Intex Easy set Owner's Manual page 7

You may have purchased this pool with the Intex Krystal Clear™ filter
pump. The pump has its own separate set of installation instructions. First
assemble your pool unit and then set up the filter pump.
1. • Find a flat, level location that is free and clear of stones, branches or other sharp objects
that may puncture the pool liner or cause injury.
• Open the carton containing the liner, etc., very carefully as this carton can be used to
store the pool during the winter months.
• Take out the ground cloth (3) and spread it
over the cleared area. Then take out the
liner (1) and spread it out over the ground
cloth, with the drain valve directed towards
the draining area. Place the drain valve away
from the house.
IMPORTANT: Always set up the pool unit
with at least 2 persons. Do not drag the
liner across the ground as this can cause
leaks or other damages (see drawing 2).
• During the setup of the pool liner, point the
hose connections or openings in the
direction of the electrical power source. The
outer edge of the pool should be within
reach of the pump's electrical connection.
2. Lay out the pool. Spread out the plain blue
sides and make the pool floor as smooth as
possible (see drawing 2).
3. Flip the top ring out and check that it is fully
outside of the wall lining and facing up. Inflate
the ring with a manual air pump (see
drawing 3). Keep the top ring centered in the
middle of the pool, while doing this.
IMPORTANT: Prevent bursting by not using
a high-pressure pump, such as an air
compressor. Do not over inflate. Preferably
use an Intex manual inflation hand pump
(not included).
Proper inflation of the top ring.
The ambient temperatures of air and water have an effect on the internal pressure of
the top ring. To maintain a correct internal pressure, it is best to leave some room for
expansion as the sun heats the air inside the ring. During very hot weather, you
must check to see whether it is necessary to release some air. This is to avoid any
possible damage to the ring.
In no event shall Intex, their authorized agents or employees be liable for
damages (such as pin holes) to the inflatable top ring caused by negligence,
ordinary wear and tear, abuse and carelessness, or external forces.
4. The following applies to pool liners with hose connectors (16" (488 cm) & below pools). If
the pool was purchased without a filter pump, stick two black plugs (2) into the black filter
pump outlets. Do this from the inside of the pool so that water will not run out when filling it.
If the pool was purchased with a filter pump, consult the Krystal Clear™ Filter Pump
Manual first and then go to step #5.
SAVE THESE INSTRUCTIONS
POOL SETUP (continued)
IMPORTANT
(86PO) EASY SET POOL ENGLISH 7.5" X 10.3" PANTONE 295U 06/12/2009
WATER
LEVEL
Level
English
86PO
1
2
3
Page 7
