SPLIT-TYPE,AIR CONDITIONERS
SERVICE MANUAL
Multi system type
Models
MUX-19TV -
MUX-20TV -
MUX-25TV -
MUX-19TV -
E1
MUX-20TV -
E1
MUX-25TV -
E1
This manual describes technical data of outdoor unit.
For indoor unit refer to the service manuals No.OB227 REVISED EDITION-B and OB252 REVISED EDITION-A of corre-
sponding models.
E1
E1
E1
CONTENTS
1. TECHNICAL CHANGES ····································2
2. PART NAMES AND FUNCTIONS······················2
CORRESPONDENCE TABLE ···························3
4. SPECIFICATION·················································3
5. NOISE CRITERIA CURVES ······························ 6
6. OUTLINES AND DIMENSIONS ························ 7
7. WIRING DIAGRAM ············································9
8. REFRIGERANT SYSTEM DIAGRAM ··············10
9. PERFORMANCE CURVES ······························14
10. TROUBLESHOOTING······································26
11. DISASSEMBLY INSTRUCTIONS·····················32
12. PARTS LIST······················································35
13. OPTIONAL PARTS···········································37
No. OB284
