FOR YOUR SAFETY!
Do not store or use gasoline or
other flammable vapors or liquids
in the vicinity of this or any other
open flame appliance.
WARNING: For Outdoor Use Only
IMPORTANT!
Please read these assembly instructions
carefully before attempting to assemble,
use, or service this product. Please keep
this manual for your future reference. If
you have any questions, please feel free to
call us at 949-474-3070 Monday through
Friday 7AM to 4PM Pacific Time.
General Hazard Warning:
Improper installation, adjustment,
alteration, service or maintenance of this
product can cause injury or property
damage. Please read the installation,
operating, and maintenance instructions
thoroughly before installing or servicing
this appliance.
Please read all operating
instructions before using and
operating this appliance.
Always follow the correct lighting and
usage procedures. Please handle metal
parts with care to avoid injury. Please
follow all steps as outlined. Never allow
children to use this product!
Vintage
0
PATIO COMFORT
1
OUTDOOR PATIO HEATER
2 0
Vintage Series Model PC-02 CAB
ASSEMBLY INSTRUCTIONS
CARE, USE, AND SAFETY MANUAL
Please Note:
This product is for outdoor use only!
This product meets or exceeds CSA
Requirement for Gas Fired Infrared Patio
Heaters No. 5.90 – 2000. Canada 1-2.23
M82. Please use a Type 1 QCC ACME Tank
Only with Overfill Protection Device
(OPD).Maximum inlet pressure 11"
1
Manual Revised 10/12/2007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vintage PC-02 CAB and is the answer not in the manual?

Questions and answers

Related Manuals for patio Vintage PC-02 CAB

Summary of Contents for patio Vintage PC-02 CAB

  • Page 1: Basic Safety And Operational Data

    Vintage PATIO COMFORT OUTDOOR PATIO HEATER Vintage Series Model PC-02 CAB ASSEMBLY INSTRUCTIONS CARE, USE, AND SAFETY MANUAL FOR YOUR SAFETY! Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other open flame appliance.
  • Page 2 Caution : Hot while in operation. Do not touch. Keep children, clothing, furniture, gasoline, and other liquids having flammable vapors away. Please pay particular attention to section with this symbol, it notes a very important safety issue: 1. The installation of this appliance must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code ANSI Z223.1-1988.
  • Page 3 The heater should be visually inspected before each use and at least annually by a qualified service person. Certain weather conditions such as being near the ocean, dusty areas, areas with high humidity, areas with high wind conditions, and heavy use, may require more frequent cleaning or maintenance.
  • Page 4 We strongly encourage that you read and understand the materials contained in the manual before using your heater. If you have any questions whatsoever regarding the safe assembly or use of your heater please call your Patio Comfort Dealer or Authorized Distributor or call us directly at 949-474-3070...
  • Page 5 THIS PAGE INTENTIONALLY LEFT BLANK...

  • Page 6: Table Of Contents

    Thank you Patio Comfort very much for purchasing a Patio heater. This manual contains very important information detailing the proper assembly, operation, and maintenance of this product. This product has been designed with the latest in safety technology but it is important to remember that this is a heating appliance and some of the surfaces are extremely hot to the touch and can cause bodily injury.

  • Page 7: Technical Data, Function Of Heater, Assembly Tips

    Fuel: LPG (Propane) Only burner system by turning valve control knob to “ON” Patio Comfort Heating: Each heater will cast a Setting.

  • Page 8: Parts Diagram And Part Descriptions (Heater Head)

    Outdoor Patio Heater Model PC-02 CAB Patio Comfort VINTAGE Parts Diagram and Repair Parts PART # Description 1001 03 M8 Wing nut 1001 M8 Hex nut 1002 8mm Flat Washer SS 1003 Reflector 1004 8mm Lock washer SS 1005# M8x20mm Hex Bolt...

  • Page 9: Parts Diagram (Base And Support)

    Outdoor Patio Heater Model PC-02 CAB Patio Comfort VINTAGE Parts Diagram and Repair Parts PART NUMBER DESCRIPTION QTY. 75041 Right Front Door Panel Bronze 75042 Left Front Door Panel Bronze 75043 L Bracket Bronze 1044 M6x12mm Hex Bolt 75046 Fuel Tube Feedline...

  • Page 10: Tools Required, Fastener Identification & Assembly Instructions

    14mm open-ended wrench or socket. Do not over- tighten. HEAD PACKED IN BASE ASSEMBLY Step 1 The majority of your Patio Comfort Vintage Outdoor Patio Heater product is already assembled, tested, and pre-fired for your safety and SOCKET ATTACHED TO TOP OF TANK ENCLOSURE convenience.
  • Page 11 purchased the optional utility table it needs to be placed on top of the threaded socket before securing the post. Step 5 Remove the plastic protective caps from the ends of the 3/8” flare fittings at each end of the solid feed line LP HOSE/REG TO FEEDLINE tube.

  • Page 12: Preparation For Use And Cylinder Information

    Your heater is now ready to be test fired. After purchasing a filled propane cylinder you will Please read our manual thoroughly and when be ready to install it into your Patio Comfort comfortable with the product and its features go to heating appliance.

  • Page 13: Placement Of The Heater & Clearances Required

    DO NOT USE the appliance. Call of the tank in a clock-wise direction and unscrew Patio Comfort the large black knob attached to the propane your authorized dealer and only regulator.

  • Page 14: Proper Lighting Instructions

    Before turning on the fuel supply at the tank visually inspect the hose assembly for evidence of excessive abrasion, cuts, cracking, or unusual wear and tear. If the hose leaks it must be replaced prior to using the Patio Comfort heater. Only use replacement hoses and other parts as specified by Before Lighting If attempting to relight a hot heater always wait at least five minutes.

  • Page 15: Relighting And Shut Down Instructions

    National Fuel Protection Agency Code 58-1986. Store your heater in an upright position in an area sheltered from inclement weather such as rain, snow, sleet, hail, dust storms, and other blowing debris. Patio Comfort makes a cover available to protect the burner head. We strongly recommend using our cover when your heater is in storage or not in use.

  • Page 16: Cleaning And Maintenance

    In a salt air or ocean environment, corrosion and rust occurs at a far greater rate than in non-ocean areas. You will need to more frequently check for corrosion and replace parts as required. The best protection for Patio Comfort the critical heater head is a cover that has been specifically designed for your heater.

  • Page 17: Trouble Shooting Guide

    TROUBLE SHOOTING GUIDE If you are having this problem: If this condition exists: You will need to do the following: Cylinder valve is closed Open valve at cylinder. Turn cylinder valve in counter-clockwise direction The pilot light won’t light Air in gas lines Purge air by holding control knob at “PILOT”...

  • Page 18: Detailed Warning And Safety Points

    Important Warnings and Safety Points!!! For Your Safety: If you smell gas: For Your Safety: 1. Shut off gas to appliance Do not store or use gasoline or Extinguish any open flame near other Flammable vapor and liquids the appliance. If odor continues in the vicinity of this or any other call gas supplier.
  • Page 19  Inspect heater before each use. If you find a damaged part, please replace the part with a genuine Patio Comfort part before using the appliance. ...

  • Page 20: Some Important Safety Tips On Propane And The Safe Use Of Propane

    Some tips on propane and the safe use of propane fuel  Propane (LP GAS) is a very safe fuel if used properly. Propane or liquefied petroleum gas is highly flammable, explosive under pressure, clean burning, heavier than air, and settles or puddles in low areas.
  • Page 21 This warranty is valid from the original date of purchase and is transferable. Please keep your original sales receipt or invoice. Proof of purchase is required to obtain warranty replacement. Patio Comfort retail dealers or distributors do NOT have the authority to modify, alter, or in any way change the product or the terms and conditions of this warranty.
  • Page 22 PURCHASER ASSUMES ALL RISK IN THE ASSEMBLY AND OPERATION OF THIS APPLAINCE. FAILURE TO FOLLOW THIS MANUAL’S WARNINGS AND INSTRUCTIONS CAN RESULT IN SEVERE PERSONAL INJURY, DEATH, OR PROPERTY DAMAGE Patio Comfort This warranty is for all heaters purchased and used in the 50 US states, The District of Columbia and Canada.

  • Page 23: Warranty Registration Form

    E-mail address (optional)___________________________________________ Thanks again for your purchase please mail this today so that we can activate your warranty information. Please mail to: AEI Corporation C/O Warranty Registration Department-Patio Comfort PO Box 16097 Irvine, California 92623-6097 Phone 949-474-3070 email aeicorp@sbcglobal.net Official Website:...
  • Page 24 The Vintage Series...
