VENTED DECORATIVE NATURAL GAS LOGS
OWNER'S OPERATION AND INSTALLATION MANUAL
COMFORT GLOW LOG SET AND BURNER MODELS
CVSR18, CVSR24, CPVSR18, CPVSR24, CVDR18
CVDR24, CVDR30, BFLT18 AND BFLT24
WARNING: If the information in these instructions
is not followed exactly, a fire or explosion may result
causing property damage, personal injury or death.
— Do not store or use gasoline or any other flammable
vapors or liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS :
• Do not try to light any appliance.
• Do not touch any electrical switch;
• Do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
— Installation and service must be performed by a quali-
fied installer, service agency or the gas supplier.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
For more information, visit www.fmiproducts.com
Comfort
Comfort
FOR YOUR SAFETY
Flame
Flame
by FMI PRODUCTS, LLC
TM
PFS
®
US
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Comfort Glow CVSR18
Summary of Contents for Comfort Glow CVSR18
- Page 1 Flame Flame by FMI PRODUCTS, LLC VENTED DECORATIVE NATURAL GAS LOGS OWNER’S OPERATION AND INSTALLATION MANUAL ® COMFORT GLOW LOG SET AND BURNER MODELS CVSR18, CVSR24, CPVSR18, CPVSR24, CVDR18 CVDR24, CVDR30, BFLT18 AND BFLT24 WARNING: If the information in these instructions is not followed exactly, a fire or explosion may result causing property damage, personal injury or death. FOR YOUR SAFETY — Do not store or use gasoline or any other flammable...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety ..............2 Troubleshooting ..........16 Local Codes............4 Service Hints ............. 19 Unpacking............4 Technical Service..........19 Product Identification ........... 5 Replacement Parts ..........19 Optional Product Features........5 Parts ..............20 Installation ............5 Accessories ............26 Operation ............ - Page 3 SAFETy Continued Natural gas is odorless. An odor- Natural Gas: Appliance assembly becomes making agent is added to the gas. The odor very hot when in use. Keep chil- helps you detect a gas leak. However, the odor added to the gas can fade. Gas may be dren and adults away from hot present even though no odor exists.
-
Page 4: Local Codes
SAFETy Continued 4. This log set is designed to be smokeless. 9. Do not use appliance if any part has been If logs ever appear to smoke, turn off appli- exposed to or under water. Immediately ance and call a qualified service person. call a qualified service technician to in- spect the room appliance and to replace Note: During initial operation, slight smok-... -
Page 5: Product Identification
PRODUCT IDENTIFICATION Grate Steps (not required for models CVSR18/24) Grate Hearth Kit Model ___________________ Serial Number _____________________ Log Set Model _____________________ Burner Burner Clamp Burner Inlet Burner Manifold Fitting Figure 1 - Product Identification (Dual Burner Shown) OPTIONAL PRODUCT FEATURES ON/OFF SAFETY VALVE/PILOT KIT or other sources to light. - Page 6 MINIMUM FIREBOX SIZES Models: CPVSR18, CVSR18, CVDR18 Front Width* Back Width** Depth Height 28" 16" 14" 18"...
- Page 7 INSTALLATION Continued CHECK GAS TYPE CONNECTING TO GAS SUPPLY Use only natural gas. If your gas supply is not WARNING: A qualified ser- natural gas, you must install ON/OFF Safety vice person must connect log Valve/Pilot Kit (see Accessories, page 26). Call dealer where you bought log set.
- Page 8 INSTALLATION Continued We recommend that you install a sediment PRESSURE TESTING GAS SUPPLY trap in supply line as shown in Figure 4. PIPING SYSTEM Locate sediment trap where it is within reach Test Pressures In Excess Of 1/2 PSIG for cleaning. Install in piping system between (3.5 kPa) fuel supply and heater.
- Page 9 INSTALLATION Continued HEARTH KIT ASSEMBLY AND Burner Manifold INSTALLATION Kit Assembly - Single and Dual-Flame Only 1. Determine which side gas line will be Burner Inlet coming into fireplace. Fitting NOTICE: Triple-burner mod- els BFLT18 and BFLT24 come preassembled with gas inlet Knockout on right side of burner pan. Plugs DO NOT attempt to reposition Burner Pan...
- Page 10 INSTALLATION Continued Installation and Gas Connection 2. Attach pilot gas line to pilot outlet of gas 1. Place burner pan assembly in center of control valve and tighten. Connect ther- fireplace floor. Make sure front of pan mocouple to rear of gas control valve. faces forward.
- Page 11 INSTALLATION Continued 6. Install gas connector tube to gas supply PROPANE/LP GAS CONVERSION fitting. Carefully shape tube to attach to To convert to propane/LP gas, burner inlet adapter fitting. Be careful not to cause fitting and pilot orifice must be replaced. kinks in tube.
- Page 12 Figure 15. (Not required for WARNING: Never check for models CVSR18/24.) gas leaks with open flame. 3. Place back log on grate onto grate steps (see Figure 16, page 13). 2. Light burner with shutoff valve no more 4.
- Page 13 INSTALLATION Continued 5. Place smaller top logs onto bottom logs (see Figure 17). Leave as much open space between logs as possible to mini- mize flame impingement and sooting. Note: Logs may chip if they are handled roughly or if hit together while being placed.
-
Page 14: Operation
OPERATION FOR YOUR SAFETY GAS SHUTOFF READ BEFORE LIGHTING VALVE OPERATION Flame Adjustment WARNING: Keep flue open Adjust the flame ON/OFF by turning gas shut- when operating unit. off valve counterclockwise to open or clockwise to close, as necessary. WARNING: If you do not fol- Shutting Off Appliance low these instructions exactly, Turn gas shutoff valve clockwise... -
Page 15: Cleaning And Maintenance
OPERATION Continued Note: You may be running this log set Control Knob Pilot for the first time after hooking up to gas Ignitor supply. If so, the control knob may need to be pressed in for 30 seconds. This will FROM "PILOT"... -
Page 16: Troubleshooting
TROUBLEShOOTING WARNING: Turn off log set and let cool before servicing. Only a qualified service person should service and repair log set. Note: All troubleshooting items are listed in order of operation. OBSERVED PROBLEM POSSIBLE CAUSE REMEDY Log set is smoking/sooting 1. Poor fuel quality 1. Contact local natural or excessively propane/LP gas company (Note: It is natural and unavoid- 2. - Page 17 TROUBLEShOOTING Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY When ignitor button is pressed, 1. Gas supply turned off or 1. Turn on gas supply or open there is spark at pilot but no equipment shutoff valve equipment shutoff valve ignition (GA9050A-1 Only) closed 2.
- Page 18 TROUBLEShOOTING Continued WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Fol- low the gas supplier’s instructions. • If you cannot reach your gas supplier, call the fire department. IMPORTANT: Operating log set where impurities in air exist may create odors. Cleaning sup- plies, paint, paint remover, cigarette smoke, cements and glues, new carpet or textiles, etc., create fumes.
-
Page 19: Service Hints
SERVICE hINTS TEChNICAL SERVICE You may have further questions about When Gas Pressure is Too Low installation, operation, or troubleshooting. • pilot will not stay lit If so, contact FMI PRODUCTS, LLC at • burners will have delayed ignition 1-866-328-4537. When calling please have • heater will not produce specified heat your model and serial numbers of your •... -
Page 20: Parts
PARTS MODELS CvSR18, CvSR24, CPvSR18 AND CPvSR24 Oxford Round Oak Logs CPVSR Models Only Amherst Round Oak Logs www.fmiproducts.com 901265-U... - Page 21 PARTS This list contains replaceable parts used in your log set. When ordering parts, follow the instructions listed under Replacement Parts on page 19 of this manual. NO. PART NO. DESCRIPTION QTY. 901056-01 Brass 3/8 FLR x 1/2 FPT Adapter •...
- Page 22 PARTS MODELS CvDR18, CvDR24 AND CvDR30 Berkshire Oak Log Set Coventry Oa www.fmiproducts.com 901265-U...
- Page 23 PARTS This list contains replaceable parts used in your log set. When ordering parts, follow the instructions listed under Replacement Parts on page 19 of this manual. NO. PART NO. DESCRIPTION 901056-01 Brass 3/8 FLR x 1/2 FPT Adapter • • • 901059-01 Brass 3/8 FLR x 3/8 FPT Adapter •...
- Page 24 PARTS MODELS BFLT18 AND BFLT24 Mendocino Oak Log Set www.fmiproducts.com 901265-U...
- Page 25 PARTS This list contains replaceable parts used in your log set. When ordering parts, follow the instructions listed under Replacement Parts on page 19 of this manual. PART NO. DESCRIPTION QTY. 901056-01 3/8 FLR x 1/2 FPT Adapter • • 901059-01 3/8 FLR x 3/8 FPT Adapter •...
-
Page 26: Accessories
ACCESSORIES IASH BED MATERIAL (vermiculite) Purchase these accessories from your local dealer. If they can not supply these accessories GA9750A call FMI PRODUCTS, LLC at 1-866-328-4537 For all models. Use for firebox decoration for information. You can also write to the ad- only. - Page 27 NOTES _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ 901265-01U www.fmiproducts.com...
-
Page 28: Warranty
WARRANTy kEEP ThIS WARRANTy Model (located on product or identification tag) _____________________________ Serial No. (located on product or identification tag) __________________________ Date Purchased __________________________ Keep receipt for warranty verification. FMI PRODUCTS, LLC LIMITED WARRANTIES New Products Standard Warranty: FMI PRODUCTS, LLC warrants this new product and any parts thereof to be free from defects in material and workmanship for a period of two (2) years from the date of first purchase from an authorized dealer provided the product has been installed, maintained and operated in accordance with FMI PRODUCTS, LLC’s warnings and instructions.
