Instructions for use
Thank you for purchasing the M1 CLiC "Universal Music Controller".
The M1 CLiC is an all-in-one internet radio, network music player, DAC and analogue preamp offering the ultimate in
networked and portable music, as well as home audio flexibility.
The M1 CLiC has been carefully designed to be partnered with M1 series, and also matches aesthetically with M3
and M6 series products. These combinations will yield one of the best high-fidelity systems available at any price.
Used carefully, it should give many years of outstanding musical reproduction.
Dust regularly with a soft duster or soft brush, but be careful when using cleaning or polishing agents - they may
harm the surface finish.
If there are any questions about the M1 CLiC, please consult the dealer who is there to help and advise.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Musical Fidelity M1 Clic
Summary of Contents for Musical Fidelity M1 Clic
- Page 1 Dust regularly with a soft duster or soft brush, but be careful when using cleaning or polishing agents - they may harm the surface finish. If there are any questions about the M1 CLiC, please consult the dealer who is there to help and advise.
-
Page 2: Table Of Contents
USB front Inputs – Inputs Problems? – Basic fault finding Specifications – Electronic specifications – Software specifications 20, 21 – Networking Specifications – File Formats and CODECS – Weights, dimensions and manual history M1 CLiC issue 5 Page 2 of 24... -
Page 3: Safety Information
• If connecting to a BS1363 plug, a 13 amp fuse must be used. WARNING: MODIFICATIONS THIS PRODUCT EXPRESSLY APPROVED BY MUSICAL FIDELITY WHO IS THE PARTY RESPONSIBLE STANDARDS COMPLIANCE COULD VOID USER'S AUTHORITY TO OPERATE THIS EQUIPMENT. M1 CLiC issue 5... -
Page 4: Installation Precautions And User Information
• Heed all warnings shown on the back of the product. • The M1 CLiC has a built-in universal power supply that can be connected to 50-60Hz A.C. mains of between 80 to 253V rms without modification. • Always ensure that when disconnecting and reconnecting audio equipment the mains supply is switched off. -
Page 5: M1 Clic Issue
ΠΡΟΣ ΑΠΟΦΥΓΗ ΕΝΔΕΧΟΜΕΝΗΣ ΕΠΙΒΑΡΥΝΣΗΣ ΤΟΥ ΠΕΡΙΒΑΛΛΟΝΤΟΣ, ΞΕΧΩΡΙΣΤΕ ΤΟ ΠΡΟΙΟΝ ΑΠΟ ΤΑ ΑΛΛΑ ΑΠΟΡΡΙΜΑΤΑ ΩΣΤΕ ΝΑ ΕΞΑΣΦΑΛΙΣΘΕΙ Η ΑΝΑΚΥΚΛΩΣΗ ΤΟΥ ΜΕ ΤΟΝ ΠΡΕΠΟΝΤΑ ΤΡΟΠΟ. ΠΑΡΑΚΑΛΟΥΜΕ ΝΑ ΕΠΙΚΟΙΝΩΝΗΣΕΤΕ ΜΕ ΤΗΝ ΤΟΠΙΚΗ ΥΠΗΡΕΣΙΑ ΑΝΑΚΥΚΛΩΣΗΣ Η ΜΕ ΤΟ ΚΑΤΑΣΤΗΜΑ ΑΓΟΡΑΣ ΓΙΑ ΠΕΡΙΣΣΟΤΕΡΕΣ ΛΕΠΤΟΜΕΡΕΙΕΣ. M1 CLiC issue 5 Page 5 of 24... -
Page 6: Introduction
Power Connections The M1 CLiC is supplied with a standard IEC mains cable which plugs into the IEC socket at the back of the unit. The unit features a universal power supply which can accept between 80 to 253V AC mains without need for reconfiguration. - Page 7 13 USB DAC INPUT type “B” for computer or NETWORK wired input 10/100Mbps UTP RJ45 14 OPTICAL INPUT digital TOSLINK ANTENNA wi-fi aerial input RP-SMA plug 15 COAXIAL INPUTS 1, 2 digital RCA 16 MAINS power in IEC plug M1 CLiC issue 5 Page 7 of 24...
-
Page 8: Remote Control
Remote Control The universal remote control shown below enables functions from M1 CLiC and M1 CDT (basic functions) to be operated from a convenient distance. Equivalent buttons on the remote control have the same functions as those on the front panel of the unit. Other functions are only available by remote control. -
Page 9: Variable And Fixed Outputs
Computer USB input The USB (type ‘b’) input accepts USB digital from a computer directly. It allows the M1 CLiC to act as a top quality sound card via the internal up sampling digital to analogue converter. Please note, on the USB input the HOST COMPUTER controls the audio sent to the M1 CLiC. -
Page 10: Switch On
It will take approx. 15 seconds before anything is seen on the screen, as the unit starts itself up. The Musical Fidelity logo is displayed, then after a few seconds more, the main menu appears and the unit is ready for use (see left). - Page 11 Daylight Saving switches on or off the daylight saving feature (+1 hour, British Summer Time) Show Clock gives current time and date as set in the M1 CLiC. User Interface Language allows menu items to be displayed in local language. Options are English, French, German, Simplified Chinese and Spanish.
-
Page 12: Network Setup
2 bars, on the signal strength meter (see right). Move and position the aerial for best possible reception. External interference and/or signal absorption will still affect performance of the receiver and in extreme cases a wired connection should be considered. M1 CLiC issue 5 Page 12 of 24... -
Page 13: Internet Radio
FM or even DAB! The quality and bit rate is determined by the radio station, and the M1 CLiC will playback at the rate set by the station being received. Some stations do transmit a higher quality service which if available, will be visible on the station list. -
Page 14: Media Server
Media Server The media server function allows playback of music (and pictures) stored on a personal computer connected to the same network as the M1 CLiC The Media server Function requires a connected network. Please ensure that network setup is completed and working before attempting to use media server. -
Page 15: Ipod Rear
Audiobooks lists any audiobooks stored on the iPod® or iPhone®. Using the navigation keys, select the music/audio required. Then scroll through the listings and select the track required. Press OK to start playing. M1 CLiC issue 5 Page 15 of 24... -
Page 16: Usb Front
It can then be plugged into the USB INPUT socket on the front, using original USB cable supplied with the mobile device. It should then be recognized by the USB host controller in the M1 CLiC. Navigation is then the same as with any other USB Drive. See also note below about USB drive formatting. -
Page 17: Inputs
Other Operating systems may have proprietary drivers built-in or available. Please contact the operating system publisher or support for more details. Please note Musical Fidelity do not provide any drivers for any operating system for the USB interface. PC users-... -
Page 18: Problem Solving
Try running fewer applications if possible. If none of these actions affect a cure, please contact the dealer, or an authorised Musical Fidelity service agent. Remember; never open the case of the M1 CLiC, as this will invalidate the guarantee. -
Page 19: Electronic Specifications
N.B. 9-pin D type plug is for factory use only. No features or upgrades available for or from this port. Power requirement Mains voltages 80-253VAC 50/60Hz universal Consumption 25 Watts maximum Display Colour LCD QVGA 320x240 M1 CLiC issue 5 Page 19 of 24... -
Page 20: Software Specifications
(output sampling rate = max 48kHz) Resolution: 16 bit Quality: 8-320 kbit/s Channels: stereo AAC+ v1/HE-AAC Ogg Vorbis 1.0 Supported containers: OGG Support sampling rates: 32-48 kHz Resolution: 16 Bit Quality: Q1-Q10 Tags: Ogg comments/tags Channels: stereo M1 CLiC issue 5 Page 20 of 24... -
Page 21: Software Specifications
M3U An .m3u file is a special type of metafile playlist that is used with Windows Media files that have an .mp3 file extension Via UPnP media server PLS Shoutcast/Winamp format Via UPnP media server M1 CLiC issue 5 Page 21 of 24... -
Page 22: Networking Specifications
Embedded web server for device management and configuration through a web browser on a PC in the local network Status page Configuration page Favourites page Manage favourites stored on device Language support for all device languages Browser compatibility Internet Explorer 7 and 8 Mozilla (Firefox 3) Opera 10 M1 CLiC issue 5 Page 22 of 24... -
Page 23: File Formats And Codecs
Supported containers: WMA Support sampling rates: 8-48 kHz Resolution: 16 Bit Quality: 5-320 kbit /s Tags: WMA tags Channels: stereo/mono WMA-9 lossless and WMA-9 pro Support through transcoding of unprotected tracks by Windows Media Connect only M1 CLiC issue 5 Page 23 of 24... - Page 24 RJ45 UTP cable 10/100 baseT (2 meters) IEC type mains lead (10-Amp type) Musical Fidelity reserves the right to make improvements which may result in specification or feature changes without notice. E&OE. iPod and iPhone are trademarks of Apple Inc., registered in the U.S. and other countries...
