- Page 1 ® VividImage LCD Surgical Grade Monitor High Definition OPERATION MANUAL MON-VTS19HD MON-VTS19HDT MON-VTS21HD MON-VTS24HD MON-VTS19HD(M) MON-VTS19HDT(M) MON-VTS21HD(M) MON-VTS24HD(M) MON-VTS24HD Wide Screen...
-
Page 2: Notice For Users
Medical Grade Monitor- VividImage MON-VTS19HD (M) / MON-VTS19HDT (M) / MON-VTS21HD (M) / MON-VTS24HD (M): This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 3: Table Of Contents
Monitor Care ................................... 15 Storage ................................... 15 Troubleshooting ................................15 SPECIFICATIONS ............................16 Table 2: Specifications ............................. 16 GLOSSARY ..............................17 INDEX ................................19 CONTACT VTS MEDICAL SYSTEMS ......................20 Document # Revision Date 3 of 20 82070-244, Revision D 1/14/2009... -
Page 4: Tips And Safety Precautions
Tips and safety precautions - Do not display a still image for ten (10) or more Location hours. An afterimage may remain. - Use the monitor in a suitable environment. See - It may be difficult to see the image on the screen “Operating Temperature”... -
Page 5: Connecting The Monitor And Turning On/Off
Connecting the monitor and turning on/off Step 1: Unpacking the carton Included in the carton are the following items: ® 1 VividImage HD Monitor 1 Cable Cover (screwed onto the back of the monitor) 1 Power Cord 1 Power Supply 8 Mounting Screws (screwed into the back of the monitor) 1 Quick Start Guide 1 Operation Manual (this document) -
Page 6: Figure 2: Sample Video Source Connections And Power Plug
VESA Mounting Holes 19” & 21” 24” ® Figure 1: VividImage Monitor Rear View with VESA Mounting Holes 19” & 21”, and 24”. (shown without cable cover) Figure 2: Sample Video Source Connections and Power Plug Document # Revision Date 6 of 20 82070-244, Revision D 1/14/2009... -
Page 7: User Interface
User Interface Note about Monitors with Touch Screen Capability ® VividImage monitors with a touch screen interface (Model # MON-VTS19HDT) allow the user to activate a control and adjust settings by touching the On Screen Display menus. All menus function in the same way as monitors without the touch screen capability. -
Page 8: Osd (On Screen Display)
OSD (On Screen Display) Main Menu Pressing the “MENU / SELECT” button displays the first in a series of menus along with the menu’s associated picture icon. To move to the desired submenus that are available for each menu function, press the “+”... -
Page 9: System Menu
Component Type- (RGBS/YPbPrS and RGB/YPbPr only) allows switching the component type between RGBS and YPbPrS (YUV). Colors will distort if RGBS mode is chosen and signal type is YPbPrS and if YPbPrS mode is chosen and signal type is RGBS. Red, Green &... -
Page 10: Default Settings
Default Settings VTS Model Number MON-VTS19HD(T) MON-VTS21HD MON-VTS24HD Setting MON-VTS19HD(M) MON-VTS21HD(M) MON-VTS24HD(M) Brightness Contrast Geometry Left Edge Right Edge 1280 1600 1920 Top Edge Bottom Edge 1024 1200 1200 Changes upon Changes upon Changes upon Clock signal selection signal selection... -
Page 11: Osd Navigation
OSD Navigation Main Menu Brightness Contrast Geometry Color System Auto Setup Exit Brightness Contrast Left Edge Color Escape Adjustment Adjustment Back Back Right Edge Contrast Save Black Level Top Edge Reset Bottom Edge OSD Timeout Clock Color Temperature OSD X Position Phase Component Type OSD Y Position... -
Page 12: Examples Of Osd Menus
Note: Figure 4 shows the On Screen Display menu navigation options when a video signal is selected. The menus are the same for any signal selected except where noted in Figure 4. Some menu options have three levels. For example; “Geometry” from the main menu (level 1), then “Left Edge” from the Geometry submenu (level 2), then “Left Edge Adjustment”... - Page 13 Color Submenu Color Submenu Options Document # Revision Date 13 of 20 82070-244, Revision D 1/14/2009...
-
Page 14: Figure 5: Osd Screen Display Examples
System Submenu System Submenu Options Component Format Search Submenus Figure 5: OSD Screen Display Examples Note: Depending upon the signal type that is chosen, you may see additional OSD menu options other than those shown in the examples in Figure 5. There may also be fewer menu options than those shown if an option is not applicable to a particular signal. -
Page 15: Monitor Care / Troubleshooting
Monitor Care / Troubleshooting Monitor Care Storage If the monitor will not be used for a long period LCD Panel of time, be sure to remove the power plug from ® VividImage monitors feature an optical quality the AC outlet (if accessible). Store in its original acrylic panel specially coated for superior anti- carton if available. -
Page 16: Specifications
Medical Grade, Extra Long 15ft. (4.57m) Power Supply Cable Power Supply 60 Watts max, 150 Watts max (24” Monitor) Power Requirements *RGB port is not available on the MON-VTS19HDT (Touch Screen Monitor). It is available on MON-VTS19HD(M). Table 2: Specifications Document # Revision Date... -
Page 17: Glossary
Glossary Bias (Red, Green, Blue): Increasing the bias of a color increases the proportion of that color in the image. The level of the selected color is varied equally for all proportions. For example: Color Number 1 Proportions Bias Increase New Color Proportions Red = 20% Red = 20% + 5% = 25%... - Page 18 Notice that the increase in the color proportion of the Red is greater for greater original color proportions of Red. Lighter reds are increased a lesser amount than darker reds as gain is increased. Hue: Hue refers to the “shade” of the colors. Adjustment of this feature is applicable primarily to analog signal sources.
-
Page 19: Index
Index Auto Setup, 9 Main Menu, 8 Monitor Care, 15 Mounting, 5 Brightness, 7, 8 On Screen Display, 8 OSD, 8, 15 OSD Navigation, 11 Cable Cover, 5 OSD X, 9 Care, 15 OSD Y, 9 Checklist, 4 Color, 8 Component, 9 Connecting, 5 Contact VTS, 20... -
Page 20: Contact Vts Medical Systems
Contact VTS Medical Systems VTS Medical Systems, LLC 40 Melville Park Road Melville, NY 11747 (877) VTS-1788 www.vtsmedical.com ® and VividImage are registered trademarks of VTS Medical Systems, LLC. Printed in USA Document # Revision Date 20 of 20 82070-244, Revision D 1/14/2009...
