PATIO COMFORT

NATURAL GAS FUELED OUTDOOR PATIO HEATER

MODEL NPC05

ASSEMBLY INSTRUCTIONS

CARE, USE, AND SAFETY MANUAL

FOR YOUR SAFETY!

Do not store or use gasoline

or other flammable vapors or

liquids in the vicinity of this or

any other appliance.

IMPORTANT!

Please read these assembly instructions

carefully before attempting to assemble,

use, or service this product.

Please

keep

this

manual

for

your

future

reference. If you have any questions,

please feel free to call us at 949-474-

3070 Monday through Friday 7AM to

4PM Pacific Time.

General Hazard Warning:

Improper installation, adjustment,

alteration, service or maintenance of

this product can cause injury or

property damage. Please read the

installation, operating, and maintenance

instructions thoroughly before installing

or servicing this appliance.

Please read all operating instructions

before using and operating this appliance.

Always follow the correct lighting and

usage procedures.

Please handle metal parts with care to

WARNING:

avoid injury. Please follow all steps as

This product is for Outdoor Use Only

outlined.

Never allow children to use this product!

Revised 7-06-05 gfs

AEI CORPORATION 2005

Table of Contents

Need help?

Do you have a question about the NPC05 and is the answer not in the manual?

Questions and answers

Summary of Contents for patio NPC05

Page 1: Basic Safety And Operational Data
PATIO COMFORT NATURAL GAS FUELED OUTDOOR PATIO HEATER MODEL NPC05 ASSEMBLY INSTRUCTIONS CARE, USE, AND SAFETY MANUAL FOR YOUR SAFETY! Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other appliance.
Page 2 Patio Comfort replacement part. 9. When using your heater with 12-foot hose please be sure that the hose is placed in a manner where it cannot be damaged or positioned in a way that someone might trip over it.
Page 3: R Eflector
Please note the following very important safety precautions: Children and adults should be alerted to the hazards of high surface temperatures of the main burner and reflector and should stay away from these areas. Children should be carefully supervised when near the heater. This heater is not a toy and children should not be allowed to push, climb on, or swing on the heater.
Page 4: Assembly Instructions - Step 2 To
The preceding pages attempt to highlight only the most important safety aspects and guidelines for using your natural gas fueled Patio Comfort heater. We have made every effort to thoroughly address all safety, assembly, lighting, and use issues for this product in the manual to follow.
Page 5: Table Of Contents
Table of Contents PAGE BASIC SAFETY AND OPERATIONAL DATA TABLE OF CONTENTS TECHNICAL DATA FUNCTION OF HEATER ASSEMBLY TIPS PARTS DIAGRAM DESCRIPTION HEAD ASSEMBLY PARTS DIAGRAM DESCRIPTION ASSEMBLY TOOLS NEEDED FASTENER IDENTIFICATION – ASSEMBLY INSTRUCTIONS STEP – ASSEMBLY INSTRUCTIONS STEP –...
Page 6: Technical Data
Technical Data: Model NPC05 Function of Heater Infrared heaters utilize virtually 100% of the This unit is designed and configured fuel/energy they consume to produce clean draft- for use with Natural Gas Only. free warmth. Infrared heaters do not waste precious energy by trying to heat the air.
Page 7: Assembly Instructions - Step 5 To
When starting the assembly process please take all transit. If anything is missing, please contact your of the parts out of the boxes and check if anything is Patio Comfort local dealer or call us directly at missing. Please check parts with the following parts 949-474-3070.
Page 9: Parts Diagram / Description ( Sub - Assembly )
NPC05 ATIO OMFOR UTDOOR ATIO EATER ODEL ARTS IAGRAM AND EPAIR ARTS PART# DESCRIPTION PART# DESCRIPTION 1001 M8 SS 1028 . SS LAT WASHER MM DIA 1001-03 M8 SS 1029 . SS OCK WASHER MM DIA ACEPLATE FOR LIGHTING 1002 .
Page 10: Tools Needed
PLEASE NOTE: he appliance. Call your authorized heater requires basic mechanical skills. Proper Patio Comfort dealer and only use genuine Patio Comfort replacement parts. Using improper parts assembly and installation is the responsibility may damage the product or cause physical or of the customer.
Page 11 We have tried to make the assembly of your Patio Comfort Natural Gas heater as simple as possible while maintaining the highest levels of safety and performance.
Page 12: Assembly Instructions - Step 10 To
Figure 2A Step 2 A: Slide 3” Vinyl sleeve down post. Align the holes in the socket with the post and vinyl sleeve. Insert lock washer, flat washer, and screw into four holes. (See Figure #2 A) Step 2 B. Figure #2B Securely tighten the four stainless steel screws with flat washers and...
Page 13: Aei Corporation
Step 5: If the 3/8” x 3/8” flared brass fitting is screwed into the shorter feed line Figure #5 hose please remove it at this time and attach this fitting at the base of the heater head. Tighten securely. Do not use any pipe sealant at this brass to brass connection.
Page 14: Assembly Instructions - Step 13 To
At this point we need to stop assembling the heater and test for any possible gas leaks in the regulator assembly and head to feed line connection. In order to achieve the leak testing we must attach the twelve-foot hose and couplers to the gas supply. If you are not comfortable either hooking up the valve at the gas supply line or leak testing the unit you should contact a licensed plumber, gas technician, or public utility.
Page 15 Step 10: (See Figure #10) Figure #10 Testing For Gas Leaks 1) The hose should be properly engaged at the quick disconnect coupler at the post and at the house supply. Please turn the supply of gas ON. 2) Using a soapy solution carefully check each and every fitting, quick coupler, and gas connection.
Page 16 Step 13: Figure #13 You can now attach the heater reflector with the three 8 mm flat washers and wing nuts provided. (See Figure #13) Figure #14 Step 14: Be sure the to attach the blue colored protective rubber plug onto the fitting before inserting it into the gas inlet in the post.
Page 17 This hose, coupler, and shut-off valve assembly comply with all UL standards. DO NOT attempt any modifications to this hook-up. You have now finished the assembly of the heater. We have tried to design your Patio Comfort heater with the finest materials and safety systems available. Please do not try to modify any part of the product, the feed line assembly, natural gas regulator, or quick disconnect connections.
Page 18: Information On Natural Gas Supply
The heater is set to operate 4.5” W.C. No attempt should be made to modify any of the components included with your Patio Comfort natural Gas heater. In most areas of the U.S. and Canada, natural gas pressure in residential settings is adequate to fuel patio heaters, outdoor gas grills, gas lights, pool heaters, etc.
Page 19: Placement Of Heater
Placement of the Heater Your Patio Comfort outdoor patio heater is designed for use as temporary comfort heating for your outdoor patio, outdoor decks, outdoor spa areas, pool areas, and other outdoor areas with plenty of fresh air. The heater is NOT designed, approved, or intended for indoor use or enclosed area use such as a garage, commercial building, basements, tents, ice fishing tents, prefabricated buildings or enclosures or other enclosed areas.
Page 20: Lighting Instructions
Lighting Instructions Before turning on the natural gas fuel supply, visually inspect the hose assembly for evidence of excessive abrasion, cuts, cracking, animal damage, or unusual wear and tear. If the hose leaks do not attempt to use the heater, replace the hose immediately. Only use replacement hoses and other parts as specified by Patio Comfort Before Lighting...
Page 21: Heater Storage And Insect Warning
Store your heater in an upright position in an area sheltered from inclement weather such as rain, snow, sleet, hail, dust storms, and other blowing debris. Patio Comfort makes a cover available to protect the burner head. We strongly recommend using our cover when your heater is in storage or not in use.
Page 22: Cleaning And Maintenance
In a salt air or ocean environment, corrosion and rust occurs at a far greater rate than in non-ocean areas. You will need to more frequently check for corrosion and replace parts as required. The best protection for the Patio Comfort critical heater head is a cover that has been specifically designed for your heater.
Page 23: Trouble Shooting Guide
3) Thermocouple is not operating 3) Depress Knob in “Pilot” position for properly. full 30 seconds. Remove emitter grid replace thermocouple. Use only Patio Comfort thermocouples and parts. 4) High wind condition blowing out pilot flame. 4) Put heater in more protected location.
Page 24: Warnings And Safety Points
Important Warnings and Safety Points!!! For Your Safety: For Your Safety: If you smell gas: Do not store or use gasoline or other 1. Shut off gas to the appliance Flammable vapor and liquids in the vicinity of 2. Extinguish any open flame near the appliance this or any other appliance.
Page 25 If you have any questions whatsoever about the assembly or operation of this product please contact your authorized Patio Comfort retailer or call us directly at 949-474-3070 or E-mail . This product has been designed and constructed to provide you and aeicorp@sbcglobal.net...
Page 26: Service And Warranty Information
Be sure to use only genuine Patio Comfort replacement parts for your heater. Use of unauthorized parts or modification of our parts will void the heater warranty and could create personal injury or property damage.
Page 27: Legal Rights
We know that you and your family will enjoy your Patio Comfort heating product for many years to come and that it will be a welcome addition and important ingredient to your outdoor entertainment and activities.
Page 28: Warranty Registration Form
Patio Comfort Congratulations on purchasing a Model NPC05 Outdoor Heater. To ensure that you’ll get all of the warranty protection that comes with the purchase of this fine product please fill out the Warranty Registration Form and send it back to us within 10 days of purchase.
