Technical Information
Features
5.1system : A perfect acoustic effect could be reached if connected to the audio source with AC-3
or DTS decoder.
＂ ＂
6.5 subwoofer : 6.5 subwoofer unit made of dual Sr Magnet system blazes the trail in the use
of costly low-Q value, long-stroke program design, having the low-frequency quality of quick and high
resolution.
EAirbass: eAirbass creates no distortion when enhancing bass. With brandnew airflow passage
design, it delivers clearer sound with an extended frequency range. The use of electronic control
technology enables a precise bass signal selection for enhanced bass delivery and crystal clear high
notes reproduction. Moreover the sychronous phase control technology guarantees accurate bass
delivery, providing an effective solution for slow frequency response.
Specification
*Amplifier specification:
AC IN 220V-240V~ 50Hz 800mA
Power output 60W+15Wx5 RMS
Frequency response Woofer 30 Hz-130Hz
Satellite 130 Hz-20kHz
Sensitivity input 420mV
Distortion <0.3%(1W 1KHz)
Separation >50dB
S/N >75 dB
*Driver unit: (Woofer Speaker )6.5"
(Satellite Speaker)2"x5(magnetically shielded)
*Audio input: RCA jacks
*Audio output: RCA jacks
* Product size(WxDxH): Woofer Speaker 220 x360x325mm
Center Speaker 159x64x65mm
Satellite Speaker 102x90x193mm
5
the apparatus is left unused for a long period of time.
－
20.Serving Do not attempt to service this product yourself, as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.
－
21.Replacement parts When replacement parts are required, be sure the service technician has used replacement parts
specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may
result in fire, electric shock or other hazards.
－
22.Mains fuses For continued protection against fire hazard, use fuses only of the correct type and rating. The correct fuse
specification for each voltage range is marked on the product.
23.Do not turn up the volume while listening to a section with very low level inputs or no audio signals. If you do, the
speaker may be damaged when a peak level section is suddenly played.
24.The only means of completely disconnecting the product from the power supply is by removing the power cord from the
wall outlet or the product. Either the wall outlet or the power cord entry to the product must remain freely accessible at all
times while the apparatus is in use.
Unpacking the system
Unpacking:
*Fold the carton flaps right back and invert the carton and contents.
*Lift the carton clear of the contents.
*Remove the inner packing from the product.
We suggest you retain the packing for future use.
You should find following items while unpacking:
Subwoofer 1pc
Center speaker 1pc
Satellite speakers 4pcs
Satellite stands(plastic) 4pcs
Remote control 1pc
Batteries 2pcs
Audio cables(2RCA-2RCA) 3pcs
Audio cable(3.5mm-2RCA) 1pc
User manual 1pc
* Metal stands of satellite: this accessory is optional. If you have not order it at the time buying, then
this packing does not include it
