Tenda Fast Ethernet 100Base-TX User Manual

This RSET8139.EXE setup program can configuration and
diagnostics PCI adapters. It is in the root directory of the
Driver Diskette that comes with the package. It is used to set
the PCI adapter's parameter, such as Operating mode, Media
type, Full-duplex, Boot ROM address and Wake On LAN
statrs, on board test...etc.
Run Rset8139.exe setup program. Insert the driver diskette
into floppy driver of the host PC. Then at the DOS prompt,
type the following and press Enter：
A:\>RSET8139 <Enter>
Boot ROM Installation
The optional BootRoM allows you to connect a workstation
Without disk driver to your network Ssystem.
Installation procedure
1.Plug the BootROM into the BootROM socket.
2.Run the RSET8139.EXE to change the configuration to
enable the BootROM at available address.
3.Refer to your Network Operating System installation
guide for detail.(Make image file)

If you need BootROM.please call your dealer for
assistance.When installing the BootROM into the socket.
Please make sure that the BootROM IC mark is in the same
direction as the other ICs on the adapter.Also,see to it that
all the IC legs are in the right holes of the Socket.
Supported Network Drivers
Novell Netware v3.12,4.0,5.0(included Client/Server
drivers)
Microsoft Windows NT V 3.5X,V4.0
 Microsoft Windows 95/95 OSR2/98
Microsoft windows 2000
Packet Drivers for FTP TCP/IP,NCSA TCP/IP
All products or brand names mentioned are trademarks or
registered trademarks of their respective companies.
Appendix
10Base-T Twisted-pair Cable
The RJ-45 connector used on 10Base-T Ethernet networks is
the 8-pin RJ-45 modular phone jack. The cable used is
0.4~0.6mm round-wire UTP or STP wire cable similar to
that used for ordinary telephone voice transmission.
Pin Number Assignment
1 Transmit Data(+)
2 Transmit Data(-)
3 Receive Data(+)
6 Receive Data(-)
4,5,.7,8 Received
10Base-T Phone Jack connector
®
Fast Ethernet 100Base-TX
PCI Adapter
User's Guide
