OPERATOR'S MANUAL
FOR YOUR
DG SERIES
GENERATOR
MODEL
__________
SERIAL #
__________
BALDOR GENERATORS
3815 Oregon Street, Oshkosh WI 54902
Phone 1-800-USA-POWR • Fax 920-236-4219
FORM#: S-PSG-002-11
EFFECTIVE DATE: 4/4/97
DIESEL (DG) COVER\MSW'00
REVISION DATE: 3/14/03

Advertisement

loading
Need help?

Need help?

Do you have a question about the DG Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Baldor DG Series

  • Page 1 OPERATOR'S MANUAL FOR YOUR DG SERIES GENERATOR MODEL __________ SERIAL # __________ BALDOR GENERATORS 3815 Oregon Street, Oshkosh WI 54902 Phone 1-800-USA-POWR • Fax 920-236-4219 FORM#: S-PSG-002-11 EFFECTIVE DATE: 4/4/97 DIESEL (DG) COVER\MSW'00 REVISION DATE: 3/14/03...
  • Page 2 DO NOT OPERATE THIS GENERATOR SET UNTIL YOU CAREFULLY READ THIS MANUAL AND UNDERSTAND THE SAFETY WARNINGS AND INSTRUCTIONS CONTAINED IN IT. While safety is built into every Baldor Pow'R Gard generator set, careless or improper operation could possibly result in mechanical failure, property damage, severe injury or even death.
  • Page 3 SAFETY WARNINGS ♦ Place protective covers and guards over the rotating parts, if rotating parts such as the drive shaft, pulley, belt, etc. are left exposed, they are potentially hazardous. ♦ When cleaning, repairing or inspecting, make sure all moving parts have stopped. ♦...
  • Page 4 SAFETY WARNINGS ♦ Never permit anyone to operate the generator set without proper instructions. ♦ Never allow children to operate the generator set. ♦ Children and pets must be kept away from the area of operation due to the possibility of burns from hot engine components or injury from any equipment the generator set is powering.
  • Page 5 SAFETY WARNINGS ♦ Always treat the electrical circuits as if they were energized. ♦ Disconnect all leads plugged into the unit Prior to working on it. ♦ Have the electrical circuits serviced only by qualified technicians. ♦ Inspect wiring frequently and replace frayed, broken or poor leads. ♦...
  • Page 6 Operation inside an enclosed compartment or building is a potential fire hazard and should not be done unless approval is obtained from Baldor Generators. Engine/Generator overheating can cause severe damage due to restricted, obstructed or improper air-flow that is necessary for the proper cooling of the unit.
  • Page 7: Table Of Contents

    TABLE OF CONTENTS SECTION PAGE Basic Location Information………………………………………………………………………………………..1 Basic Connection Information…………………………………………………………………………………..2 Basic Engine Information……………………………………………………………………………………………..3 Generator End Maintenance…………………………………………………………………………………………..4 Basic Engine Maintenance……………………………………………………………………………………………..5 Electric Motor Loads………………………………………………………………………………………………………..6 Parts & Service Information……………………………………………………………………………………..7 Operation……………………………………………………………………………………………………………………………………..8 Simple Troubleshooting…………………………………………………………………………………………………..10 Control Panel for DG3E…………………………………………………………………………………………………..12 Control Panel for DG5E, DG6E, DG8E…………………………………………………………………..13 Parts Breakdown: DG3E……………………………………………………………………………………………………..16 Parts Breakdown: DG5E……………………………………………………………………………………………………..19 Parts Breakdown: DG6E……………………………………………………………………………………………………..22...
  • Page 8: Basic Location Information

    LOCATION For best service from your portable generator set there are several factors, which should be taken into consideration when choosing the best location in which to operate it: MOISTURE: All electrical equipment should be protected from excessive moisture. Failure to do so will result in deterioration of the insulation and may result in short circuits and a possible electrocution hazard.
  • Page 9: Basic Connection Information

    CONNECTIONS WIRING: Use sufficiently large insulated wire to connect the generator set to the load. The gauge of the wire will depend largely on the distance, the permissible voltage drop, and the size and type of load. If you are not sure of the gauge wire needed for your application, consult a competent electrician.
  • Page 10: Basic Engine Information

    ENGINE INFORMATION This operator's manual only covers basic day-to-day engine operating instructions. However, the engine manufacturer's manual is included with your generator set and should be referred to for any additional information you may need. Become familiar with and follow all the engine manufacturer's operation, safety and maintenance guidelines.
  • Page 11: Generator End Maintenance

    MAINTENANCE MAINTENANCE SHOULD ONLY BE PERFORMED ON THE GENERATOR SET AFTER THE ENGINE HAS STOPPED AND THE GENERATOR SET HAS COOLED DOWN. THE BATTERY AND SPARK PLUG SHOULD ALSO BE DISCONNECTED PRIOR TO PERFORMING MAINTENANCE. GENERATOR END MAINTENANCE Generator end maintenance consists of cleaning the generator set, inspecting the wiring and fuel system, and making any necessary adjustments.
  • Page 12: Basic Engine Maintenance

    ADJUSTMENTS: √ The engine should be checked for proper speed setting(s). √ Prior to adjusting the engine speed, turn the auto idler switch off (if your generator set is equipped with this feature). Adjust the engine speed to 3720 RPM's (62 Hertz) with no load applied to the generator set.
  • Page 13: Electric Motor Loads

    STORAGE If you will not be using the generator set for a significant amount of time (3 months or longer) you should store the generator to prevent any problems that could arise from sitting idle. Please fully read the following guidelines prior to storing the unit. Remove all fuel from the engine's fuel tank.
  • Page 14: Parts & Service Information

    NOTE: Engine parts can usually be obtained from a local representative of your engine manufacturer via the information in the engine manufacturer’s owner’s manual. Baldor generator can obtain engine parts if necessary. However we do not stock engine parts nor are we a dealer in engine parts.
  • Page 15: Operation

    OPERATION PRIOR TO STARTING THE UNIT: 1. Locate and set up the generator set in an open, dry, well ventilated and reasonably level location. OPERATING THIS UNIT IN AN AREA NOT SUITABLE FOR IT'S PROPER USE MAY CAUSE DAMAGE TO THE UNIT, SEVERE INJURY, OR DEATH. SEE "LOCATION INFORMATION"...
  • Page 16 STOPPING THE ENGINE: 1. Disconnect or 'Turn Off' all loads connected to the generator set. 2. Turn any engine 'On/Off' switches to the 'Off' position (On DG3E units, put the run/stop lever in the stop position). 3. Push engine 'Stop' switch if so equipped. 4.
  • Page 17: Simple Troubleshooting

    Listed below are the more simple solutions to some of the more common problems that are reported to the Customer Services Department at Baldor Generators of Oshkosh. These troubleshooting solutions are meant to be an aid for a person who has minimal electrical knowledge and experience.
  • Page 18 Stop the unit after doing this and replace the end cover. If you still have no output, look for other reasons or contact the Technical Support Department at Baldor Generators. (920-236-4200).
  • Page 19: Control Panel For Dg3E

    CONTROL PANEL For the DG3E A = NEMA 515R GFCI DUPLEX. This receptacle is a ground fault circuit interrupter duplex rated at 125 VAC., 20 Amps. This receptacle must be tested on a regular basis (Monthly). B = NEMA L530R RECEPTACLE. This is a twist-lock style receptacle rated for 125 VAC, 30 Amps.
  • Page 20: Control Panel For Dg5E, Dg6E, Dg8E

    CONTROL PANEL For DG5E and DG6E Units A = THE START SWITCH. Pushing this button engages the starter motor. B = THE RUN SWITCH. When this switch is in the 'ON' position the engine will start and run once the start switch is engaged. When this switch is turned "OFF' the engine will shut down.
  • Page 21 GENERATOR END COMPONENTRY For DG3E Generator sets - 14 -...
  • Page 22 CONTROL BOX COMPONENTRY For DG3E Generator Sets - 15 -...
  • Page 23: Parts Breakdown: Dg3E

    PARTS BREAKDOWN FOR DG3E Units: REF LETTER OLD PART # NEW PART # DESCRIPTION 46.03002B 61SA0016A07* Stator assembly 66.03002 61RA0017A00 Rotor Assembly- 2 3/8" brushless 230.02020 10XN3124K12 Bolt, Rotor attaching 230.06040 10XN3816K20 * Bolt, Engine Adaptor Casting 230.12010 84XN1032L10SP Bolt, Fan Attaching 340.00000 61FN3000SP Cooling Fan, RTP 105...
  • Page 24 GENERATOR END COMPONENTRY For DG5E Generator sets - 17 -...
  • Page 25 CONTROL BOX COMPONENTRY For DG5E Generator Sets - 18 -...
  • Page 26: Parts Breakdown: Dg5E

    PARTS BREAKDOWN FOR DG5E Units: REF LETTER OLD PART # NEW PART # DESCRIPTION 46.00055 61SA0021A04SP Stator assembly 66.00055 61RA0015A00 Rotor Assembly- 2 3/8" brushless 560.70020 WD1541A33SP Receptacle, GFCI, Black, 250 V MOV 560.10025 WD1541A10SP Receptacle, L530R Twistlock 230.02025 10XN3124l12* Bolt, Rotor attaching 560.10090 WD1541A14SP...
  • Page 27 GENERATOR END COMPONENTRY For DG6E Generator sets - 20 -...
  • Page 28 CONTROL BOX COMPONENTRY For DG6E Generator Sets - 21 -...
  • Page 29: Parts Breakdown: Dg6E

    PARTS BREAKDOWN FOR DG6E Units: REF LETTER OLD PART # NEW PART # DESCRIPTION 46.10055J 61SA0021A04* Stator assembly 66.00055 61RA0015A00 Rotor Assembly- 4.25' brushless 2 Pole 560.70020 WD1541A33SP Receptacle, GFCI, Blac, 250V MOV 560.10025 WD1541A10SP Receptacle, L530R 230.02025 10XN3124L12* Bolt, Rotor attaching 560.10090 WD1541A14SP Receptacle, NEMA L14-30R...
  • Page 30: Connection Diagram: Dg3E

    DG3E CONNECTION DIAGRAM - 23 -...
  • Page 31: Connection Diagram: Dg3E Remote Start/Stop

    DG3E CONNECTION DIAGRAM W/ LOW OIL & REMOTE START - 24 -...
  • Page 32: Connection Diagram: Dg5E Generator/Control Box

    DG5E GENERATOR/CONTROL BOX CONNECTION DIAGRAM - 25 -...
  • Page 33: Connection Diagram: Dg5E Receptacle/Control Box

    DG5E RECEPTACLE/CONTROL BOX CONNECTION DIAGRAM - 26 -...
  • Page 34: Wiring Diagram: Dg5-Er

    DG5-ER WIRING DIAGRAM - 27 -...
  • Page 35: Wiring Diagram: Dg6E Hatz/Robin

    DG6E HATZ/ROBIN CONNECTION DIAGRAM - 28 -...
  • Page 36: Warranty Information

    Baldor product upon its return to the party requiring warranty service. Customers who are unable to take or ship the Baldor product to a Baldor Generator repair facility, or who desire a repair to be made by other than a Baldor Generator repair facility, should contact Baldor Generators’ Customer Service Department at 920-236-4200.
  • Page 37: Warranty Period

    The owner is obligated to operate and maintain the generator in accordance with the recommendations published by Baldor Generators in the Operator’s Manual for the generator. The owner is responsible for the costs associated with maintenance and any adjustments that may be required.
  • Page 38 Limitations: Baldor Generators is not responsible for the repair of generators required because of normal wear, accident, misuse, abuse, improper installation, lack of maintenance, unauthorized modifications or improper storage. Normal Wear: This warranty will not cover repair where normal use has exhausted the life of a part or generator. It should be remembered that the service life of any generator is dependent on the care it receives and the conditions under which it has to operate.
  • Page 39: California Proposition 65 Warning

    CALIFORNIA PROPOSITION 65 WARNING Engine exhaust from this product contains chemicals known to the state of California to cause cancer, birth defects, and other reproductive harm. CALIFORNIA PROPOSITION 65 WARNING Diesel engine exhaust and some constituents are known to the state of California to cause cancer, birth defects, and other reproductive harm.
  • Page 40 Service is just a phone call away: 800-872-7697 www.baldor.com/products/generators.asp 3815 Oregon Street Oshkosh WI 54902 Phone: (920) 236-4200 Fax: (920) 236-4219...
