Custom Audio Electronics RS-10 Operating Manual

Midi foot controller

Advertisement

Quick Links

custom audio electronics inc.
RS-10
MIDI FOOT CONTROLLER
OPERATING
GUIDE
10648 Magnolia Blvd. North Hollywood, CA. 91601 Phone (818) 763-8898 Fax (818) 763-8890

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RS-10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Custom Audio Electronics RS-10

  • Page 1 • • • RS-10 MIDI FOOT CONTROLLER OPERATING GUIDE 10648 Magnolia Blvd. North Hollywood, CA. 91601 Phone (818) 763-8898 Fax (818) 763-8890...
  • Page 2 The RS-10 requires 9VAC at approximately 200ma. Power is applied via pins 6 and 7 of the 7 pin MIDI out port. If your RS-10 is equipped with a 5 pin MIDI Out jack, power will be applied to pins 1 and 3. There is no provision for power input other than these connections.
  • Page 3 The Global Preset The RS-10 (with EX software) contains a unique feature called the Global Preset. It is a preset with all the capabilities of preset 1 through 4 (including MIDI patch changes) but is the same for all banks. To access the Global Preset, just press again any active preset switch 1 through 4.
  • Page 4 Programming MIDI Patch Change Commands in the RS-10 The RS-10 (with EX software) is capable of sending 5 different MIDI patch changes (program change) commands on 5 separate channels for each bank/preset selected. Therefore, you must set each MIDI device in your system to a separate MIDI channel and send the required patch changes without mapping.
  • Page 5 * NOTE: 0.0 is used to indicate the Global Preset (which is the same for all banks). Use this location to set a Global Patch for each PC group 1 through 5. To Program an Alternate RS-10 MIDI Receive Channel: 1. Use FUNCTION SELECT (PS-1) in PROGRAM MODE to scroll until display reads rch.
  • Page 6 2. Press program (PS-4) switch. Display flashes. 3. The RS-10 is now ready to receive data from the storage device or computer via the MIDI in port. 4. Initiate the data dump procedure for the storage device (Data Disk, sequencer or computer).
  • Page 7 MIDI Input to the RS-10 the RS-10’s MIDI input port can be used for bulk data dumps and master/slave operations. It can also receive MIDI program change commands on a selected MIDI channel (factory default = channel 16). Below are charts showing the relationship between MIDI program change commands received and bank/presets selected for both standard and expanded RS-10’s.
  • Page 8 CONNECT WITH THE POWER OFF!!! The Expander was designed to be placed on the right side of the RS-10, directly against it. However, it can be placed no more than 2 feet to either side of necessary. Contact factory if a longer cable is necessary.
