MICROWAVE OVEN
Focal Point Fires plc.
Christchurch, Dorset BH23 2BT
Tel: 01202 499330
Fax: 01202 499326
www.focalpointfires.co.uk
e : sales@focalpointfires.co.uk
Please note: Except where otherwise stated, all rights,
including copyright in the text, images and layout of this
booklet is owned by Focal Point Fires plc. You are not
permitted to copy or adapt any of the content without
the prior written permission of Focal Point Fires plc.
Owner's Instructions
MODELS COVERED BY THESE INSTRUCTIONS
VT -25UG16-1 MICROWAVE OVEN
1
VT-25UG16-1
All instructions must be handed to the user for
safekeeping.
Revision A - 02/13
GB IE
BS7977-1 : 2009
KM579168
©
2013 Focal Point Fires plc.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Focal Point VT-25UG16-1
Summary of Contents for Focal Point VT-25UG16-1
- Page 1 Please note: Except where otherwise stated, all rights, including copyright in the text, images and layout of this booklet is owned by Focal Point Fires plc. You are not All instructions must be handed to the user for permitted to copy or adapt any of the content without safekeeping.
-
Page 2: Table Of Contents
Power Source 220-240V/50Hz Input Power Microwave 1350W Grill 1000W Output Power 800W Dimensions (WxHxD) Outside 509 x 320 x 385 Oven cavity 348 x 222 x 336.5 Volume 25 litre Weight 15.2 Kg approx © 2013 Focal Point Fires plc. -
Page 3: Oven
Purpose: The turntable serves as the main cooking surface; it can be easily removed for cleaning. Figure 4 Grill rack, to be placed on the turntable. Purpose: The grill rack serves as the grilling surface; it can be easily removed for cleaning. Figure 5 © 2013 Focal Point Fires plc. -
Page 4: Control Panel
4) If you turn the food during operation, press the Instant/Start button once and the preset cooking procedure will continue. 5) If you intend to remove the food before the preset time, you must press Press/Cancel button once to clear the preset procedure to avoid unintended operation of the next time use. © 2013 Focal Point Fires plc. - Page 5 D.2 For defrosting meat between 0.1Kg to 2.0Kg. D.3 For defrosting seafood between 0.1Kg to 0.9Kg. 1. It is necessary to turn over the food during defrosting, to ensure it defrosts evenly. 2. Defrosting food usually takes longer the cooking foods. © 2013 Focal Point Fires plc.
- Page 6 If you do not want the menu be started immediately, you can preset the cooking menu and time and the preset menu will be automatically started at your set time. 14. Multi-sequence cooking To obtain best cooking result, some recipes need to different amounts of time to cook. © 2013 Focal Point Fires plc.
-
Page 7: Safety Precautions
NEVER fill the container to the top and choose a container that is wider at the top than at the bottom to prevent the liquid from boiling over. Bottles with narrow necks may also explode if overheated. ALWAYS check the temperature of the baby foods or milk before giving it to a baby. © 2013 Focal Point Fires plc. -
Page 8: Installing Your Microwave
As shown in figure 7. Top air guide Outer-back baffle Self-lock screw M4X10(6PCS) b) Secure fixing brackets onto each side of the microwave housing. As shown in figure 8. Fixing bracket Self locking screws M4X10 (12PCS) © 2013 Focal Point Fires plc. - Page 9 Secure the decorative frame into the fixing brackets, which have already been fixed in place on the microwave. As shown in figure 10. The side with gap should be installed at the bottom of the microwave Decrorative frame e) Integrated microwave installation completed. © 2013 Focal Point Fires plc.
-
Page 10: Troubleshooting
The oven causes interference with radios or televisions. • Slight interference may be observed on televisions or radios when the oven is operating.This is normal.To solve this problem, install the microwave away from televisions, radios and aerials. © 2013 Focal Point Fires plc. -
Page 11: Cookware Guide
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your local authority or retailer for recycling advice. As our policy is one of continuous improvement and development, we therefore hope that you will understand we must retain the right to amend details and/or specifications without prior notice. © 2013 Focal Point Fires plc.
Need help?
Do you have a question about the VT-25UG16-1 and is the answer not in the manual?
Questions and answers
The microwave has a burn mark on the inside of the door and is now not working
A burn mark inside the Focal Point VT-25UG16-1 microwave could be caused by:
- Using a dish with metal trimmings
- Leaving a fork or other metal utensils inside
- Aluminium foil being too close to the oven walls
These can cause sparking or arcing, leading to burn marks.
The microwave may not be working because:
- The timer was not set correctly
- The door is not properly closed
- The electric circuit is overloaded, causing a fuse to blow or a breaker to trip
These issues can prevent the microwave from operating.
This answer is automatically generated
My control panel has a mind of its own jumping about various settings
The control panel of the Focal Point VT-25UG16-1 microwave could be changing settings unexpectedly due to several possible reasons:
1. Accidental Knob Movement – The Time/Weight/Auto Cooking knob can change settings if it is accidentally turned.
2. Child Lock Not Activated – If the child lock function is not enabled, accidental button presses could alter settings.
3. Electrical Interference – Power fluctuations or unstable voltage might cause the LED panel to behave unpredictably.
4. Faulty Buttons or Control Panel – A malfunctioning button or panel may cause unintended inputs.
5. Moisture or Dirt on the Panel – If the control panel is dirty or damp, it may register unintended touches.
If the issue persists, cleaning the panel, enabling the child lock, or checking the power supply may help. If none of these resolve the problem, technical inspection may be needed.
This answer is automatically generated
Where can I buy a new microwave from
Where can I buy one
My control panel starts ok, but if I'm heating something longer than a few minutes the panel starts to fluctuate and flickering off the timer and even though the turntable is still going round it stops heating
