol is recommended. antifreeze volume must not ethylene or other types of exceed 50% of the total volume of water in the system.

  • Page 56: Geography & Components

    SL 20-115 MODULATING GAS BOILER geograPHY & CoMPonents Note: Vent stack piping and air intake riser have been removed in some of these photos for clarity Fan housing Gas valve connection block Removing front cover Gas valve Fan motor Ignition module...
  • Page 57 SL 20-115 MODULATING GAS BOILER Water temperature high limit switch Water pressure sensor Combustion air intake riser Upper vessel high limit switch Ignition electrode/flame sensor Removing combustion air intake riser Outlet (supply) water temperature sensor Fan coupler block Removing vent stack...
  • Page 58 SL 20-115 MODULATING GAS BOILER 4.2.1 Fan and gas valve removal instructions turn off electric power and gas supply to the boiler. ensure boiler cools down to ambient temperature. do not drain the boiler unless freezing conditions are expected during this procedure.

  • Page 59: Troubleshooting

    SL 20-115 MODULATING GAS BOILER 5.0 TROUbLESHOOTING the troubleshooting section is divided into 3 sections: NOTE 5.1 Preliminary Checks This boiler is equipped with a 5.2 Electronic Components blocked vent shutoff system, which closes the gas supply 5.3 Troubleshooting Guide...

  • Page 60: Electronic Components

    SL 20-115 MODULATING GAS BOILER eleCtroniC CoMPonents this section details the method for troubleshooting the non-standard electronic components on the boiler including the electronic differential air pressure sensor and the temperature sensors. 5.2.1 Temperature Sensors the resistance of the temperature sensors varies inversely with temperature. to...
  • Page 61 SL 20-115 MODULATING GAS BOILER 5.2.2 Fan/blower operating power is provided by means of a separate 120 VaC connector at the bottom of the fan (white/black/green). Control of the fan is provided via a four lead connector at the top of the fan. this connector feeds a PWM control signal (black wire) from the controller and provides a tachometer signal (white wire) back from the fan.

  • Page 62: Water Pressure Sensor

    SL 20-115 MODULATING GAS BOILER Next, confirm that the circuit is properly powered. The supply voltage to the sensor should be 13.8 VdC; to check, the simplest technique is to measure the circuit on the face of the controller circuit board (vs. an attempt to splice into the harness / connectors). See previous page for a presentation of the measurement points.

  • Page 63: Troubleshooting Guide

    SL 20-115 MODULATING GAS BOILER 5.3 trouBlesHooting guide 5.3.1 Using Control Module Errors Displayed SYMPTOM DIAGNOSIS REMEDY AIRFLOW ERROR Check fan operation • Check lead is attached at fan. • Cycle power off/on; listen for fan initialization. LCD Screen Message: if no action, focus your attention on the fan itself. Error – Insufficient Air Flow Check for fouled • Check clear vinyl air pressure line for...
  • Page 64 SL 20-115 MODULATING GAS BOILER SYMPTOM DIAGNOSIS REMEDY MAxIMUM IGNITION TRIALS No spark when igniting. Check that igniter lead is secure at the control ERROR Igniter probe/flame module and at the probe. sensor disconnected. LCD Screen Message: Manual gas shutoff is Check for gas flow. Open manual gas shutoff...

  • Page 65: Ignition Problems

    SL 20-115 MODULATING GAS BOILER SYMPTOM DIAGNOSIS REMEDY vENT HI-LIMIT ERROR Indicates one or both • Check wiring to ensure switches are properly switches has tripped. connected to control module. LCD Screen Message: • Check for evidence of any damage to vent Error - Vessel/Vent High-Limit system and signs of excess heat near Exceeded *** Call for service! switches.
  • Page 66 SL 20-115 MODULATING GAS BOILER SYMPTOM DIAGNOSIS REMEDY • bOILER WILL NOT ATTEMPT No power to ignition Check system wiring. TO IGNITE. FAN AND PUMP control module. • Check air reference tubing. ARE OPERATING NORMALLY. Igniter probe/flame reconnect probe. sensor disconnected.
  • Page 67 SL 20-115 MODULATING GAS BOILER SYMPTOM DIAGNOSIS REMEDY RAPID CYCLING Insufficient water flow Check manufacturer’s rating charts/check due to undersized temperature differential across heat exchanger. pump. Insufficient water flow Check temperature differential across zone/heat due to restrictions in exchanger. water pipe.
  • Page 68 SL 20-115 MODULATING GAS BOILER SYMPTOM DIAGNOSIS REMEDY TEMPERATURE ExCEEDS Incorrect anticipator Check with ammeter. THERMOSTAT SETTING setting. Thermostat not level. Check level. ONE OR MORE ZONES DO Air trapped within Vent system/zone as required. NOT HEAT PROPERLY zone(s) piping...

  • Page 69: Diagrams

    SL 20-115 MODULATING GAS BOILER 6.0 DIAGRAMS 6.1 - Parts diagraMs 6.2 - Wiring diagraMs 6.3 - seQuenCe oF oPeration DIAGRAMS...

  • Page 70: Parts List & View

    SL 20-115 MODULATING GAS BOILER 6.1 Parts diagraMs SL 20-115 Modulating boiler - Parts assembly Diagram 6.1-1: Boiler assembly parts INSTALLATION AND OPERATION INSTRUCTIONS...
  • Page 71 SL 20-115 MODULATING GAS BOILER ITEM PART NO. DESCRIPTION 240-027 180-017 air intaKe Housing Base 180-010 Fan adaPter Plate 180-018 air intaKe Housing CoVer 500-030 air intaKe tuBe 180-014 air intaKe sWirl Plate 180-008 gas ValVe 250-174 gas ValVe inlet BloCK...
  • Page 72 SL 20-115 MODULATING GAS BOILER 6.2 Wiring diagraMs Diagram 6.2-1: Pictorial wiring diagram INSTALLATION AND OPERATION INSTRUCTIONS...
  • Page 73 SL 20-115 MODULATING GAS BOILER Diagram 6.2-2: Ladder wiring diagram DIAGRAMS...
  • Page 74 SL 20-115 MODULATING GAS BOILER Diagram 6.2-3: Internal wiring diagram INSTALLATION AND OPERATION INSTRUCTIONS...
  • Page 75 SL 20-115 MODULATING GAS BOILER 6.3 seQuenCe oF oPeration Diagram 6.3: Sequence of operation diagram DIAGRAMS...
  • Page 76 installation & CoMMissioning rePort boiler Details: Model Number _____________________ Serial Number ______________________________________________ Date of Installation ______________ Address of installation __________________________________________ _____________________________________________________________________________________________ User contact information _______________________________________________________________________ Installer Information Company ___________________________________________________________________ address ______________________________________________________________________________________ Phone/Fax/e mail ______________________________________________________________________________ Fuel natural gas Propane Gas Supply Pressure (high fire) _______ inches w.c. Measured Rate of Input (high fire) ____________ Btu/hr installation instructions have been followed and completed (section 1 of installation and operating instructions).

  • Page 77: Service Record

    installer set-uP Load Definition - Load #1 _______________________________________________________________________ Load Configuration - Load #1 _____________________________________________________________________________________________ Load Definition - Load #2 _______________________________________________________________________ Load Configuration - Load #2 _____________________________________________________________________________________________ Load Definition - Load #3 _______________________________________________________________________ Load Configuration - Load #3 _____________________________________________________________________________________________ serViCe reCord DATE LICENSED CONTRACTOR DESCRIPTION OF WORK DONE...
  • Page 78 notes...
  • Page 79 as referenced on page 2-7 of this manual, the following message is relevant to users in the usa: IMPORTANT this Boiler is equipped with a feature that saves energy by reducing the boiler water temperature as the heating load decreases. this feature is equipped with an override which is provided primarily to permit the use of an external energy management system that serves the same function.
  • Page 80 IbC Technologies Inc. 1445 Charles street, Vancouver, BC Canada V5l 2s7 tel: 604.877.0277 Fax: 604.877.0295 www.ibcboiler.com 120-116E-A-R2 september 2012...
