Mini Owner's Manual page 106

Controls
Installation behind the rear seats
1. If necessary, move the rear seat backrests
forward, refer to page 105, and remove the
cargo cover, refer to page 104.
2. Insert the retaining pins of the partition net
all the way into the rear holders in the
headliner, arrow 1, and push forward.
3. Attach the partition net to the cargo area
floor by hooking the hooks into the eyelets,
arrow 2.
Installation behind the front seats
1. Fold down the rear seat backrests, refer to
page 105.
2. Insert the retaining pins of the partition net
all the way into the front holders in the
headliner, arrow 1, and push forward.
3. Fold up the eyelets on the rear seat and at‐
tach the partition net, arrow 2.
MINI Clubman: flat loading floor
Note the maximum load
The maximum load on the flat loading
floor is 165 lbs, 75 kg. Do not exceed a maxi‐
mum permissible load of 55 lbs, 25 kg, in the
106
Interior equipment
Online Edition for Part no. 01 40 2 911 452 - VI/13
storage compartment under the loading floor;
otherwise, damage may
Raise the flat loading floor and fold up for‐
wards, arrow.
Removing
1. Fold up the flat loading floor.
2. Pull the loading floor back slightly.
3. Then remove it upward.
result.◀
