Engel RC5320HD User Manual

Dtt+satellite hd receiver
Hide thumbs
Table of Contents

Advertisement

Quick Links

ENGLISH
DTT+SATELLITE HD RECEIVER
RC5320HD
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RC5320HD and is the answer not in the manual?

Questions and answers

Related Manuals for Engel RC5320HD

Summary of Contents for Engel RC5320HD

  • Page 1 ENGLISH DTT+SATELLITE HD RECEIVER RC5320HD USER MANUAL...

  • Page 2: Table Of Contents

    CONTENTS GENERAL INFORMATION Main Features For your Safety Unpacking General Operation Rear Panel INSTALLATION MENU INFORMATION Main Menu 1. Edit Channel 1.1 TV Channel List 1.2 Radio Channel List 1.3 Delete All 2. Installation 2.1 Antenna Connection 2.2 Satellite List 2.3 Antenna Setup 2.4 Single Satellite Search 2.5 Multi Satellite Search...
  • Page 3 CONTENTS 4. Tools 4.1 Information 4.2 Factory Setting 4.3 Common Interface 4.4 Conditional Access 4.5 Upgrade by USB 4.6 Media Player 4.7 Remove USB device safely 4.8 Network Local Setting 4.9 Upgrade by network 4.10 Network DDNS Setting 5. Game 6.
  • Page 4 GENERAL INFORMATION A Digital Satellite&Terrestrial Receiver is a convenient product that allows you to view a variety of programs provided through satellite or terrestrial antenna. This user’s guide covers the installation of the receiver and the necessary steps to implement various features. This also explains special features available only in this receiver in detail, which will allow you to make full of these feature.

  • Page 5: General Information

    GENERAL INFORMATION To avoid electric-shock hazards, do not open the Keep the receiver away from flower vases, tubs, cabinet, refer servicing to qualified personnel only. sinks, etc., in order to avoid damaging the equip- ment. Do not expose the receiver un-der the Do not block ventilation holes of the Receiver so sunlight.

  • Page 6: Unpacking

    GENERAL INFORMATION Unpacking Remote Control Batteries (not included) User Manual AV cable General Operation >Throughout this manual you will notice that the everyday operation of the receiver is based on a series of user friendly on screen display and menus. These menus will help you get the most from your receiver, guiding you through installation, channel organizing, viewing and many other functions.
  • Page 7 GENERAL INFORMATION Remote Control FUNCTION Turns power ON/OFF of the DSR When watching a channel, mute the sound MENU Enter number of the required item or select a channel number to watch TV-RADIO Switches between TV and Radio mode Switches back to previous channel Displays the orite group list FA V...

  • Page 8: Rear Panel

    INSTALLATION Rear Panel LNB IN: CONNECT TO SATELLITE ANTENNA LNB OUT:CONNECT TO THE OTHER RECEIVER CONNECT TO A DIGITAL AMPLIFIER CONNECT TO AUDIO R/L TO TV OR AUDIO TUNER CONNECT TO A PC FOR S/W UPGRADE CONNECT TO TV POWER ON/OFF USING A SCART CABLE CONNECT TO THE INTERNET...
  • Page 9 INSTALLATION Connecting to TV using SCART support Cable or OFF-Air Antenna Satellite Dish IN FROM ANT OUT TO ANT Terrestrial Antenna Connecting to Digital Amplifier Satellite Dish Terrestrial Antenna DIGITAL AUDIO CONVERTOR OR AMPLIFIER SPEAKER The picture is only for reference, please make the object as the standard...

  • Page 10: Menu Information

    MENU INFORMATION Main MENU Make sure that you have properly installed and connected the cables of the receiver . If the receiver is the factory status or there is no program list, when power on, the Main MENU window will be displayed on the screen.

  • Page 11: Tv Channel List

    MENU INFORMATION If there is no program, you can not EXIT from the Main MENU window by pressing MENU or EXIT key. System will inform “No channel” and the following items turn grey. Sub-MENU Turn grey when there’s no program Edit channel TV Channel List Radio Channel List...
  • Page 12 MENU INFORMATION 3. Press FAV key to move the FAV button upward. Select the pro- gram and press OK key to pop up the Favourite group list. In the list, select the group that you want to add into and press OK key, and then you will find the Favourite mark is displayed at the right side of the selected program.
  • Page 13 MENU INFORMATION i . Sort (red colour key) Press red colour key to pop up the Sort drop-down list. Name(A-Z): The ascending order, omitting the $ character, the number is ahead, then the capital letter, at last the lowercase. Name (Z-A): The opposite order of the above Name (A-Z). Free/Scramble: All FTA programs are listed ahead, while all scrambled programs are listed last.

  • Page 14: Radio Channel List

    MENU INFORMATION iii. Delete (blue colour key) In Delete window, press blue colour key to move the Delete button upward. Select the program and press OK key to mark this program with the deletion mark. You can cancel this mark by pressing OK key again.

  • Page 15: Satellite List

    MENU INFORMATION 2.2 Satellite List 1. Press PR+, PR- keys to select the satellite up or down. Press OK key to select and mark, and you can press OK key again to cancel the selection and the mark. 2. If there is no satellite, the red colour and blue colour keys will be invalid.

  • Page 16: Antenna Setup

    MENU INFORMATION 2.3 Antenna Setup Part A: Fixed Suppose that you have selected Fixed Antenna in the Antenna Connection window. 1. Satellite: All selected satellites in the satellite list are displayed in this item. Press keys to select the satellite in circle. Or press OK key to pop up the drop-down list, then select the desired satellite in the list and press OK key to confirm.
  • Page 17 MENU INFORMATION Position No., & Save: The range is from 0 to 63. “0” delegates the original position. You can select the proper value when you has rotated the antenna. Go to X: Press OK key to pop up the drop-down list, select the proper position (reference or from 1to 63) to realize the selected position.

  • Page 18: Single Satellite Search

    MENU INFORMATION 2.4 Single Satellite Search 1. Satellite : Press keys to select the satellite in circle. Or press OK key to pop up the drop-down list, then select the desired satellite in the list and press OK key to confirm. 2.

  • Page 19: Tp List

    MENU INFORMATION 2.6 TP List 1. Press PR+,PR- keys to select the proper satellite 2. Press red colour key to pop up the Edit TP window. Frequency, Symbol rate: Press keys to add or reduce by step one. Or press numeric keys (0-9) to input the desired value.

  • Page 20: Terrestrial Automatic Scan

    MENU INFORMATION 2.7 Terrestrial Automatic Scan 1. Area: Select the area. 2. FTA Only: Select between YES and No. 3. LCN: Select between ON/OFF 4. Search: Press OK key to start searching. 2.8 Terrestrial Manual Scan When you enter Manual Search, the screen will display as beside. There are two scan modes for you.

  • Page 21: Tv System

    MENU INFORMATION 3.2 TV System Press PR+, PR- key to move the cursor up or down, while press keys to change the setting and the setting will take effect immediately. 1. Video Resolution: Select among 480i, 576i, 480p,576p, 720p and 1080i. 2.

  • Page 22: Timer Setting

    MENU INFORMATION 3.5 Timer Setting If there is no program, you can not enter into this window. The- re are 8 timers that can be set. Select Timer up or down, and press OK key to enter into the setting window. 1.

  • Page 23: Osd Setting

    MENU INFORMATION 3.7 OSD Setting 1. OSD Timeout: Press keys toselect from 1 to 10 by step1. The default values Is 5. 2. OSD Transparency: Press keys to select among Off, 10%, 20%, 30%, 40%. The default option is Off. Press MENU or EXIT key to save and EXIT.

  • Page 24: Factory Setting

    MENU INFORMATION 4.2 Factory Setting Press OK key to enter into the Factory Setting window. Select Yes button and press OK key to return to the factory set- ting. All searched channels and set information will be erased. Select No button and press OK key to cancel this operation, or press MENU or EXIT key to cancel and EXIT.
  • Page 25 MENU INFORMATION Change CA PIN Changes CA PIN window is designed for changing the smart card’s PIN, which is required if you want chan- ge the maturity level settings. In order to change the PIN, you must know the current PIN also called the old PIN. Input the new PIN and twice the PIN (New PIN and Confirm PIN must be the same) your want to set.

  • Page 26: Conditional Access

    MENU INFORMATION Loader Status You can select allow download or forbid download. 4.4 Conditional Access Insert the smart card with the golden chip facing up. Push the smart card into the CA slot. Only a few millimetres of the card should be visible outside the slot.

  • Page 27: Upgrade By Usb

    MENU INFORMATION 4.4.4 Maturity Level Input the PIN then Move cursor to Select Maturity level,you can select A-Over18, X-Erotic, G-General audience,PG-Parental Guidance,move cursor to Change Maturity level button and press OK key,and then system will pop up a dialogue informing you the changing result. 4.4.5 Subscription Status Know the detail information of Subscription Status.
  • Page 28 MENU INFORMATION Color key operation: 1.Green key: Press green key to add the Favorite symbol on your selected files, and put the file selected by scroll bar to play list . 2.Yellow Key: Press yellow key to add all the image and music files to the play list . 3.Red Key: Show the Play List.

  • Page 29: Remove Usb Device Safely

    MENU INFORMATION 4.7 Remove USB device safely Press OK on this item it will pop up a dialogue:”You can safely re- move USB device now! “, then you can move your USB device safely. 4.8 Network Local Setting HDCP: Select between ON and OFF, when it ON, the IP Address, Sub- net Mask and Gateway item will turn gray, you can not edit them.

  • Page 30: Rec

    MENU INFORMATION 6. REC 6.1 Storage Information Show you the information in windows as besides. 6.2 DVR Configuration 1.Time shift: Select between Off and On. 2. Timeshift to Record: Select between On and Off. 3. Jump: Select among 30 sec, 1 min, 5 min, 10min and 30 min.

  • Page 31: Find

    MENU INFORMATION 7.2 Find Press FIND key on to pop up the Find window. Use numeric keys to enter into the character and use the co- lour keys to realized the corresponding operation. 7.3 Number Use the numeric keys (0-9) to input the number of the desired channel.

  • Page 32: Audio

    MENU INFORMATION 7.10 Audio 1. Press keys to enter into the Audio window. 2. Press keys to select among Left, Right, Stereo, and Mono. 3. Changing the audio mode is only connected with the cu- rrent channel, not all the channels. 4.

  • Page 33: Troubleshooting

    TROUBLESHOOTING Problem Possible causes What to do The display on the front panel Main cable is not connected Chack that the main cable is does not light up plugged into the power socket No sound or picture, but the The receiver is in standby mode Press the standby button front panel shows red light No sound or picture.
