SERVICE MANUAL
CONTENTS
LED ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
PRE AMPLIFIER ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4
POWER AMPLIFIER ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-7
SMPS ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-8
PACKING ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
POWER CORD ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
CASING ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
CASING LED ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-10
CASING PRE AMP ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
CASING POWER AMP ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
CASING SMPS ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11-12
SPEAKER ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12-13
BLOCK DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
SCHEMATIC DIAGRAMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15-18
PCB LAYOUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19-21
EXPLODED VIEW DIAGRAMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22-24
POWERED SUBWOOFER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PSW 3000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for KEF PSW 3000

Summary of Contents for KEF PSW 3000

  • Page 1: Table Of Contents

    SERVICE MANUAL POWERED SUBWOOFER CONTENTS PARTS LIST: LED ASSEMBLY ..............2 PRE AMPLIFIER ASSEMBLY .

  • Page 2: Parts List

    POWERED SUBWOOFER PARTS LIST LED ASSEMBLY QTY PART NO DESCRIPTION LOCATION 1681-1000-A UL1007 AWG#20 BLACK L=310MM RF101 3700-4536-RG L-115W EGW/209EGW RED/GR LED301 3700-9528-0 LED DISP LR2x5-10B-YYB LED302 4860-8710-5 TR 9012H Q307,310 4860-8720-5 TR 9013H SAMSUNG Q301, 302, 303, 304, 305, 306, 308, 309 157C-107M-5-IU CE 10V 100µF...
  • Page 3 POWERED SUBWOOFER PARTS LIST PRE AMP ASSEMBLY CONTINUED QTY PART NO DESCRIPTION LOCATION 157D-477M-5-OVK CE 16V 470µF 20% RL 157E-106M-5-IU CE 25V 10µF 20% RL 5x11 157F-225M-5-IU CE 50V 2.2µF 20% RL 5x11 C1, 3, 7, 11, 13, 35, 150, 151,152,153,154,155,156 15CG-470J-7-IJ CTC 0/30 47pF...
  • Page 4 POWERED SUBWOOFER PARTS LIST PRE AMP ASSEMBLY CONTINUED QTY PART NO DESCRIPTION LOCATION 4701-104J-2 RCF 1/8W 100K 5% AT R4, 16, 50, 52, 54, 55, 68, 91, 93, 126, 154, 157 4701-105J-2 RCF 1/8W 1M 5% AT R135, 140, 141, 143, 144, 146, 147, 149, 150, 153, 156, 158, 159 4701-123J-2...

  • Page 5: Power Amplifier Assembly

    POWERED SUBWOOFER PARTS LIST POWER AMP ASSEMBLY QTY PART NO DESCRIPTION LOCATION 150F-101K-5-IEA CC 50V 100pF 10% RL 5X3 C204,222,224,226 150F-104M-N-FD CC 50V 0.1µF 20% RLF C205, 207, 227, 252, 503, 150F-470K-5-IEA CC 50V 47pF 10% RL 5X3 C225 150F-471K-5-IEA CC 50V 470pF 10% RL 5x3 C202,217...
  • Page 6 POWERED SUBWOOFER PARTS LIST POWER AMP ASSEMBLY CONTINUED QTY PART NO DESCRIPTION LOCATION 4860-8470-0 TR TIP41C SGS Q203,207 4860-8720-5 TR 9013H SAMSUNG Q202 4860-8890-0 TR MPS A06 VCE 80V NS Q205,206 4860-8910-0 TR MPS A56 VCE 80V NS Q204,213 8910-0115-0 CE 4700UF 63V 20% RL C210,212 8910-0196-0...

  • Page 7: Smps Assembly

    POWERED SUBWOOFER PARTS LIST POWER AMP ASSEMBLY CONTINUED QTY PART NO DESCRIPTION LOCATION 2954-2606-0000 SCREW BT 2.6X6 U501,502 2954-3008-3000 T3X8MM SELF TAPPING U501,502 3130-2520-2 IC 7812H 12V REG, T0220F U502 3130-3800-0 IC UPC79M12HF REGULATOR U501,502 5400-9130-0 HEAT SINK FOR 7805 2438- U501,502 SMPS ASSEMBLY QTY PART NO...

  • Page 8: Smps Assembly

    POWERED SUBWOOFER PARTS LIST SMPS ASSEMBLY CONTINUED QTY PART NO DESCRIPTION LOCATION 4154-0841-0 INSULATION BUSHING D8-D11 4154-0841-0 INSULATION BUSHING Q1-Q4 4705-103J-2 RCF 1/4W 10K 5% AT R24,26 4705-472J-2 RCF 1/4W 4.7K 5% AT 4719-101J-C-X RMF 2W 100R 5% ATS METAL 4719-470J-C-X RMF 2W 47R 5% ATS METAL...

  • Page 9: Packing Assembly

    POWERED SUBWOOFER PARTS LIST PACKING ASSEMBLY QTY PART NO DESCRIPTION LOCATION 1497-1932-0 POLYBAG 04x5x9" w/PE-LD REMOTE 2150-7001-0 NAME PLATE RF REMOTE REMOTE 4060-0530-0 GREENCELL 3A SIZE GP24G2 PACKING 4153-7941-0 K100081B BLANKING PIN BK SPK- 4153-7951-0 K100081J BLANKINGPIN RED SPK+ 8912-0002-1 RF REMOTE DUAL CHANNAL PACKING POWER CORD ASSEBLY...

  • Page 10: Casing Led Assembly

    POWERED SUBWOOFER PARTS LIST CASING LED ASSEMBLY CONTINUED QTY PART NO DESCRIPTION LOCATION 7011-9360-0 UL1007 AWG#26 RAINBOW CN301 8912-0003-0 RF RECEIVER MODULE DUAL RF101 4152-6890-0 RUBBER PAD 2617-19-0 W/DOUBLE RF101 7010-0060-0 CN ASSY UL2547 #26 L=210 3P M/F RF101 1681-1000-A UL1007 AWG#20 BLACK L=620MM RF101 CASING PRE AMP ASSEMBLY...

  • Page 11: Casing Smps Assembly

    POWERED SUBWOOFER PARTS LIST CASING SMPS ASSEMBLY QTY PART NO DESCRIPTION LOCATION 1403-6680-0 SWITCH POWER TOP COVER TOP COVER 1403-6690-0 SWITCH POWER BOTTOM BOTTOM COVER 1806-2375-0 TT-9975 EARTH TOROIDAL C 1806-3556-0 CHOKE TRANSFORMER EI-41 2113-9535-0 HALO BUSHING 0813C BOTTOM COVER 2600-3005-0803 METAL WASHER M3X0.5X8MM FAN1...

  • Page 12: Speaker Assembly

    POWERED SUBWOOFER PARTS LIST CASING SMPS ASSEMBLY CONTINUED QTY PART NO DESCRIPTION LOCATION 6360-0011-0 PLASTIC CABLE TIE 97MM 6360-1322-0 PLASTIC CABLE TIE 200MM 7010-2353-0 WIRE CON ASSY 3P L=120MM 7011-6720-0 UL1007 #18 500MM W/FUSE RING T'NAL 8900-9520-0 DC FAN CHA8012BS FAN1 SPEAKER ASSEMBLY QTY PART NO...

  • Page 13: Speaker Assembly

    POWERED SUBWOOFER PARTS LIST SPEAKER ASSEMBLY CONTINUED QTY PART NO DESCRIPTION LOCATION DUM-1403-4440-0 DUMMY 1403-4440-0 1497-7202-0 PE BAG 840X700X0.05 OTHER-SPK-FC3T0C OTHER PARTS FOR PSW3000 145A-7200-0 M.BOX FOR PSW3000 1490-7343-0 P.FOAM FOR PSW1000/S8 1490-7343-1 P.FOAM FOR PSW1000/S8 1497-4102-0 P.BAG 10'*12' W/ES GREEN 1497-4122-0 P.BAG 10'*14' W/ES GREEN 2640-4030-0704...

  • Page 14: Block Diagram

    POWERED SUBWOOFER BLOCK DIAGRAM...

  • Page 15: Schematic Diagrams

    POWERED SUBWOOFER SCHEMATICS DIAGRAMS Pre Amp Schematic...
  • Page 16 POWERED SUBWOOFER SCHEMATICS DIAGRAMS Power Amp Schematic...
  • Page 17 POWERED SUBWOOFER SCHEMATICS DIAGRAMS...

  • Page 18: Schematic Diagrams

    POWERED SUBWOOFER SCHEMATICS DIAGRAMS...

  • Page 19: Pcb Layout

    POWERED SUBWOOFER PCB LAYOUT LED PCB Component Side LED PCB Copper Side...
  • Page 20 POWERED SUBWOOFER PCB LAYOUT Pre AMP PCB Component Side Pre AMP PCB Copper Side...

  • Page 21: Pcb Layout

    POWERED SUBWOOFER PCB LAYOUT Power AMP PCB Component Side Power AMP PCB Copper Side...

  • Page 22: Exploded View Diagrams

    POWERED SUBWOOFER EXPLODED VIEW DIAGRAMS REF DESCRIPTION PARTS NO. REF DESCRIPTION PARTS NO. REAR PANEL 1403-6700-0 BINDING POST BLK 2103-7101-0 DUST FILTER NET 3100-5951-0 INT TEETH WASHER M3*0.5*6.4 2606-3005-0643 SWITCH TOP COVER 1403-6680-0 T3*8MM SELF TAPPING 2954-3008-3000 SMPS PCB 1725-542A-0000 M3 NUT NI 2640-3022-0544 SWITCH BOT COVER...
  • Page 23 POWERED SUBWOOFER EXPLODED VIEW DIAGRAMS Packing Exploded View FC3T0C-EU/UK/US REF DESCRIPTION PARTS NO. P.FOAM FOR PSW1000/S8 1490-7343-0 CABINET FOR PSW3000 1403-4440-1 PE BAG 840X700X0.05 1497-7202-0 M.BOX FOR PSW3000 145A-7200-0 UPC LABEL FOR PSW3000 - EU 3000-6820-0 UPC LABEL FOR PSW3000 - UK 3000-6822-0 UPC LABEL FOR PSW3000 - US 3000-6821-0...

  • Page 24: Exploded View Diagrams

    POWERED SUBWOOFER EXPLODED VIEW DIAGRAMS Sub-pack Exploded View REF DESCRIPTION PARTS NO. CABINET FOR PSW3000 1403-4440-1 SUBWOOFER FOOT PSW1000 PART A 4153-9411-0 SUBWOOFER FOOT PSW3000 PART B 4154-2461-0 10"WF FOR PSW3000 8900-5780-0 ME SCREW ALLEN HEAD M4*25 2918-4025-3400 SCREW BINDING HEAD M4*16 2913-4016-3000 ELE-AMP-FC3T0C ACOUSTIC WOOL 860*320*30...
