Summary of Contents for Innovative Technology ITSB-201-37
- Page 1 Bluetooth Stereo Soundbar ® Model: ITSB-201-37 TUN- TUN+ VOL- VOL+ SOURCE Instruction Manual Please read this instruction manual carefully and keep it for future reference.
- Page 2 • CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT. • WARNING: moisture. • CAUTION: may result in hazardous radiation exposure. • WARNING: compliance could void the user’s authority to operate the equipment. • WARNING: Do not place the unit on top of any soft, porous, or sensitive surfaces to avoid damaging the surface.
-
Page 3: Safety Instructions
SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. This apparatus shall not be exposed to dripping or splashing, and no objects filled with liquids, such as vases, shall be placed on the apparatus. - Page 4 INCLUDED IN THIS PACKAGE 1 x Bluetooth Stereo Soundbar ® 1 x Power adapter x Instruction manual 1 x Remote control 1 x CR 2025 button cell 1 x 3.5mm aux in cable 1 x RCA audio cable 2 x Wall mount brackets x Screws 4 x Wall anchors PRODUCT OVERVIEW...
- Page 5 Rear View FM ANT DC 16V OPTICAL IN 1. Optical audio input 2. FM antenna 3. AUX IN jack 4. DC IN jack...
- Page 6 Remote Control 1. Source Button 7. VOL – (Volume –) Button 12. CLOCK / MO / ST Button 2. Standby Button 8. BASS – Button 13. VOL + (Volume +) Button 3. FM SCAN Button 9. Treble – Button 14. BASS + Button 4.
- Page 7 WALL MOUNTING INSTRUCTIONS 27” + 0.125” – 0.125” Metal Bracket Metal Bracket 1. Using figure 1 above as a guide, measure the Stereo Soundbar to determine the position of where the metal brackets and screws should be mounted on the wall. Make sure the two brackets are mounted at the same level.
-
Page 8: Battery Installation
BATTERY INSTALLATION - Before installation Remove and discard the insulation tab. Out of the box the Remote Control has a battery and will be usable after the tab is removed. - How to replace battery for the remote control 1. Push and slide out the battery holder as shown below. 2. - Page 9 3.5mm AUX IN (Front of Unit) - 3.5mm AUX IN source may include: ·MP3 player, smartphones, tablets, computers or laptops - 3.5mm AUX IN connection: 1. Connect a 3.5mm aux in cable (supplied) between the headphone or AUX/Audio output of the personal audio player and the 3.5mm AUX IN jack on the front of the unit.
- Page 10 BLUETOOTH - Pairing: 1.Press SOURCE button until "BT" appears on the display. 2. Turn ON Bluetooth functionality on your Bluetooth device. Typically, Bluetooth controls are found in the device’s tools or settings menu (see your user manual). Turn ON Bluetooth connectivity and make your device “discoverable”.
- Page 11 OPTICAL IN - Connecting 1. Press SOURCE button until "OPTI" appears on the display. Follow the figure below to make connections. NOTE: Not all entertainment systems are set up the same way. The diagram below is only one example of how the connection can be made. Optical Out of TV/DVD/Etc.
-
Page 12: Fcc Statement
SPECIFICATIONS Power source of the remote control..........DC 3V, 1x CR 2025 button cell Output of the power adapter..................DC 16V, 1.8A Audio output........................10W x 2 Power consumption........................25W Bluetooth working range....................33FT (10M) FM coverage......................87.5-108.0MHz Bluetooth is a registered trademark of Bluetooth SIG, Inc. Other trademarks and trade names are those of their respective owners. - Page 13 Limited Warranty: 90 Days Labor, One Year Parts Innovative Technology Electronics Corp. (IT) warrants the product to be free from “Defects” in materials under normal use for a period of “One Year” from the date of the original purchase. The Warranty is “Not” transferable.
