SEARCH KEYPAD SOURCE VOICE GUIDE RETURN CH.LIST EXIT SMART HUB P.SIZE MENU INFO Samsung Remote Batteries Base Stand Mount Smart Control Control (2 AA, 2 AAA) Also included Screws (x8) Wall Mount Adapter (75 inches models: 4 pieces) User manual...
Assemble Locate the Base, Stand Mount, and Place the TV on a soft surface, Screws in the box and set them screen side down. Use the aside. Styrofoam to protect the screen. ✎ Remove the top portion of the box to locate the stand parts. X 4 (M4 X L14) Fit the Base and Stand Mount Insert 4 screws, and then use a...
Holding the stand parallel to the screen, slide the Stand Mount into the notches on the back of the TV. X 4 (M4 X L14) Insert 4 screws, and then use a screwdriver to secure the stand to the TV. Set the TV upright on its stand.
Connect * Recommended Connections After you have connected all Connection panel on your external devices, plug the the back of the TV TV’s power cord into the back of the TV. DO NOT plug it into a wall outlet until you have reached Section 7, Initial Setup.
Gear * Recommended Connections Audio Connect a receiver/home theater using an optical audio cable. Blu-ray/DVD/Home Theater Connect your video player using an HDMI cable. Game console Connect your game console or DVR using an HDMI cable.
STB Control You can control your set-top-box or satellite box with the Samsung Smart Control. To establish control, you must ﬁrst set up the IR extender cable. If you don’t have an STB, skip this section. Connect the IR extender cable to the TV’s IR output connector.
ﬁgure above until the cover is completely attached to the remote control. Using the Samsung Smart Control When you start the TV for the ﬁrst time by pressing the TV button on the Samsung Smart Control, the TV and the Samsung Smart Control pair, using the TV’s Bluetooth function.
If you need to re-establish the connection between the TV and the Samsung Smart Control, point the Samsung Smart Control at the remote control sensor of the TV, and then press the RETURN button and GUIDE button simultaneously for 3 seconds or...
Once your Samsung Smart Control pairs, you can use the Samsung Smart Control’s motion sensor function to move the pointer on the screen. To use the motion sensor function, rest a ﬁnger on the touch pad, and then move the Samsung Smart Control. To select items, press the touch pad.
Common issues Can’t Connect to Network or “Weak or No Signal” Displayed in Apps (For Internet supported TV Mode/Cannot Find Channel models only) Press the SOURCE button on your Make sure the TV has a network remote. connection (MENU > Network > If the TV is not connected to a cable Network status).
If you experience issues, please do not take the TV back to the store. In the United States of America, call us at 1-800-SAMSUNG (1-800-726-7864) or visit us at www.samsung.com or www.samsung.com/spsn for support and warranty service.
Supported devices : The function is available for all 2014 models that support Multiroom Link. Sound quality may be affected by the condition of the wireless network. The network connection can be negatively affected and even lost if the network environment deteriorates over time.
If you want to connect to a HUB, refer to the manual for each device. HUBs may not be available in all countries and regions. If you want to purchase a HUB, please contact or visit the dealer you purchased your Wireless Audio Multiroom from or contact the Samsung Customer Care Center.
Setting Up Grouping with the Multiroom App Group Group Multiroom Audio 1 Multiroom Audio 1 Multiroom Audio 1 Multiroom Audio 1 + [Samsung] Multiroom Audio 1 + [Samsung] To create a new group. To create a new group. choose some speakers. Choose some speakers.
[Samsung] M* 1 Multiroom Audio 1 Wi-Fi Select the function that is suitable for how you will use the speaker. No Music No Music No Music [HTS]Model Name 1 [TV] Samsung Model Name 1 Source Surround Group Source Surround Group Source Surround...
Home Entertainment System Wireless Audio - Multiroom Setting Up Multiroom Home Theater Audio Using the Multiroom App Source [Samsung] M* 1 [Samsung] M* 1 Multiroom Audio 1 Wi-Fi Select the function that is suitable for how you will use the speaker.
Blu-ray Disc Player Wireless Audio - Multiroom Setting Up Multiroom Blu-ray Audio Using the Multiroom App Source [Samsung] M* 1 [Samsung] M* 1 Multiroom Audio 1 Wi-Fi Select the function that is suitable for how you will use the speaker.
Move the speaker by dragging it to the Move the speaker by dragging it to the desired location. desired location. [Samsung] M* 1 [Samsung] M* 2 [Samsung] M* 3 [Samsung]... [Samsung] M* 2 [Samsung] M* 3 [Samsung] M* 4 Cancel Next...
