Installation Manual
PLEASE READ BEFORE USE AND SAVE.
This handset is an accessory cordless handset, for use with Panasonic base units
KX-TG5100/KX-TG5110. This installation manual only describes the steps necessary to start
up the handset. Please read the KX-TG5100/KX-TG5110 operating instructions for further
details.
Accessories (included) For extra orders, call 1-800-332-5368.
Charger Unit . . . . . . . . . . . . . . . . . . . . .one
Charger
Order No. PQLV30019ZM
AC Adaptor Order No. KX-TCA1-G (KX-TCA1)
Handset Cover . . . . . . . . . . . . . . . . . . . .one
Order No. PQKK10137Z1
Installation

Connecting the Charger unit

• USE ONLY WITH Panasonic AC ADAPTOR KX-TCA1 (Order No. KX-TCA1-G).
• The AC adaptor must remain connected at all times. (It is normal for the adaptor to feel
warm during use.)

Installing the battery

Insert the battery (
1
When finished, close the cover.
For assistance, please call: 1-800-211-PANA(7262)
5.8GHz Expandable Cordless Handset
AC Adaptor
), and press it down until it snaps into the compartment (
2
1
– 1 –
KX-TGA510M
Model No.
Battery . . . . . . . . . . . . . . . . . . . one
Order No. P-P511
Belt Clip . . . . . . . . . . . . . . . . . . one
Order No. PQKE10363Z1
Power Outlet
(AC 120 V, 60 Hz)
PQQX13604YA
).
2
S0203-1033
