Parts List - Portland 67255 Owner's Manual

parts List

part Description
1 Nut Cover
2 Nut M8
3 Drive Cover
4 Seal Ring
5 Retaining Ring Ø 7
6 Sprocket
7 Seal Cover
8 Screw M4 x 16 (on page 18
9 Rubber Sleeve
10 Connecting Plug
11 Sponge
12 Oil Outlet Connection
13 Oil Outlet Tube
14 Oil Inlet Tube
15 Oil Tube Clamp
16 Screw M3 x 12
17 Oil Outlet Tube
18 Oil Tank
19 Oil Tank Cap
21 Cap Gasket
22 Valve
23 Screw
24 Screw M4 x 10
25 Guide Bar Mounting Pad
26 Tension Screw
27 Tightening Nut
28 Spring
29 Right Housing
30 Front Handle Guard
31 Rubber Ring
32 Oil Outlet Connection
33 Screw M4 x 10
34 Bearing
35 Micro Switch
36 Bolt M8
37 Circlip Ø 16
38 Output Shaft
Item 67255
Qty
1
1
1
1
1
1
1
19) 23
&
1
1
1
1
1
1
1
3
1
1
1
1
1
1
2
1
1
1
1
1
1
2
1
2
1
1
1
1
1
For technical questions, please call 1-888-866-5797.
part Description
39 Gear
40 Trim Plate
41 Bearing
42 Motor Gear
43 Backup Plate
44 Front Bearing
45 Rear Bearing
46 Rotor
47 Spring
48 Lockout Switch
49 Trigger Switch
50 Trigger Spring
51 Power Cord Sheath
52 Power Cord
53 Power Cord Clamp
54 Left Housing
55 Screw
56 Motor Rear Holder
57 Carbon Brush
58 Brush Holder
59 Plate
60 Screw
61 Stator
62 Pump
63 Oil Plug Cover
64 Piston Support
65 Worm Gear Shaft
66 Worm Gear
67 Spring Washer Ø 4
68 Washer Ø 4
69 Nut M4
70 Stator Housing
71 Chain Guide Bar
72 Saw Chain
73 Chain Guide Bar Sheath
74 Wrench
Qty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
2
2
1
1
1
1
1
1
2
2
2
1
1
1
1
1
Page 21
