- Page 1 ENGLISH Full HD Video Wireless Kit USER’S MANUAL MV7500 Emitter MV7500 Receiver Please read the user manual and the quick installation guide so you can enjoy the product to the full extend.
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. IMPORTANT INFORMATION ............SAFETY PRECAUTIONS . -
Page 3: Important Information
1. Important Information Please take the time to read this user manual before using the Emitter MV7500 and Receiver MV7500. It contains important information about operating your Full HD video wireless kit. Danger: Be careful with electricity. Our limited warranty applies when the product is •... - Page 4 • MV7500 may interfere 5GHz wireless devices, rated current <16 A per phase and not subject to such as routers or other wireless devices.
- Page 5 • The following regulatory and Safety notices must be published in documentation supplied to the end user of the product or system incorporating CAUTION of RF module on US region an adapter in compliance with local regulations, Host system must be labeled with “Contains FCC ID: XXX-XXXXX”...
- Page 6 CAUTION of System on US region CAUTION of System on Canada region • Any changes or modifications not expressly • Industry Canada regulatory information Operation approved by the grantee of this device could void is subject to the following two conditions: the user’s authority to operate the equipment.
-
Page 7: Introduction
Please check whether the following items are present free of the constraint of cables. Just connect your in the package. If any items missed or damaged, HDTV to the Receiver MV7500 with an HDMI cable, please call your dealer and connect your AV equipment (Blu-ray players, HD... -
Page 8: Overview
HDTV your TV. also connected to the Emitter MV7500, or on a If you have more than one pair of MV7500, each 2nd HDTV possibly in a different room, once the transmitter and receiver should be at least 6.5 feet transmitter is paired successfully with receiver away from one another.. - Page 9 Generally, sensors with cable are placed near your HDTV set so that you can easily operate and control your AV equipment connected to Emitter MV7500 by pointing the remote control to the TV instead of the AV equipment.
- Page 10 C) Remote Controller Unit (RCU) Instruction Button Function Description Operation Press to turn the MV7500 Press it pointing at receiver Emitter / Receiver on/off. to enter “Standby” mode See the below Note 1 & 2. and the Loop-through When both of TX & RX connection is on;...
- Page 11 Note: 1. When the system is in active mode, press POWER key on the RCU pointing to transmitter or on the top of transmitter, then both the transmitter and the receiver will enter “Standby mode” (RF disconnected; LED lit in red) and Loop-through display and the 2nd display will be off. 2.
- Page 12 D) On Screen Display (OSD) vs. RCU Instruction Press the POWER button (1) Press the power button on the RCU to Transmitter or press the power button on the top of Transmitter to enter “Standby mode” from “active mode”. OSD Displayed: HDMI1 CH10 WIDE Off 1280x1024 Standby Mode, Loop-thru Off (2) Press the power button on the RCU to Receiver or press the power button on the top of Receiver to...
- Page 13 HDMI1 CH10 [WIDE On] 1280x1024 Press again to switch WIDE mode NOTE: Only the status of the Receiver MV7500 connected to the HDTV can be displayed on the OSD. The status of the Emitter MV7500 HDMI out cannot be displayed. - 13 -...
-
Page 14: Installation
(3) Connect the supplied power adapter to the DC IN jack of the Emitter MV7500 and a wall socket. The LED indicator in the POWER button lights up in solid purple when the Emitter MV7500 is connected to the power mains. - Page 15 High Def. Projector High Def. Flat-panel TV (1) Connect the HDMI cable to the HDMI OUT jack of the Receiver MV7500 and to your HDTV set (or an HD projector). Press the Source / Input button of your TV’s remote to select the appropriate “HDMI” video input.
- Page 16 AV equipment. (2) If the Receiver MV7500 will be out of the direct line of sight of your remote controls, plug the IR Sensor Extender cable into the IR IN jack at the rear panel of the Receiver MV7500 and place the IR sensor on the front of TV for operation.
- Page 17 (1) Place the two AAA batteries into the remote control. (2) After the power cord is plugged into the electrical outlet, the MV7500 will be turned on automatically. (3) If it is in Standby mode and Loop-thru. display off (Both POWER LED of transmitter and receiver are lit in red), press the POWER button on both transmitter and receiver to turn on the Emitter MV7500 and Receiver MV7500.
- Page 18 MV7500 and Receiver MV7500. Note: During this period, Emitter MV7500 will enter Standby mode and turn off Loop-thru. display when press the POWER button of transmitter or press the POWER key of RCU to transmitter. (5) During the warm-up, the POWER LED will blink in blue until the signal link between the Emitter MV7500 and the Receiver MV7500 is established.
- Page 19 (7) If you have electronic devices such as a cordless phone, wireless access point/ router sharing the 5GHz channel frequency, when you use it near the MV7500, you may experience disturbed picture or diminished sound quality. Press the CHANNEL button on the remote control to change the MV7500 to different channels.
- Page 20 B. Channel Number Indicating the Wireless Frequency: WIDE mode US (DFS) Europe (DFS) Japan (DFS) Support Support Support Frequency Channel Channel Channel Region Region Region (MHZ) 5.190 5.230 5.270 5.310 5.510 5.550 5.590 5.630 5.670 5.755 5.795 WIDE mode US (DFS) Europe (DFS) Japan (DFS) Support...
- Page 21 LED description. Note: A. Make sure your High-Definition audio/video devices connected to the Emitter MV7500 has already been powered on. B. Warming-up or source switching time should take approximately 20~30 seconds if the operation is in normal condition.
- Page 22 B. Please make sure the source player have been power on and switched the signal output to HDMI out; also re-plug the HDMI cable to make sure the HDMI connector had settled well. C. If there is no video displayed and OSD displayed “Not Supported Format”, this is an indication that the video frame rate from the source device is not supported, please refer chapter 5 to switch a supported video timing.
- Page 23 Only 1080i or below HD video transmission is available when enabling the “Wide” mode (OSD shows: WIDE On). Please shorten the distance and disable the “Wide” mode (OSD shows: WIDE Off) if full HD 1080p 60Hz content transmission is desired. Receiver MV7500 Emitter MV7500 - 23 -...
- Page 24 Step 6: Mounting the MV7500 to the Wall (1) Refer the drawing of the bottom page that have (5) Place MV7500 main holes over the protruding relative position of the main holes and attach this screws and slide down into position.
-
Page 25: Troubleshooting
• Verify that the proper cables have been selected and installed between the Emitter MV7500 input and your High-Defi nition device output. • On your TV side (connected to the Receiver MV7500), select the HDMI as input source. • Verify the POWER LED and SOURCE LED indicator of MV7500. - Page 26 No audio. • Ensure the bit rate of audio from the source device can be supported by MV7500. Please refer to the details in Chapter 6 Audio Bit Rate Support. • Check the HDMI output setting of Source device, set up HDMI output format to Auto mode instead of 1080p.
-
Page 27: Supported Resolution
5. Supported Resolution If the SOURCE LED continues to blink in blue (slower than “no signal” mode); OSD display: “No Supported Format ” and there is no video displayed or the video quality suffers, it indicates that the video frame rate from your A/V source device is not supported. -
Page 28: Audio Bit Rate Support
6. Audio Bit Rate Support • Digital Audio from HDMI inputs: Up to 6Mbit/s bit-rate support. • Support AC3 and DTS. • 2-channel PCM: 16~24 bits audio sample with 32~96KHz sampling rate as below: 2channel PCM 32 KHz 44,1 KHz 48 KHz 96 KHz 16 bits... -
Page 29: Product Specification
Operating Frequencies 4.9~ 5.9GHz (Include non-DFS and DFS Frequency Bands) Power Supply 100~ 240V AC in, 5V 3A DC out Power Adaptor Operating Temperature 0~40°C Interfaces Emitter MV7500 Receiver MV7500 HDMI Input TWO (Type A) A/V Interfaces HDMI Output -One (Loop-through) - Page 30 IB 03212 0699 Rev.0 - 30 -...
