Sony Walkman WM-FX571 Service Manual page 20

Ref. No. Part No. Description
FB706 1-414-235-22 INDUCTOR, FERRITE BEAD
FB707 1-414-235-22 INDUCTOR, FERRITE BEAD
< IC >
IC301 8-759-359-76 IC TA2072AF
IC601 8-759-356-46 IC MM1279XVBE
IC701 8-759-460-25 IC S-8321AJMP-DNJ-T2
< JACK >
J701 1-778-930-21 JACK 7P (2 REMOTE)
J801 1-779-080-11 JACK, DC (POLARITY UNIFIED TYPE)
< JUMPER RESISTOR >
JC801 1-216-296-00 SHORT
< COIL >
L101 1-412-011-31 INDUCTOR CHIP 27uH
L201 1-412-011-31 INDUCTOR CHIP 27uH
L301 1-412-011-31 INDUCTOR CHIP 27uH
L701 1-412-034-11 INDUCTOR CHIP 330uH
< PHOTO INTERRUPTER >
PH701 8-719-988-15 PHOTO INTERRUPTER PR-11-C
< TRANSISTOR >
Q301 8-729-426-51 TRANSISTOR XP1210-TXE
Q302 8-729-422-39 TRANSISTOR XN4404
Q303 8-729-426-36 TRANSISTOR XP1215-TXE
Q304 8-729-230-72 TRANSISTOR 2SA1362YG
Q306 8-729-426-36 TRANSISTOR XP1215-TXE
Q601 8-729-403-42 TRANSISTOR XN1401
Q602 8-729-402-84 TRANSISTOR XN4601
Q701 8-729-421-26 TRANSISTOR UN5216
Q702 8-729-230-72 TRANSISTOR 2SA1362YG
Q704 8-729-425-46 TRANSISTOR XP4315-TXE
< RESISTOR >
R101 1-216-812-11 METAL CHIP
R102 1-216-847-11 METAL CHIP
R103 1-216-831-11 METAL CHIP
R104 1-216-824-11 METAL CHIP
R105 1-216-825-11 METAL CHIP
R107 1-216-795-11 RES,CHIP
R108 1-218-270-11 RES,CHIP
R109 1-216-834-11 METAL CHIP
R110 1-216-852-11 METAL CHIP
R111 1-216-822-11 METAL CHIP
R112 1-216-824-11 METAL CHIP
R113 1-216-809-11 METAL CHIP
R114 1-216-840-11 METAL CHIP
R115 1-218-739-11 RES,CHIP
R151 1-216-864-11 METAL CHIP
Remark Ref. No.
(DC IN 1.5V)
0
180 5% 1/16W
150K 5% 1/16W
6.8K 5% 1/16W
1.8K 5% 1/16W
2.2K 5% 1/16W
6.8 5% 1/16W
1.1K 5% 1/16W
12K 5% 1/16W
390K 5% 1/16W
1.2K 5% 1/16W
1.8K 5% 1/16W
100 5% 1/16W
39K 5% 1/16W
91K 5% 1/16W
0 5% 1/16W
– 33 –
Part No. Description
R201 1-216-812-11 METAL CHIP
R202 1-216-847-11 METAL CHIP
R203 1-216-831-11 METAL CHIP
R204 1-216-824-11 METAL CHIP
R205 1-216-825-11 METAL CHIP
R207 1-216-795-11 RES,CHIP
R208 1-218-270-11 RES,CHIP
R209 1-216-834-11 METAL CHIP
R210 1-216-852-11 METAL CHIP
R211 1-216-822-11 METAL CHIP
R212 1-216-824-11 METAL CHIP
R213 1-216-809-11 METAL CHIP
R214 1-216-840-11 METAL CHIP
R215 1-218-739-11 RES,CHIP
R251 1-216-864-11 METAL CHIP
R301 1-218-891-11 RES,CHIP
R302 1-216-839-11 METAL CHIP
R303 1-216-825-11 METAL CHIP
R304 1-218-295-11 RES,CHIP
R305 1-216-821-11 METAL CHIP
R307 1-216-847-11 METAL CHIP
R309 1-216-826-11 METAL CHIP
R310 1-216-793-11 RES,CHIP
R604 1-216-817-11 METAL CHIP
R605 1-216-830-11 METAL CHIP
R606 1-216-809-11 METAL CHIP
R607 1-216-837-11 METAL CHIP
R611 1-216-821-11 METAL CHIP
R612 1-216-833-11 RES,CHIP
R701 1-216-849-11 METAL CHIP
R702 1-216-849-11 METAL CHIP
R703 1-216-845-11 METAL CHIP
R704 1-216-821-11 METAL CHIP
R705 1-216-821-11 METAL CHIP
R706 1-216-843-11 METAL CHIP
R707 1-216-843-11 METAL CHIP
R708 1-216-849-11 METAL CHIP
R709 1-216-857-11 METAL CHIP
R710 1-216-823-11 METAL CHIP
R711 1-216-829-11 METAL CHIP
R712 1-216-849-11 METAL CHIP
R713 1-216-821-11 METAL CHIP
R714 1-216-821-11 METAL CHIP
R715 1-216-821-11 METAL CHIP
< NETWORK RESISTOR >
RB301 1-233-872-21 RES, NETWORK (CHIP TYPE) 33K (3216)
RB601 1-233-873-21 RES, NETWORK (CHIP TYPE) 220K (3216)
RB602 1-233-576-11 RES, NETWORK (CHIP TYPE) 100
< VARIABLE RESISTOR >
RV301 1-225-342-23 RES, VAR, CARBON 10K/10K (VOLUME)
RV601 1-223-576-11 RES, ADJ, METAL GLAZE 2.2K
AUDIO
Remark
180 5% 1/16W
150K 5% 1/16W
6.8K 5% 1/16W
1.8K 5% 1/16W
2.2K 5% 1/16W
6.8 5% 1/16W
1.1K 5% 1/16W
12K 5% 1/16W
390K 5% 1/16W
1.2K 5% 1/16W
1.8K 5% 1/16W
100 5% 1/16W
39K 5% 1/16W
91K 5% 1/16W
0 5% 1/16W
68K 0.50% 1/16W
33K 5% 1/16W
2.2K 5% 1/16W
43K 5% 1/16W
1K 5% 1/16W
150K 5% 1/16W
2.7K 5% 1/16W
4.7 5% 1/16W
470 5% 1/16W
5.6K 5% 1/16W
100 5% 1/16W
22K 5% 1/16W
1K 5% 1/16W
10K 5% 1/16W
220K 5% 1/16W
220K 5% 1/16W
100K 5% 1/16W
1K 5% 1/16W
1K 5% 1/16W
68K 5% 1/16W
68K 5% 1/16W
220K 5% 1/16W
1M 5% 1/16W
1.5K 5% 1/16W
4.7K 5% 1/16W
220K 5% 1/16W
1K 5% 1/16W
1K 5% 1/16W
1K 5% 1/16W
