Instruction Manual
Electronic Pulse Massager
■ Thank you for purchasing the OMRON Electronic Pulse
Massager HV-F127.
■ Please read this Instruction Manual thoroughly before using
this unit for the safe and correct use of it.
■ Please keep this Instruction Manual always at hand for your
future reference.
HV-F127-AP_C_M07_130218.pdf
HV-F127
Notes on Safety ...............................1
Features of the Product ..................3
Components of the Product ............3
Low-Frequency Therapy ...............4
of the Parts ...................................5
How to Insert the Batteries .............7
How to Attach the Pad ....................9
Examples of Application ................10
How to Treat ..................................11
Region Button ..........................14
Massage Button.......................15
Maintenance
When it is Difficult to Attach
the Pad ........................................17
How to Clean and Store the Unit .......18
Troubleshooting .............................19
Specifications ................................20
CONTENTS
Advertisement
Table of Contents
Related Manuals for Omron HV-F127
Summary of Contents for Omron HV-F127
-
Page 1: Table Of Contents
Treat the region with the Region Button ......14 Treat the region with the Massage Button.......15 ■ Thank you for purchasing the OMRON Electronic Pulse After Treatment –Storing the unit ..16 Massager HV-F127. ■ Please read this Instruction Manual thoroughly before using Maintenance this unit for the safe and correct use of it. -
Page 2: Before Using The Unit Notes On Safety
Before Using the Unit Notes on Safety (Please read this section carefully before using the unit.) ● The icons and warning signs are indicated here for your safe and correct use of the product as well as to prevent injuries and/or damage to properties. ●... -
Page 3: Notes On Safety
Notes on Safety CAUTION If the unit is not functioning properly or you feel discomfort, immediately stop using the unit. If you feel any trouble with your body or skin, consult the doctor and follow his/her instructions. If you want to move the Electrode Pad to another region or your body during treatment, be sure to turn off the power. -
Page 4: Features Of The Product
* Washable and long-lasting Long-Life Pads Components of the Product The following components are included in the box. If any components are missing, please contact the nearest OMRON dealer. 5. Electrode Holder 1. Main unit 2. Type K Electrode Cord Note: This is a consumable. -
Page 5: Information On High & Low-Frequency Therapy
100 stimulation in a second = 100 Hz Standard treatment time Long-time treatment and strong stimulation cause muscular fatigue and generate adverse effects. In order to avoid the excessive treatment, Electronic Pulse Massager, model HV-F127 is made to turn off the power automatically in 15 minutes. -
Page 6: Names And Functions Of The Parts
Names and Functions of the Parts Electrode Cord Main Unit Connects the Main unit with the Pad Electrode Cord Plug Intensity Adjustment/ Power Dial Switch Electrode Turns on and off the power Cord Jack and adjusts the intensity of stimulation. INTENSITY /POWER RELIEVE... - Page 7 Electrode Cord Plug Attach the red or the white plug to each Pad. Tab of the Pad Hold the Tab to peel off Attach each Pad to the region the Pad. you want to treat. Point & Wide Mode The unit treats the red and the white sides alternately. POINT WIDE The unit treats both the red and white sides simultaneously.
-
Page 8: How To Use
OOOOOO 4. Close the battery cover. General advice from OMRON on the handling of batteries • The supplied batteries are for the trial use only and may wear out in less than three months. • Replace the worn batteries with new ones immediately. -
Page 9: How To Connect The Electrode Cord
❇ Although Electrode Cord Plugs are provided in red and white, either plug can be connected with one of the Pads irrespective of color. General advice from OMRON on the handling of Electrode Cord • Avoid excessive bending and pulling of the Electrode Cord. -
Page 10: How To Attach The Pad
Attach the Pad close to the skin. ❇ If the Pad comes off from the skin, the unit is turned off automatically in approximately 7 seconds. General Advice from OMRON on the handling of Pad • Do not place pads one on top of the other. -
Page 11: Examples Of Application
Examples of Application... -
Page 12: How To Treat
How to Treat This section explains the treatment procedure and the entire operation flow from turning on the power to storing of the unit. Three treatment methods are available. Select your favourite one to receive treatment. – Treat with the Relieve Button When you want to relieve pain. - Page 13 3. Adjust the intensity of stimulation. Select your favorite intensity level from 1 to 10 by rotating the Intensity Adjustment/Power Dial Switch. INTENSITY /POWER RELIEVE SOLE Standard for treatment WAIST SHLDR REGION Duration: 10 to 15 minutes per region for each time KNEAD PUSH MASSAGE...
-
Page 14: Treat The Region With The Relieve Button
How to Treat Treat the region by selecting one course from Relieve, Region, and Massage. Treat the region with the Button RELIEVE When you want to relieve pain 1. Push the Relieve Button. This is a program using high-frequency stimulation of 1200 Hz, which INTENSITY /POWER is said to relieve pain. -
Page 15: Treat The Region With The Region Button
Treat the region with the Button REGION When you want to treat the selected region of shoulder, sole, leg (calf), and waist (lower back) to which the Pads are attached with the program 1. Push the Region Button. Each time you push the Region Button, the display flashes in the INTENSITY /POWER order of Shoulder, Sole, Leg (calf), and Waist (lower back). -
Page 16: Treat The Region With The
How to Treat Treat the region by selecting one course from Relieve, Region, and Massage. Treat the region with the Button MASSAGE When you want to treat the region according to your symptom and favourite operation by selecting the massage method from Tapping, Kneading, Pushing, and Rubbing 1. -
Page 17: After Treatment -Storing The Unit
After Treatment – Storing the unit If you leave the Pads without taking care of them, they will become dirty or the adhesive property will drop. When the treatment ends, attach the Pads to the Electrode Holder and store them. 1. -
Page 18: When It Is Difficult To Attach The Pad
4. Lightly attach the Pad to the Electrode Holder for storage. (Refer to Page 16.) General advice from OMRON on the handling of Pads • Do not use hot water, detergent, or chemicals such as thinner or benzine. • Do not scratch the adhesive surface with your nail or a brush. -
Page 19: How To Clean And Store The Unit
• If you are not going to use the unit for a long time of more than three months, store the unit after removing the batteries. ❇ If you do not observe the above-mentioned notes or correct use of the unit, OMRON cannot take responsibility on quality of the unit. -
Page 20: Troubleshooting
⇒ Pad is a consumable. ■ The adhesive surface of Pad is damaged. Replace the Pad with a new one. (Refer to page 20) ❇ If the unit does not operate after taking the above-mentioned measures, contact the nearest OMRON dealer. -
Page 21: Specifications
= Read the instruction manual carefully This product should not be used by persons with medical implants, e.g. heart pacemakers, artificial heart, lung or other electronic life support systems. This OMRON product is produced under the strict quality system of OMRON HEALTHCARE Co. Ltd., Japan. - Page 22 OMRON HEALTHCARE Co., Ltd. 53, Kunotsubo, Terado-cho, Muko, Kyoto 617-0002 JAPAN OMRON HEALTHCARE SINGAPORE PTE LTD. 438A Alexandra Road, #05-05/08, Asia Pacific HQ Alexandra Technopark, Singapore 119967 www.omron-healthcare.com.sg OMRON (DALIAN) CO., LTD. Production Facility Dalian, China...
