Operator's Manual
LAWN TRACTOR
19.5 HP, 42" Deck
Electric Start, 7 Speed
Model No. 247.28902
• Espanol, P. 59
This product has a low emission engine which operates differently
from previously built engines. Before you start the engine, read and
understand this Operator's Manual.
CAUTION
Before using this equipment,
read this manual and follow
all safety rules and operating
instructions.
Sears Brands Management Corporation, Hoffman Estates, IL 60179 U.S.A.
Visit our website: www.craftsman.com
®
For answers to your questions about
this product, Call:
1-800-659-5917
Craftsman Tractor Help Line
7 am - 7 pm CT, Mon. - Sun.
Form No. 769-05571A
(February 15, 2010)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Craftsman 247.28902
Summary of Contents for Craftsman 247.28902
- Page 1 ® LAWN TRACTOR 19.5 HP, 42” Deck Electric Start, 7 Speed Model No. 247.28902 • Espanol, P. 59 This product has a low emission engine which operates differently from previously built engines. Before you start the engine, read and understand this Operator’s Manual.
- Page 2 Labels 777S32491 REF: 751B278856 777X43688 DANGER TO START 1. DISENGAGE BLADES/PTO, (POWER TAKE OFF) ROTATING BLADES CAUSE 2. ENGAGE THE TRACTOR’S PARKING BRAKE. SERIOUS INJURY OR DEATH 3. ACTIVATE THE CHOKE CONTROL. 4. TURN KEY TO START ENGINE. AFTER START RELEASE KEY & DEACTIVATE CHOKE •...
-
Page 3: Parts List
PARTS LIST Craftsman Model 247.28902 30 30... - Page 4 PARTS LIST Craftsman Model 247.28902 Ref. Ref. Part No. Description Part No. Description 711-0736 Ferrule, 1/4-20 x 1.00 925-1649 Bulb Socket 712-04065 Nut, Hex Flange Insert Lock, 3/8-16 683-04619-4043 Hood Assembly 710-04484 Screw, 5/16-18 x .750 714-04040 Cotter Pin 936-0133 Flat Washer, .411 x 1.25 x .100...
- Page 5 PARTS LIST Craftsman Model 247.28902...
- Page 6 PARTS LIST Craftsman Model 247.28902 Ref. Ref. Part No. Description Part No. Description 756-04196A Engagement Pulley 683-04155A-0637 Shaft, Lift 747-04857 Belt Keeper Rod Assembly 712-04065 Nut, Hex Flange Insert Lock, 3/8-16 710-04484 Screw, Hd. Tapp, 5/16-18 x .75 714-04040 Bow-Tie Pin, 91, RH...
- Page 7 PARTS LIST Craftsman Model 247.28902...
- Page 8 PARTS LIST Craftsman Model 247.28902 Ref. Ref. Part No. Description Part No. Description 617-04024 Gear Assembly, Steering 938-04007A-0637 Axle Assembly LH 710-0376 Screw, 5/16-18, 1.00, Gr5 638-04008P Axle Assembly RH 683-0128B-0637 Pivot Bar Axle Assembly 710-0643 Screw, 5/16-18, 1.00, Gr5, Lock 710-04484 Screw, 5/16-18, 0.750...
- Page 9 PARTS LIST Craftsman Model 247.28902 31 32...
- Page 10 PARTS LIST Craftsman Model 247.28902 Ref. Part No. Description 710-1268 Screw, #10-16 x .375 712-04063 Flange Lock Nut, 5/16-18 712-04064 Flange Lock Nut, 1/4-20 720-0309A Seat Adjustment Grip 726-0201 Speed Nut 731-04074 Seat Adjustment Spacer 732-0499 Compression Spring, .41 x 1.50...
- Page 11 PARTS LIST Craftsman Model 247.28902...
- Page 12 PARTS LIST Craftsman Model 247.28902 Ref. Part No. Description 683-04549-0637 Muffler Shield Assembly 710-0227 Screw, AB #8-18 0.500 710-04683 Tap Screw, 3/8-16 1.000 710-0642 Tap Screw, 1/4-20 0.750 710-1314A Screw, Socket Head, 5/16-18 x .750 712-0271 Sems Nut, 1/4-20 BS-692236...
- Page 13 PARTS LIST Craftsman Model 247.28902...
- Page 14 PARTS LIST Craftsman Model 247.28902 Ref. Ref. Part No. Description Part No. Description 747-05188 Brake Rod 918-04566 Transmission Drive Assembly 747-05243 Shift Rod, 46” 647-04034C-0637 Pedal Assembly 948-0334 Spacer, T-Axle 647-04035 Shaft Lever Assembly 750-0566A Spacer, .260 x .375 x 1.030 LG 710-0227 Screw, 8-18:0.500...
- Page 15 PARTS LIST Craftsman Model 247.28902...
- Page 16 PARTS LIST Craftsman Model 247.28902 Ref. Ref. Part No. Description Part No. Description 918-04822A Spindle Pulley Assembly 736-0262 Flat Washer, .385 x .870 x .092 736-0362 Flat Washer, .330 x 1.25 x .06 683-0254B-0637 Deck Hanger Bracket Assembly 738-04146 Bolt Plug, M16 x 1.5...
- Page 17 PARTS LIST Craftsman Model 247.28902 with engine Model 31p677-1373-b2 1264 1263 1044 1270 1017 1024 1027...
- Page 18 PARTS LIST Craftsman Model 247.28902 with engine Model 31p677-1373-b2 1026 1026A 1022 1034 1029 1023 1022...
- Page 19 PARTS LIST Craftsman Model 247.28902 with engine Model 31p677-1373-b2 1091 135A 1127 1266...
- Page 20 PARTS LIST Craftsman Model 247.28902 with engine Model 31p677-1373-b2 1040 305A 305B 1070 1005 1044 1051...
- Page 21 PARTS LIST Craftsman Model 247.28902 with engine Model 31p677-1373-b2 1059 1119 1054 1051 1090...
- Page 22 PARTS LIST Craftsman Model 247.28902 with engine Model 31p677-1373-b2 121 CARBURETOR OVERHAUL KIT 1266 1266A 358 ENGINE GASKET SET 1022 1266 1095 VALVE GASKET SET 1022...
- Page 23 PARTS LIST Craftsman Model 247.28902 with engine Model 31p677-1373-b2 Ref. No. Part No. Description Ref. No. Part No. Description 796010 Cylinder Assembly 695408 Kit-Idle Speed 399265 Kit-Bushing/Seal (Magneto Side) 694918 Pin-Float Hinge 696136 Valve-Float Needle 391086s Seal-Oil (Magneto Side) 695419...
- Page 24 PARTS LIST Craftsman Model 247.28902 with engine Model 31p677-1373-b2 Ref. No. Part No. Description Ref. No. Part No. Description 796006 Shield-Cylinder 691909 Boot-Spark Plug 691003 Screw (Cylinder Shield) 698401 Retainer-Air Filter 693551 Motor-Starter 690958 Nut (Carburetor) 690323 Screw (Starter Motor)
