  • Page 1 SL ePAR 180 LED Luminaire...
  • Page 2 SL ePAR 180 User’s Manual 24-004-3564-00 Rev1.0 SL ePAR 180 LED Luminaire installation & User’s Manual 2013 Philips Group. All rights reserved.

  • Page 3: Warnings And Notices

    SL ePAR 180 LED Luminaire Installation & User’s Manual You must have access to a mains circuit breaker or other power disconnect device mains circuit breaker off before installation. Installing the device with power on may expose you to Additional Resources for DMX512 For more information on installing DMX512 control systems, the following publication is available for purchase from the United States Institute for Theatre Technology (USITT), "Recommended Practice for DMX512: A Guide...

  • Page 4: Table Of Contents

    SL ePAR 180 LED Luminaire DMX Mapping 16-Bit Mode 8-Bit Mode HSIC Mode DMX Timing Channel Detail RDM PARAMETER IDs SL ePAR 180 LED Luminaire RDM Parameter IDs CLEANING AND CARE Special Cleaning and Care Instructions Front Lens Cleaning Service and Maintenance Accessories...

  • Page 5: Preface

    Please read all instructions before installing or using this product. Retain this manual for future reference. Additional product information and descriptions may be found on the product specification sheet. Note: The SL ePAR 180 LED Luminaire is universal voltage 100 to 240 VAC (auto-ranging). Included Items...

  • Page 6: Sl Epar 180 Led Luminaire Overview

    AC Power Input Menu System High Intensity LED Array Truss Hook / Clamp Attachment Point Accessory Holder Clip Accessory Holder Yoke (Tilt) Position Locking Handle Luminaire Head Assembly Figure 1: SL ePAR 180 LED Luminaire Components SL ePAR 180 LED Luminaire Overview...

  • Page 7: Lcd Display/Menu System

    INSTALLATION AND SET UP Power Requirements The SL ePAR 180 LED Luminaire operates on AC input voltages from 100 to 240 VAC. WARNING! This luminaire does not contain an ON/OFF switch. Always disconnect the power input cable to completely remove power from the luminaire when not in use.

  • Page 8: Connecting Power

    Basic DMX512 installation consists of connecting multiple SL ePAR 180 LED Luminaires together (up to 32 luminaires) in a "daisy-chain" fashion. A cable runs from the control console (or DMX512 control source) to the DMX connector on first SL ePAR 180 LED Luminaire. Another cable runs from the other DMX connector on the first luminaire to...

  • Page 9: Mounting Luminaire

    Figure 4: SL ePAR 180 LED Luminaire - DMX512 Connections Mounting Luminaire Floor Mounting The SL ePAR 180 LED Luminaire is designed to sit directly on its yoke assembly in a floor installation application. When used in this type of application, loos...

  • Page 10: Truss/Hanging Applications

    SL ePAR 180 LED Luminaire menu structure, see "SL ePAR 180 LED Luminaire Menu Tree" on page 11. Upon power up, the LCD will display the main screen display menu of SL ePAR 180 LED Luminaire. Press “ ” or “ ” to select the press “OK” to enter the desired function menu.

  • Page 11: Lcd Display And Menu System Operation

    SL ePAR 180 LED Luminaire Installation & User’s Manual LCD Display EXIT Button ENTER Button LEFT Arrow Button RIGHT Arrow Button Figure 7: LCD Display and Menu System 2. LCD Display and Menu System Operation The LCD Display Menu system consists of several categories. Upon power up, the LCD will display the main menu automatically.
  • Page 12 Once at the desired menu, use the LEFT and RIGHT arrow buttons to check the related fixture information. Note: For more information about Preset, Colour Filter, Chase, Strobe/Timing, Settings and Status, please refer to “SL ePAR 180 LED Luminaire Menu Tree” on page 11. LCD Display and Menu System Operation...

  • Page 13: Sl Epar 180 Led Luminaire Menu Tree

    SL ePAR 180 LED Luminaire Installation & User’s Manual 3. SL ePAR 180 LED Luminaire Menu Tree Figure 8: SL ePAR 180 LED Luminaire Menu Tree SL ePAR 180 LED Luminaire Menu Tree...

  • Page 14: Dimming Curve Selection

    Installation & User’s Manual SL ePAR 180 LED Luminaire Figure 8: SL ePAR 180 LED Luminaire Dimmer Curves Dimming Curve Selection...

  • Page 15: Master / Slave Operational Mode

    SL ePAR 180 LED Luminaire The Master / Slave Operational Mode allows one SL ePAR 180 LED Luminaire to act as the “Master” luminiare and all other connected luminaires are controlled by this luminaire. When a luminaire is set to “Slave”...

  • Page 16: Dmx Control

    Table 3 provides DMX channel mapping of all DMX512 control values when the SL ePAR 180 LED Luminaire is in 16-bit DMX512 mode (as set by the luminaires’ menu system). Table 3: SL ePAR 180 LED Luminaire DMX Channel Mapping (16-Bit Mode) Select presets, variable colour filters or chases...
  • Page 17 SL ePAR 180 LED Luminaire Installation & User’s Manual Table 3: SL ePAR 180 LED Luminaire DMX Channel Mapping (16-Bit Mode) Select presets, variable colour filters or chases as follows: Colour Presets DMX Control...

  • Page 18: 8-Bit Mode

    Installation & User’s Manual SL ePAR 180 LED Luminaire Table 3: SL ePAR 180 LED Luminaire DMX Channel Mapping (16-Bit Mode) Allows for timing control of intensity. Channel should default to 255 for smoothest actions using console and/or manual fades.
  • Page 19 SL ePAR 180 LED Luminaire Installation & User’s Manual Table 4: SL ePAR 180 LED Luminaire DMX Channel Mapping (8-Bit Mode) Select presets, variable colour filters or chases as follows: Colour Presets SL ePAR 180 LED Luminaire DMX Mapping...
  • Page 20 Installation & User’s Manual SL ePAR 180 LED Luminaire Table 4: SL ePAR 180 LED Luminaire DMX Channel Mapping (8-Bit Mode) Select presets, variable colour filters or chases as follows: Colour Presets Functions DMX CONTROL...

  • Page 21: Hsic Mode

    Table 5 provides DMX channel mapping of all DMX512 control values when the SL ePAR 180 LED Luminaire is in HSIC (Hue, Saturation, Intensity, and Colour Correction) DMX512 mode (as set by the luminaires’ menu system). Table 5: SL ePAR 180 LED Luminaire DMX Channel Mapping (HSIC Mode) zoom Functions...
  • Page 22 Installation & User’s Manual SL ePAR 180 LED Luminaire Table 6: SL ePAR 180 LED Luminaire Timing Channel Detail DMX TIMING CHANNEL DETAIL...
  • Page 23 SL ePAR 180 LED Luminaire Installation & User’s Manual Table 6: SL ePAR 180 LED Luminaire Timing Channel Detail DMX TIMING CHANNEL DETAIL...
  • Page 24 Installation & User’s Manual SL ePAR 180 LED Luminaire Table 6: SL ePAR 180 LED Luminaire Timing Channel Detail DMX CONTROL...
  • Page 25 SL ePAR 180 LED Luminaire Installation & User’s Manual Table 6: SL ePAR 180 LED Luminaire Timing Channel Detail DMX TIMING CHANNEL DETAIL...
  • Page 26 Installation & User’s Manual SL ePAR 180 LED Luminaire Table 6: SL ePAR 180 LED Luminaire Timing Channel Detail DMX Timing Channel Detail...
  • Page 27 SL ePAR 180 LED Luminaire Installation & User’s Manual Table 6: SL ePAR 180 LED Luminaire Timing Channel Detail 120mS DMX Timing Channel Detail...

  • Page 28: Rdm Parameter Ids

    Table 8, “SL ePAR 180 LED Luminaire RDM UID” Table 9, “SL ePAR 180 LED Luminaire RDM Parameters IDs” Table 10, “SL ePAR 180 LED Luminaire RDM Manufacturer Status IDs”, on page 28 Table 11, “SL ePAR 180 LED Luminaire RDM Manufacturer Specific PIDs”, on page 28 Table 7: SL ePAR 180 LED Luminaire RDM Product Parameters IDs Unique Seq.
  • Page 29 SL ePAR 180 LED Luminaire Installation & User’s Manual Table 9: SL ePAR 180 LED Luminaire RDM Parameters IDs RDM PARAMETER IDS...
  • Page 30 Installation & User’s Manual SL ePAR 180 LED Luminaire Table 9: SL ePAR 180 LED Luminaire RDM Parameters IDs Table 10: SL ePAR 180 LED Luminaire RDM Manufacturer Status IDs Table 11: SL ePAR 180 LED Luminaire RDM ManufacturerSpecific PIDs 8A00H...

  • Page 31: Sl Epar 180 Led Luminaire Rdm Parameter Ids

    This section covers portions of the luminaire that can be removed for cleaning. The SL ePAR 180 LED Luminaire requires special care when it comes to cleaning the front lens assembly. Additional care needs to be taken with the plastic components because they are much easier to scratch or damage than the glass lenses used in traditional luminaires.

  • Page 32: Cleaning And Care

    Installation & User’s Manual SL ePAR 180 LED Luminaire Only Showline approved accessories should be used with your SL ePAR 180 LED Luminaire. For a list of available accessories from Showline, please see “Accessories” on page 3. For questions regarding accessories, please contact your local Authorized Showline Dealer or Showline office.

  • Page 33: Operational Specifications

    SL ePAR 180 LED Luminaire Installation & User’s Manual Colour RGB+Cool White Array (x19 High Power LEDs) 21 Degrees > 4,400 lumens 2700 - 10,000K (user adjustable) 1.80 Amps (100V) / 0.75Amps (240V) 180 Watts (max.) 35~85RH% Weight: 9.9 lbs(4.5 kg) - Luminaire only (no accessories)

  • Page 34: Luminaire Dimensions

    Installation & User’s Manual SL ePAR 180 LED Luminaire Luminaire Dimensions(mm) Luminaire Dimensions...
  • Page 35 SL ePAR 180 LED Luminaire Installation & User’s Manual NOTE NOTE...
