The Model Tech Apex 3D EP ARF is designed for one thing: Electric Flying Fun! A cross between a stick and a 3D airplane, the Apex
3D EP ARF is light, nimble, responsive, and solid. No matter how wild the maneuver, just release input and watch it straighten up,
making recovery easy. The light wing loading provides that quick response and allows for great low-speed handling. Soloed pilots
to wold champions can set this airplane up for anything from Mild-to-Wild.
The APEX is a great time. It's the Peak of Fun, the APEX by Model Tech.
Check out our website for more information on this and other exciting Model Tech products!
The Model Tech Apex 3D EP ARF is distributed
exclusively in North America by Global Hobby Distributors
and in the U.K. by YT International
All Contents Copyright © 2006, Global Hobby Distributors
Version 1 December 2006
Wing span: 43.375 Inches (1102mm)
Weight rTf: 2.1-2.4 Pounds (34-38oz)
Motor required: 200-400 Watt Power System
Made in China
HTTP://MODELTECH.GLOBALHOBBY.COM
ASSEMBLY INSTRUCTIONS
sPECifiCATiONs
Wing Area: 600 Square Inches (38.7dm
●
●
functions: Ailerons, Elevator, Rudder and Throttle
EsC required: 40 Amp Brushless
●
Precision-Built, All-Wood Structure
●
Ultra-Lightweight Wing Loading and Over-Sized Control Surfaces
●
Motor Installation Allows for Easy Mounting of Different Motor Types
●
Premium, Factory-Applied Covering with Four-Color Decal Sheet
●
Dual Aileron Servos for Precise Control and Mixing Capabilities
●
Includes High-Quality Hardware
●
Fast and Easy Assembly - Over 60 High-Resolution Digital Photos and Drawings
●
Wing Loading: 8.17-9.14 Ounces/Square Foot (28-32gr/dm
Page
fEATurEs
2
)
Length: 43.5 Inches (1105mm)
●
2
)
Battery required: 3 Cell 2100mAH LiPO
●
Kit Product Number 128508
Advertisement
Table of Contents
Related Manuals for Model Technology Apex 3D EP ARF
Summary of Contents for Model Technology Apex 3D EP ARF
- Page 1 The Model Tech Apex 3D EP ARF is designed for one thing: Electric Flying Fun! A cross between a stick and a 3D airplane, the Apex 3D EP ARF is light, nimble, responsive, and solid. No matter how wild the maneuver, just release input and watch it straighten up, making recovery easy.
-
Page 2: Table Of Contents
Thank you for purchasing the Model Tech Apex 3D EP ARF. We're confident that the quality of your new airplane meets and even exceeds your expectations. Before completing the final assembly of your new airplane, please carefully read through these assembly instructions in their entirety. -
Page 3: Customer Service Information
4.4:1 gearbox, APC 10 x 7E propeller, KMS Sentry 40 amp brushless ESC, and Impulse Power 3C 2100mAH LiPO battery. The Apex 3D EP ARF, however, is set up so that both in-line gearbox and Outrunner direct drive motors can easily be used. These motors... -
Page 4: Lithium Polymer Battery Warnings - Please Read
LiTHiuM POLYMEr BATTErY WArNiNGs - PLEAsE rEAD WARNINGS AND SAFETY PRECAUTIONS FOR ALL BRANDS OF LITHIUM POLYMER BATTERIES Please read and understand the warnings listed in this section. Make sure to read any and all warnings included in the packaging with your battery, too. If used improperly, lithium polymer batteries can be very dangerous, so please follow these warnings and suggestions at all times. -
Page 5: Tools And Supplies Required
TOOLs AND suPPLiEs rEQuirED ❑ 5 Minute Epoxy ❑ T-Pins ❑ Thin and Thick C/A ❑ Builder's Triangle ❑ # 1 and # 2 Phillips Head Screwdrivers ❑ 220 Grit Sandpaper with Sanding Block ❑ 1.5mm Hex Wrench (Optional) ❑ Masking Tape ❑... -
Page 6: A Note About Covering Material
MOTOr MOuNT AssEMBLY ❑ (2) Motor Mount Straps - Tall ❑ (2) Motor Mounts Straps - Short ❑ (4) M3 x 12mm Wood Screws MisCELLANEOus PArTs ❑ (2) Wing Hold-Down Dowels ❑ (1) Wing Hold-Down Doubler ❑ (1) Hook and Loop Material ❑... -
Page 7: Motor Installation
MOTOr iNsTALLATiON YOu'LL NEED THE fOLLOWiNG PArTs frOM THE KiT: ❑ (1) Fuselage ❑ (2) Motor Mount Straps - Short ❑ (2) Motor Mount Straps - Tall ❑ (4) M3 x 12mm Wood Screws YOu'LL NEED THE fOLLOWiNG TOOLs AND suPPLiEs: ❑... -
Page 8: Wing Installation
❑ Set the motor mounting straps and your motor back into place and realign them. ❑ Place the remaining two motor mounting straps over the motor and secure the assembly into place, using four M3 x 12mm wood screws. ☞ Tighten the wood screws firmly, yet evenly, to clamp the motor securely in place. - Page 9 ❑ Cut away the covering material from within the outline you drew, then glue the wing hold-down doubler into place. IMPORTANT Glue does not stick well to covering material. To ensure the strongest bond, always make sure to remove the covering material from the gluing surfaces before gluing the parts together.
-
Page 10: Stabilizer Installation
sTABiLiZEr iNsTALLATiON YOu'LL NEED THE fOLLOWiNG PArTs frOM THE KiT: ❑ (1) Vertical Stabilizer with Rudder ❑ (1) Horizontal Stabilizer with Elevator YOu'LL NEED THE fOLLOWiNG TOOLs AND suPPLiEs: ❑ 5 Minute Epoxy ❑ 220 Grit Sandpaper with Sanding Block ❑... - Page 11 ❑ With the wing mounted to the fuselage and centered, measure the distance between the tips of the stabilizer and the tips of the wing. Pivot the front of the stabilizer until both of these measurements are equal. ☞ When both of these measurements are equal, you're assured that the stabilizer is square to the wing.
- Page 12 ❑ Apply a generous amount of 5 minute epoxy to the gluing surfaces of both the stabilizer and the fuselage, then push the stabilizer into place and realign it, double-checking all of your measurements once more before the epoxy sets up. Remove any excess epoxy and use T-Pins to hold the stabilizer in place and aligned until the epoxy has fully cured.
-
Page 13: Elevator And Rudder Control Systems Installation
ElEvAToR AnD RUDDER conTRol SySTEMS inSTAllATion YOu'LL NEED THE fOLLOWiNG PArTs frOM THE KiT: ❑ (2) Nylon Clevises ❑ (1) 5-1/2" (140mm) Threaded Wire with Z-Bend ❑ (1) 4-1/8" (105mm) Threaded Wire with Z-Bend ❑ (4) M2 x 10mm Machine Screws ❑... - Page 14 ❑ Install the control horn and backplate, using two M2 x 10mm machine screws. ❑ Cut away all but one arm from a "4-point" servo horn, then install the Z-Bend in the 4-1/8" (105mm) long pushrod wire into the outermost hole in the servo arm.
-
Page 15: Aileron Control Systems Installation
❑ Install the servo horn retaining screw to secure the servo horn to the servo. ❑ With both the rudder servo horn and the rudder centered, thread one nylon clevis onto the pushrod wire and snap the clevis into the outermost hole in the control horn. -
Page 16: Landing Gear Installation
sTEP 2: iNsTALLiNG THE AiLErON CONTrOL LiNKAGE AssEMBLiEs ❑ Position and install one control horn onto the bottom of one aileron, using the same techniques that you used to install both the elevator and the rudder control horns. When aligned properly, the centerline of the control horn should be 4-1/2"... - Page 17 ❑ Test-fit and glue the tail skid into place, using a generous amount of glue. ☞ Make sure that the tail skid faces toward the back of the fuselage and that it's lined up straight with the bottom of the rudder. sTEP 2: iNsTALLiNG THE LANDiNG GEAr WirEs ❑...
-
Page 18: Final Assembly
❑ Slide one wheel onto each axle and secure the wheels into place, using one wheel collar and one M3 x 5mm machine screw. ☞ Tighten the machine screws firmly, then double-check that both wheels spin freely. fiNAL AssEMBLY YOu'LL NEED THE fOLLOWiNG PArTs frOM THE KiT: ❑... -
Page 19: Balance Point And Control Throws
❑ Drill a 5/64" (2mm) diameter hole through the bottom of the fuselage for the antenna to exit, then run the antenna out and along the bottom of the fuselage. Use pieces of clear tape to secure it into place along the length of the fuselage. Do not cut the antenna shorter. -
Page 20: Preflight Check And Safety
PrEfLiGHT CHECK AND sAfETY Check the operation of the throttle. Double-check that you're getting full power when the throttle control stick is at full. ● ☞ If you're using a computer radio, you may need to increase your throttle channel's EPA setting to result in full power. (Refer to your radio system's operating guide for further information.) Check the condition of the transmitter batteries. - Page 21 If you liked the Model Tech Apex 3D EP ARF, here's a few of the many other Model Tech ARF airplanes that are currently available: Mini Magic Extra ARF (P/N 123661) (MT3192D-5) Inspired by it's larger brother, the Magic Extra, this smaller version has the...
- Page 22 THIS PAGE INTENTIONALLY LEFT BLANK Page ...
-
Page 23: Product Evaluation Sheet
Your privacy is important to us. 7) Was any of the assembly difficult for you? If yes, please explain. 1) Kit: Model Tech Apex 3D EP Arf # 128508 ❑ Yes ❑ No... - Page 24 _______________________________ _______________________________ Post office will not deliver _______________________________ without proper postage (Return Address Here) Global Hobby Distributors Attn: Global services 18480 Bandilier Circle Fountain Valley CA 92728-8610 fold along dotted line Page ...
