SERVICE MANUAL
Colour Television
The above models are classified as either green products (*1) or non-green products. Green product(s) are
indicated by an underlined serial number. This Service Manual describes replacement parts for green
product(s). When repairing any green product(s), use the parts described in this manual and lead-free solder
(*2).
For (*1) and (*2), see the next page.
Use this Service Manual in conjunction with the original Service Manual (File No.020-200509) for 62HMX85.
© TOSHIBA SINGAPORE PTE LTD
62HMX85
FILE NO. 023-2006171GR
SUPPLEMENT
Pubished in Singapore Feb. 2005 Green
Advertisement
Table of Contents
Related Manuals for Toshiba 62HMX85
Summary of Contents for Toshiba 62HMX85
-
Page 1: Service Manual
When repairing any green product(s), use the parts described in this manual and lead-free solder (*2). For (*1) and (*2), see the next page. Use this Service Manual in conjunction with the original Service Manual (File No.020-200509) for 62HMX85. Pubished in Singapore Feb. 2005 Green © TOSHIBA SINGAPORE PTE LTD... -
Page 2: Green Product Procurement
Hazardous Substances. From July 1, 2006, the RoHS Directive will prohibit any marketing of new products containing restricted substances. Increasing attention is given to issues related to the global environmental. Toshiba Corporation recognizes environmental protection as a key management tasks, and is doing its utmost to enhance and improve the quality and scope of its environmental activities. -
Page 3: Chassis And Cabinet Replacement Parts List
• The PC board assembly with mark is no longer available after the end of the production. • The green parts describes in "G" mark, listed to the left side of the Parts No. item. Model : 62HMX85 Capacitors..... Ceramic Disk... - Page 4 Location Parts No. Description Location Parts No. Description C863 76212221 CAPACITOR, CERAMIC DISC, 50V B 220PF K CS10 76092795 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K C864 76590681 CAPACITOR, PLASTIC FILM, 50V 680PF J CS11 76092795 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K C864 76591681 CAPACITOR, PLASTIC FILM, 50V 680PF J CS12...
- Page 5 Location Parts No. Description Location Parts No. Description CY506 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K R810 76568479 RESISTOR, CERAMIC COVERED, 7W 4.7 OHM J CY508 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K GJ105 76000445 RESISTOR, CHIP JUMPER, 1608TYPE CY512 76092463 CAPACITOR, CERAMIC CHIP, 16V B 0.22UF K GR103...
- Page 6 Location Parts No. Description Location Parts No. Description RV323 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RY533 76011102 RESISTOR, CHIP, 1/20W 1K OHM J RV324 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RY534 76011102 RESISTOR, CHIP, 1/20W 1K OHM J RV325 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RY548...
- Page 7 Location Parts No. Description Location Parts No. Description R622 76011391 RESISTOR, CHIP, 1/20W 390 OHM J R8251 76000145 RESISTOR, METAL FILM, 1/4W 330 OHM F RB87 76011394 RESISTOR, CHIP, 1/20W 390K OHM J R886 76000525 RESISTOR, METAL FILM, 1/4W 4.7K OHM F RB88 76011394 RESISTOR, CHIP, 1/20W 390K OHM J R888...
- Page 8 Location Parts No. Description Location Parts No. Description M811A 23103778 FERRITE CORE, TFE1008 QV004 23205506 TRANSISTOR, 2SC4081 Q M905A 23103778 FERRITE CORE, TFE1008 QV005 23205506 TRANSISTOR, 2SC4081 Q M802A 23103839 FERRITE CORE, TFE1012 QV006 23205506 TRANSISTOR, 2SC4081 Q MB91A 23103840 FERRITE CORE, TFE1013 QV007 23205506 TRANSISTOR, 2SC4081 Q P800A...
- Page 9 Location Parts No. Description Location Parts No. Description DB82 23358585 LED, LAMP, SML-810MTT86 D615 23362140 DIODE, KDS160-RTK D850 23357622 DI0DE, ZENER, RD11ESA B3 D616 23362140 DIODE, KDS160-RTK D8200 23357922 DIODE, 1SS120-7-E D617 23362140 DIODE, KDS160-RTK D845 23357922 DIODE, 1SS120-7-E DB03 23358615 DIODE, LED INFRARED, SIR-56SB3F D848 23357922 DIODE, 1SS120-7-E...
- Page 10 23171400 WIRE, PVC, SOLDER-PLATED 300V 7/16 BRN UL CSA A227 23433346 DECORATIVE, CTRL PANEL TRIM 62HMX85;S1304E784 PX18 23713270 CONNECTOR, 11FE-ST-VK-N 11FE-ST-VK-N A329 23433359 DECORATIVE, SCREEN DECO FRAME 62HMX85;A055085E PA01 23713240 CONNECTOR, 15FE-BT-VK-N JST 15FE-BT-VK-N A184 23469392 INSULATOR, 05_LENS_GASKET 62HM195;C055045E PV04...
- Page 11 23450863 PANEL, A/V MOUNT PURCHASE 52HMX85;S1304E780 B112 23059129 PIECE COVER, 52HM84 52HM84 A215 23940083 PIECE, PIECE ENCLOSURE,DLE 52HM84;S1304F019 A232 23940467 PIECE, PIECE SIDE LEFT 62HMX85;S1305E242 A231 23940466 PIECE, PIECE SIDE RIGHT 62HMX85;S1305E241 A225 23940084 PIECE, STRIKER 52HM84;S1304F028 A220 23451976 PUSH CATCH, CLICK K502...
- Page 12 Projection Television 46HMX85 52HMX85 62HMX85 - SUMMARY - 46HMX85/52HMX85/62HMX85 is the same as 52HM85/62HM85 except for the parts tabled on back of this sheet. Use this service manual together with the service manual of 52HM85/62HM85 (File No. 020-200506). TOSHIBA CORPORATION 2005 Published in Japan Jun.
-
Page 13: Replacement Parts List Differences
#1 : [46HMX85] C8201 76503047 PLASTIC FILM, 63V 0.33UF J #2 : [52HMX85] C8202 76073169 ELECTROLYTIC, 25V 470UF M 3A #3 : [62HMX85] C8210 76073172 ELECTROLYTIC, 25V 1000UF M 3A C8211 76503041 PLASTIC FILM , 63V 0.1UF J CAPACITORS C8212... - Page 14 Location Parts No. Description Location Parts No. Description CS26 76794470 ELECTROLYTIC, 16V 47UF M CY541 76761102 ELECTROLYTIC, 6.3V 1000UF M CS27 76794220 ELECTROLYTIC, 16V 22UF M CY582 76105101 CERAMIC CHIP, 50V CH 100PF J CS28 76794100 ELECTROLYTIC, 16V 10UF M CS29 76794100 ELECTROLYTIC, 16V 10UF M RESISTORS...
- Page 15 Location Parts No. Description Location Parts No. Description R864 76321828 METAL FILM, 1/2W 0.82 OHM J RA88 76011104 CHIP, 1/20W 100K OHM J R865 76381221 OXIDE METAL FILM, 1/2W 220 OHM J RA91 76011623 CHIP, 1/20W 62K OHM J R866 76366681 CARBON FILM, 1/6W 680 OHM J RA94 76000445 CHIP JUMPER, 1608TYPE...
- Page 16 Location Parts No. Description Location Parts No. Description RV19 76011101 CHIP, 1/20W 100 OHM J RY533 76011102 CHIP, 1/20W 1K OHM J RV20 76366750 CARBON FILM, 1/6W 75 OHM J RY534 76011102 CHIP, 1/20W 1K OHM J RV21 76011562 CHIP, 1/20W 5.6K OHM J @U103 RY535 76011330 CHIP, 1/20W 33 OHM J 76366750 CARBON FILM, 1/6W 75 OHM J @UV03...
- Page 17 Location Parts No. Description Location Parts No. Description L891 23248432 COIL, CHOKE, TLN3499AH QA81 23205329 TRANSISTOR, RN1404(F) L892 23248432 COIL, CHOKE, TLN3499AH QA82 23205329 TRANSISTOR, RN1404(F) L893 23248417 COIL, CHOKE, TLN3481AH QA83 23205329 TRANSISTOR, RN1404(F) L895 23248432 COIL, CHOKE, TLN3499AH QA84 23205329 TRANSISTOR, RN1404(F) L896...
- Page 18 Location Parts No. Description Location Parts No. Description D844 23357838 DIODE, ZENER, MTZJ5.6C F882 23144714 FUSE, AXIAL 125V 4.0A D845 23357697 DIODE, 1SS133 F883 23144715 FUSE, AXIAL 125V 5.0A D846 23357684 DIODE, ZENER, RD3.0ESA B2 F884 23144715 FUSE, AXIAL 125V 5.0A D847 23357684 DIODE, ZENER, RD3.0ESA B2 F899...
- Page 19 Location Parts No. Description Location Parts No. Description UV02 #1 23148418 SCAN CONVERTER MODULE, 03DVI, MHDM01A #3 23311081 SCREEN, 62K4MF FRESNEL SHEET #2 23148376 SCAN CONVERTER MODULE, 03DVI-2, MHDM02 K601 #1 23405454 MIRROR, 46G4M3 #3 23148376 SCAN CONVERTER MODULE, 03DVI-2, MHDM02 #2 23405453 MIRROR, 52G4M3 UV03 23764204 PC BOARD ASSY, FRONT AV PU PD2128A-2...
