Digital Antenna PowerMax DA4KSBR-50U Installation And Operation Manual

60 db gain dual band wireless amplifier/repeater system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Installation and Operation Manual
DA4KSBR-50U
TM
60 dB Gain Dual Band
Wireless Amplifier/Repeater System
Read Instruction before installing!
If you do not understand instructions,
seek professional installation.
# $ % $ % %
! "
& # $ % $ % %

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PowerMax DA4KSBR-50U and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Digital Antenna PowerMax DA4KSBR-50U

Summary of Contents for Digital Antenna PowerMax DA4KSBR-50U

  • Page 1 Installation and Operation Manual DA4KSBR-50U 60 dB Gain Dual Band Wireless Amplifier/Repeater System Read Instruction before installing! If you do not understand instructions, seek professional installation. # $ % $ % % ! " & # $ % $ % %...

  • Page 2: Table Of Contents

    INSTALLATION AND OPERATION MANUAL Model #DA4KSBR-50U 1. Package Contents…………………………………………………………………….. 3 2. Important Safety Information………………………………………………………… 3 a. Limited Warranty………………………………………………………. 4 b. Limitation on Liability………………………………………………….. 4 c. FCC Regulations………………………………………………………… 4 3. Pre-installation Guidelines……………………………………………………………. 5 a. Installation Tools…………………………………………………...…… 5 b. Installation Procedure………………………………………………..…. 5 c.

  • Page 3: Package Contents

    WARNING! Only Digital Antenna authorized products may be used with the DA4000SBR system. Using unauthorized equipment with the DA4000SBR system will harm the system, voids the warranty and can be detected in the event of a failure.

  • Page 4: Limited Warranty

    Digital Antenna in writing. If products sold hereunder are not as warranted, Digital Antenna shall, at its option either refund the purchase price, or repair or replace the product, provided proof of purchase and written notice of nonconformance are received by Digital Antenna within five (5) or one (1) years of date of purchase and provided said nonconforming Products are, with Digital Antenna’s written authorization, returned in protected shipping containers.

  • Page 5: Pre-Installation Guidelines

    3. Pre-Installation Guidelines a. INSTALLATION TOOLS The following tools are required for installation: • Standard wrench and philips head screwdriver • Standard drill with ½” bit (optional) • Cellular phone operating on 800 or 1900 MHz bands (any USA or Canadian cellular phone except Nextel) •...

  • Page 6: Electrical Power

    of the building. (see specific section for Home/Office, marine and RV installations) The omni-directional antenna should be installed on the side of the building with the strongest cellular signal as indicated by the bars on the cell phone. The outside antenna must be installed outside of the building, RV or boat.

  • Page 7: Amplifier/Repeater Status

    To plug into a standard 110 VAC receptacle use P/N DP255, a 110 VAC to 5VDC Power Supply. For use on a boat or RV, plug P/N DP515, a 12 VDC to 5 VDC Power Cable, into a 12 VDC cigarette style power receptacle. d.

  • Page 8: In-Building Coverage Problems

    If the installed application requires more than the supplied cable, DA340 ULTRA low loss 25’ extension cable and 75’ replacement cable are available. Only Digital antenna cable can be used to complete the installation. Unauthorized cable usage can be detected and voids the warranty.

  • Page 9: Home/Office Installation

    Mount the outside antenna clear of metal objects and obstructions. Outside antenna must be mounted in a vertical position. WARNING! Only Digital Antenna authorized products may be used with the DA4000SBR system. Using unauthorized equipment will harm the DA4000SBR system, can be detected and voids the warranty.

  • Page 10: Marine Installation

    Antenna’s marine 9dB gain dual band cellular antennas. (Follow minimum 40’ Inside and Outside antenna separation guideline) WARNING! Only Digital Antenna authorized products may be used with the DA4000SBR system. Using unauthorized equipment will harm the DA4000SBR system, can be detected and voids the warranty.

  • Page 11: Rv Installation

    A/C. WARNING! Only Digital Antenna authorized products may be used with the DA4000SBR system. Using unauthorized equipment with the DA4000SBR system will harm the system, can be detected and voids the warranty.

  • Page 12: Electrical Specifications

    7. Specifications Amplifier/Repeater Unit P/N DA4000SBR • Frequency: Uplink: 824-849 MHz and 1850-1910 MHz Downlink: 869-895 MHz and 1930-1990 MHz • Modulations: AMPS/GPRS/TDMA/PCS/CDMA/GSM850/GSM1900 • Max Output Power: 3W (824-849 MHz), 2W (1850-1910 MHz) • Dynamic Variable Gain: 60dB Max • Impedance: 50 ohms •...

  • Page 13: Antenna & Accessory Options

    Outside Dual Band Cellular Antennas For complete antenna specs White Black Visit www.DigitalAntenna.com Digital Antenna’s 500 series antennas include: 20’ cable, mount 1”-14 threads, high-gloss finish 2.5' Dual Band 9dB Gain Cellular Antenna 561-CW 561-CB 4' Dual Band 9dB Gain Cellular Antenna...

  • Page 14: Technical Support

    Digital Antenna manufacturers cellular amplifiers, repeaters and antennas for the best communication on land or sea. All products are designed, engineered and manufactured by Digital Antenna in the USA. Visit www.DigitalAntenna.com to view our complete product line. 9. Technical Support Read Product FAQs on Digital Antenna’s website prior to calling Tech Support.
