INSTALLATION AND OPERATION MANUAL
1. Package Contents................................................................................ 2
2. Important Safety Information.................................................................. 2
a. Limited Warranty................................................................ 3
b. Limitation on Liability........................................................... 3
c. FCC Regulations.................................................................. 3
3. Pre-installation Guidelines...................................................................... 3
a. Installation Tools.................................................................. 3
b. Installation Procedure............................................................ 4
c. Electrical Power................................................................... 5
d. Amplifier/Repeater Status....................................................... 5
e. In-building Coverage Problems................................................. 6
f. Coaxial Cable Recommendations............................................... 7
4. Home/Office Installation........................................................................ 8
5. Marine Installation............................................................................... 9
6. RV Installation.................................................................................. 10
7. Electrical Specifications....................................................................... 11
8. Antenna & Accessory Options............................................................... 12
9. Technical Support.............................................................................. 13
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Digital Antenna DA4000SBR
Summary of Contents for Digital Antenna DA4000SBR
-
Page 1: Table Of Contents
INSTALLATION AND OPERATION MANUAL 1. Package Contents…………………………………………………………………….. 2 2. Important Safety Information………………………………………………………… 2 a. Limited Warranty………………………………………………………. 3 b. Limitation on Liability………………………………………………….. 3 c. FCC Regulations………………………………………………………… 3 3. Pre-installation Guidelines……………………………………………………………. 3 a. Installation Tools…………………………………………………...…… 3 b. Installation Procedure………………………………………………..…. 4 c. Electrical Power………………………………………………………..5 d. -
Page 2: Package Contents
2. Important Safety Information The DA4000SBR system complies with all FCC, IC, UL rules, regulations and codes. Follow all guidelines in the installation and instruction manual and read completely before beginning the installation procedure. Do not deviate or disregard any of the safety features included in the manual or with the equipment, nor operate the system in an unintended application. -
Page 3: Limited Warranty
Digital Antenna in writing. If products sold hereunder are not as warranted, Digital Antenna shall, at its option either refund the purchase price, or repair or replace the product, provided proof of purchase and written notice of nonconformance are received by Digital Antenna within five (5) or one (1) years of date of purchase and provided said nonconforming Products are, with Digital Antenna’s written authorization, returned in protected shipping containers. -
Page 4: Installation Procedure
This translates into fewer dropped calls, safe, clear connections and stronger signals. The DA4000SBR dual band system operates with all carriers in the USA and Canada except Nextel. A Nextel companion unit is under development. -
Page 5: Electrical Power
50’ and 75’ cables sold separately) and within 6’ of a power receptacle (or an extension cord can be used). The DA4000SBR unit is not waterproof and must be kept in a dry location. c. ELECTRICAL POWER To maximize installation flexibility, the DA4000SBR system includes 2 power cord options. -
Page 6: In-Building Coverage Problems
DA4000SBR unit must be available. e. IN-BUILDING COVERAGE PROBLEMS If the DA4000SBR unit does not indicate a red light and the coverage area appears to be smaller than anticipated, one or more of the following may limit the signal strength to the area. -
Page 7: Coaxial Cable Recommendations
PowerMax DA340 ULTRA low loss cable and connectors in 50’ and 75’ lengths are available. Only Digital antenna cable can be used to complete the installation. Unauthorized cable usage can be detected and voids the warranty. -
Page 8: Home/Office Installation
5. Plug 100-240VAC power supply to the DA4000SBR unit. Plug the other end into standard household 110VAC receptacle. 6. Turn the power switch to ON. If the light on the DA4000SBR unit is green then the DA4000SBR system is operating. Test the amplifier/repeater system by making a cell call and verifying that the indicator light does not turn red. -
Page 9: Marine Installation
WARNING! To have DC power hardwired consult a professional electronic technician. 6. Turn the power switch to ON. If the light on the DA4000SBR unit is green then the DA4000SBR system is operating. Test the amplifier/repeater system by making a cell call and verifying that the indicator light does not turn red. If the light on the DA4000SBR unit is red immediately turn OFF the DA4000SBR unit and refer to the Amplifier/Repeater status section. -
Page 10: Rv Installation
WARNING! To have DC power hardwired consult a professional electronic technician. 6. Turn the power switch to ON. If the light on the DA4000SBR unit is green then the DA4000SBR system is operating. Test the amplifier/repeater system by making a cell call and verifying that the indicator light does not turn red. If the light on the DA4000SBR unit is red immediately turn OFF the DA4000SBR unit and refer to the Amplifier/Repeater status section. -
Page 11: Electrical Specifications
• Power Consumption: Standby 5 vdc/0.5A, Uplink 5 vdc/2A Max. • Internal Fuse: 3A • FCC approved, FCC ID: PZODA4000SBR • Industry Canada approved, IC ID: 4260A-DA4000SBR • Dimensions: 4.5" l x 4.0" w x 1.25" h (114mm x 102mm x 32mm) • Weight: 12 oz (.345 kg) •... -
Page 12: Antenna & Accessory Options
Outside Dual Band Cellular Antennas For complete antenna specs White Black Visit www.DigitalAntenna.com Digital Antenna’s 500 series antennas include: 20’ cable, mount 1”-14 threads, high-gloss finish 2.5' Dual Band 9dB Gain Cellular Antenna 561-CW 561-CB 4' Dual Band 9dB Gain Cellular Antenna... -
Page 13: Technical Support
Locate the Digital Antenna Inc. serial number on the DA4000SBR unit before calling. The serial number is located on the bottom of the DA4000SBR unit. The DA4000SBR serial number must be available to authorize technical support and/or establish a return authorization.
