Page 1: Operation Manual
VividImage ® Medical Grade High Definition Wide Screen Monitor OPERATION MANUAL MON-VTS42SDI-MD MON-VTS42SDI-MT MON-VTS52SDI-MD MON-VTS52SDI-MT MON-VTS42SDI-MD Document # 82070-639, Revision C CONFIDENTIAL © 2009 Copyright VTS Medical Systems, LLC 1 of 29... -
Page 2: Notice For Users
MON-VTS42SDI-MD / MON-VTS42SDI-MT / MON-VTS52SDI-MD / MON-VTS52SDI-MT: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 3: Table Of Contents
Table 7: Advanced Menu Functions ........................15 Table 8: OSD Menu Settings Functions ......................16 Setup menu ................................17 Table 9: Setup Menu Functions .......................... 17 Document # 82070-637, Revision C CONFIDENTIAL © 2009 Copyright VTS Medical Systems, LLC 3 of 29... - Page 4 Monitor Care / Troubleshooting ..........................25 Monitor Care ................................25 Troubleshooting ..............................25 Specifications ................................26 Table 11: Specifications ............................26 Glossary ..................................27 Index .................................... 28 Document # 82070-637, Revision C CONFIDENTIAL © 2009 Copyright VTS Medical Systems, LLC 4 of 29...
-
Page 5: Tips And Safety Precautions
For product appearance, illustrations of model MON-VTS42HD-MD are used in this manual.) Document # 82070-637, Revision C CONFIDENTIAL © 2009 Copyright VTS Medical Systems, LLC 5 of 29... -
Page 6: Connecting And Powering On The Monitor
1 S-Video Cable 1 Power Cord 1 Remote Control Figure 1: Included Cables If any one of these items is missing, please call VTS Customer Support at (877) VTS-1788. Document # 82070-637, Revision C CONFIDENTIAL © 2009 Copyright VTS Medical Systems, LLC... -
Page 7: Mounting The Monitor
BNC Connector (x8) RS-232 control (IN/OUT) D-Sub 9 pin USB Touch control( MON-VTS42SDI-MT / MON-VTS52SDI-MT only) USB-A RS-232 Serial Touch control (MON-VTS42SDI-MT / MON-VTS52SDI-MT only) D-Sub 9 pin AC Switch / Power cord input AC Power Input Table 1: Inputs and Connections... -
Page 8: Figure 4: Vividimage Monitor Rear View
Figure 4: VividImage Monitor Rear View Configuring Touch Capability MON-VTS42SDI-MT and MON-VTS52SDI-MT touch enabled monitors come preconfigured for use as a touch panel. To use the touch capability, a connection to the RS232 Touch Control port or USB Touch port must be made to the system you wish to control with the touch panel. -
Page 9: Control Devices
Enter OSD (On Screen Display) Menu / MENU Exit OSD Menu or Select Figure 5: The Side Control Panel, Table 2: Side Control Functions Document # 82070-637, Revision C CONFIDENTIAL © 2009 Copyright VTS Medical Systems, LLC 9 of 29... -
Page 10: Remote Control
Push down and pull out battery compartment. Insert one new 3V lithium battery. Make sure the polarity ( + / -) of the battery is correct. Close battery compartment. Document # 82070-637, Revision C CONFIDENTIAL © 2009 Copyright VTS Medical Systems, LLC 10 of 29... -
Page 11: On Screen Display (Osd)
To exit the OSD menu or return to the previous selection, press M Color Menu Advanced Menu Image Menu OSD Menu Display Menu Setup Menu Sub-menu Items Figure 8: OSD Menu Layout Document # 82070-637, Revision C CONFIDENTIAL © 2009 Copyright VTS Medical Systems, LLC 11 of 29... -
Page 12: Details Of Osd Menu Functions
HD-SDI source is selected. Note: Some menu items may not be displayed if the selected input does not support that function. Table 4: Display Menu Functions Document # 82070-637, Revision C CONFIDENTIAL © 2009 Copyright VTS Medical Systems, LLC 12 of 29... -
Page 13: Image Menu
Move the image up or down. The default setting is 49. Note: Some menu items may not be displayed if the selected input does not support that function. Table 5: Image Menu Functions Document # 82070-637, Revision C CONFIDENTIAL © 2009 Copyright VTS Medical Systems, LLC 13 of 29... -
Page 14: Color Menu
27 for more information. Note: Some menu items may not be displayed if the selected input does not support that function. Table 6: Color Menu Functions Document # 82070-637, Revision C CONFIDENTIAL © 2009 Copyright VTS Medical Systems, LLC 14 of 29... -
Page 15: Advanced Menu
Set the display to automatically power off if there is no signal input for Sleep Mode 8 seconds. Upon signal input, the display powers on again. Table 7: Advanced Menu Functions Document # 82070-637, Revision C CONFIDENTIAL © 2009 Copyright VTS Medical Systems, LLC 15 of 29... -
Page 16: Table 8: Osd Menu Settings Functions
Choose language to be used in screen menus. (Select ions are: English, Language Chinese, French, German, Italian, Spanish). The default is English. Table 8: OSD Menu Settings Functions Document # 82070-637, Revision C CONFIDENTIAL © 2009 Copyright VTS Medical Systems, LLC 16 of 29... -
Page 17: Setup Menu
The ID function is intended to be used with third party RS-232 control hardware and software. Table 9: Setup Menu Functions Document # 82070-637, Revision C CONFIDENTIAL © 2009 Copyright VTS Medical Systems, LLC 17 of 29... -
Page 18: Locking The Osd
Select Setup Menu. Figure 9: Setup Menu Press to select the sub-menu items. Select L and press E NTER Figure 10: Setup Menu, Lock Mode Selected Document # 82070-637, Revision C CONFIDENTIAL © 2009 Copyright VTS Medical Systems, LLC 18 of 29... -
Page 19: Figure 11: Setup Menu, Lock Mode Selections
OSD menu. • When Lock Mode is set to O , pressing Menu causes the following menu to appear: Figure 12: Display Menu Document # 82070-637, Revision C CONFIDENTIAL © 2009 Copyright VTS Medical Systems, LLC 19 of 29... -
Page 20: Figure 13: Brightness Function Selections
Note: If you temporarily override the Mode 1 or Mode 2 Lock setting as detailed in the section above, it will relock after 15 minutes. To maintain an unlock status, set the Lock Mode to Off. Document # 82070-637, Revision C CONFIDENTIAL © 2009 Copyright VTS Medical Systems, LLC 20 of 29... -
Page 21: Adjusting Monitor Settings With Hot Key Controls
• Component: Acquire analog signal from the Y/Cb/Cr input. • HD-SDI 1: Acquire digital signal from the HD-SDI input. (Option) • HD-SDI 2: Acquire digital signal from the HD-SDI input. (Option) Document # 82070-637, Revision C CONFIDENTIAL © 2009 Copyright VTS Medical Systems, LLC 21 of 29... -
Page 22: Mode Item Selection
• Gamma 2.2: 2.2 gamma value. • Gamma 1.8: 1.8 gamma value. • DICOM: DICOM standard. • Gamma 2.0: 2.0 gamma value. • User: Manually set a gamma value. Document # 82070-637, Revision C CONFIDENTIAL © 2009 Copyright VTS Medical Systems, LLC 22 of 29... -
Page 23: Using Picture In Picture (Pip) And Picture And Picture (Pap) Modes
To display two signals in PAP (Picture And Picture) mode, press PIP again. To return to full screen viewing of the main image source last selected before entering PAP mode, select PIP a third time. Document # 82070-639, Revision C CONFIDENTIAL © 2009 Copyright VTS Medical Systems, LLC 23 of 29... -
Page 24: Primary Source And Secondary Source Selection
● ● HD-SDI 2 Key: ● PIP function enabled — PIP function disabled Table 10: PIP and PIP Function Availability for Signal Type Combinations Document # 82070-639, Revision C CONFIDENTIAL © 2009 Copyright VTS Medical Systems, LLC 24 of 29... -
Page 25: Monitor Care / Troubleshooting
- If using a camera as the video source, perform a “White Balance” and check the “Iris Control” on the camera (see camera’s operating manual for instructions), if applicable. Document # 82070-639, Revision C CONFIDENTIAL © 2009 Copyright VTS Medical Systems, LLC 25 of 29... -
Page 26: Specifications
350 Watts max Power Requirements 230 Watts max 350 Watts max Table 11: Specifications Two (2) total ports for both or either SDI and/or HD-SDI Document # 82070-639, Revision C CONFIDENTIAL © 2009 Copyright VTS Medical Systems, LLC 26 of 29... -
Page 27: Glossary
100% Red saturation is 100% Red, 0% Green and 0% Blue. No saturation means all the color percentages are equal. Changes in saturation will change the emphasis of the selected color component. Document # 82070-639, Revision C CONFIDENTIAL © 2009 Copyright VTS Medical Systems, LLC 27 of 29... -
Page 28: Index
Horizontal Position, 13 Hue, 12, 27 Unpacking, 6 LED On/Off, 15 Vertical Position, 13 Video Inputs, 7 Monitor Care, 25 Mounting, 7 Zoom, 15 Document # 82070-639, Revision C CONFIDENTIAL © 2009 Copyright VTS Medical Systems, LLC 28 of 29... - Page 29 Contact VTS Customer Support 40 Melville Park Road Melville, NY 11747 (877) VTS-1788 ® VividImage is a registered trademark of VTS Medical Systems, LLC Document # 82070-639, Revision C CONFIDENTIAL © 2009 Copyright VTS Medical Systems, LLC 29 of 29...
