Arrow 697.68221 Owner's Manual & Assembly Instructions

Hide thumbs

Advertisement

Quick Links

Download this manual
Owner's Manual & Assembly Instructions
WR01
Model No.
715521208
BUILDING DIMENSIONS
*Approx.
Foundation
Size
Size
10' x 11'
121" x 131 3/8"
3,0m x 3,4m
307cm x 334cm
697.68221
* Size rounded off to the nearest foot
Storage Area
Sq. Ft. Cu. Ft.
106
628
123 1/4" 133 7/8"
2
3
9,8m
17,8m
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Exterior Dimensions
(Roof Edge to Roof Edge)
Width
Depth
Height
81 3/8"
313cm
340cm
207cm
Interior Dimensions
(Wall to Wall)
Width
Depth
Height Width Height
118 1/4" 128 5/8" 80 1/8" 55 1/2"
300cm
327cm
204cm
Door
Opening
60"
141cm 152cm

Advertisement

loading

Related Manuals for Arrow 697.68221

Summary of Contents for Arrow 697.68221

  • Page 1 Owner's Manual & Assembly Instructions WR01 Model No. 697.68221 CAUTION: SOME PARTS HAVE SHARP EDGES. CARE MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ 715521208 SAFETY INFORMATION PROVIDED IN THIS MANUAL BEFORE BEGINNING CONSTRUCTION.
  • Page 2 Anchoring and foundation materials are not included with your building. We recommend the combined use of an Arrow Floor Frame Kit and an Arrow Anchoring Kit as an effective method of securing your building to the ground (Available by mail order or at your local dealer) or you may construct a foundation and anchoring system of your choice.
  • Page 3 PLAN AHEAD..Watch the Weather: Be sure the day you select to install your building is dry and calm. Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Teamwork: Whenever possible, two or more people should work together to assemble your building.
  • Page 4 SAFETY FIRST..Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in the pieces of your building since some contain assembly of this building. Be familiar with the sharp edges.
  • Page 5 Keep roof clear of leaves and snow with long handled, soft-bristled broom. Heavy amounts of snow on roof can damage building making it unsafe to enter. In snow country, Roof Strengthening Kits are available for most Arrow Buildings for added protection against heavy snow accumulation.
  • Page 6 For buildings ATTIC KIT / WORKBENCH KIT larger than 10'x9', use 2 kits. Heavy-duty galvanized steel bars that fit all 10' wide Arrow buildings. They Model No. AK100 install quickly and easily to help New concrete anchor system permits...
  • Page 7 THIS PAGE LEFT BLANK INTENTIONALLY...
  • Page 8 THIS PAGE LEFT BLANK INTENTIONALLY...
  • Page 9 A. To support a plywood deck B. To be filled with sand. We recommend the combined use of 1. an ARROW FLOOR FRAME KIT and 2. an ARROW ANCHORING KIT as an effective method of securing the building to the ground.
  • Page 10 It is important that the entire floor frame be anchored after the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Arrow Anchoring Kit: (Model No. AK4 or 60298) Use 1/4" Wood Screws. There are 1/4" (0,63cm) dia.
  • Page 11 (Packed with Screws) 65109 67468 66646 #8-32 Acorn Nut (4) Peak Cap (2) 66045 Washer (429) (Packed with Screws) (Arrow Logo) Handle (2) (11 sheets of 40) 66183 67545 66769 66382 Roof Trim Cap Weather Stripping (1) Door Slide (4) Lower Door Guide (4) (2 right &...

  • Page 12: Table Of Contents

    Parts List WR12 Assembly Part Part Quantity Check Key No. Number Description in Carton List 8576 Right Gable 8577 Left Gable 10497 Horizontal Door Brace 7571 Roof Panel 10520 Right Roof Panel 10519 Left Roof Panel 10475 Right Door 10475 Left Door 9369 Door Jamb...
  • Page 13 Assembly by Key No. WR13...

  • Page 14: Side Floor Frame

    ● ● ● ● ● 8934 Ramp (1) ● Parts Needed For ● ● ● ● ● ● 9367 Front Floor Frame (2) Step 1 ● ● ● ● ● 8936 Rear Floor Frame (2) Floor Frame Assemblies ● ● ● ● ● 10523 Side Floor Frame (4) WR14 The front floor frame is made up of three pieces.
  • Page 15 ● ● ● ● ● 5986 Rear Wall Angle (2) ● Parts Needed For ● ● ● ● ● ● 10389 Rear Wall Channel (2) Step 2 ● ● ● ● ● 10524 Side Wall Channel (4) Frame Assemblies ● ● ● ● ● 10525 Side Wall Angle (4) WR15 The main frame pieces reinforce the walls.

  • Page 16: Roof Panel

    ● Parts Needed For ● Step 3 ● ● ● ● ● 10522 Roof Beam (8) Roof Beam Assemblies WR16 The roof beams join the two gables and support the roof panels. The main roof beam is made up of four pieces 10522 overlapped back to back at the cen- ter.
  • Page 17 ● Parts Needed For ● ● ● ● ● ● 6403 Door Track Splice (1) Step 4 ● ● ● ● ● 9366 Door Track (2) Door Track Assembly NOTE: Door Track Splice (painted part) The door track assembly supports the sliding doors and reinforces the front wall.
  • Page 18 ● ● ● ● ● Front Floor Assembly (1) ● Parts Needed For ● Step 5 ● ● ● ● ● Side Floor Assembly (2) Floor Frame ● ● ● ● ● Rear Floor Assembly (1) WR18 RIGHT REAR 10523 STEP Place the floor frame pieces that 8936...

  • Page 19: Corner Panel

    ● Parts Needed For ● ● ● ● ● ● 6515 Wall Panel (2) Step 6 ● ● ● ● ● 9373 Front Wall Panel (2) Corners ● ● ● ● ● 7333 Corner Panel (4) WR19 NOTE Narrow The remainder of the building assembly Side requires many hours and more than one 7333...

  • Page 20: Side Wall Channel

    ● Parts Needed For ● Step 7 ● ● ● ● ● Rear Wall Channel Assembly (1) ● ● ● ● ● Side Wall Channel Assembly (2) Mid Frames WR20 The mid frame pieces give rigidity to the side and rear walls. Fasten the rear wall channel across the middle of the rear wall using screws.

  • Page 21: Side Wall Angle

    ● ● ● ● ● Door Track Assembly (1) ● Parts Needed For ● Step 8 ● ● ● ● ● Rear Wall Angle Assembly (1) Top Frames ● ● ● ● ● Side Wall Angle Assembly (2) WR21 The top frame pieces give rigidity to the walls and provide a surface for attaching the gables which support the roof.
  • Page 22 ● Parts Needed For ● Step 9 ● ● ● ● ● 6515 Wall Panel (2) Wall Panels ● ● ● ● ● 7332 Wall Panel (6) WR22 STEP Each wall panel has a crimped rib on one side. The crimped rib should go under the rib of the panel that follows Crimped Rib STEP...
  • Page 23 ● Parts Needed For ● ● ● ● ● ● 9369 Door Jamb (2) Step 10 ● ● ● ● ● 9365 Front Wall Channel (2) Front Channel/Door Jamb SO23 The door jambs reinforce the door opening and provide an attractive 9365 trim.
  • Page 24 ● Parts Needed For ● ● ● ● ● ● 8576 Right Gable (2) Step 11 ● ● ● ● ● 8577 Left Gable (2) Gable Assemblies ● ● ● ● ● 6635 Roof Beam Bracket (4) WR24 The gables go on top of the front and rear walls to support the roof beams.
  • Page 25 ● ● ● ● ● Left Gable Assemblies (2) ● Parts Needed For ● Step 12 ● ● ● ● ● Right Gable Assemblies (2) Gables/Braces ● ● ● ● ● 9009 Gable Brace (2) SR25 Lift and fasten a right and left gable, under angle at corner, to the door track and rear wall angle with screws.
  • Page 26 ● Parts Needed For ● ● ● ● ● ● Roof Beam Assemblies (4) Step 13 ● ● ● ● ● 9204 Roof Beam Brace (2) Roof Beam//Braces SR26 Wrap the weather stripping tape STEP around the two joined edges of the left and right gables.
  • Page 27 ● Parts Needed For ● Step 14 ● ● ● ● ● 10520 Right Roof Panel (1) Right Roof Panel WR27 Installing the roof panels is best done with a step ladder. Install the first roof panel at the back right corner of the building.
  • Page 28 ● Parts Needed For ● ● ● ● ● ● 10519 Left Roof Panel (1) Step 15 ● ● ● ● ● 7571 Roof Panel (2) Ridge Cap & Panels ● ● ● ● ● 8742 Ridge Cap (1) WR28 Install a left roof panel 10519 at Screws To the left rear corner of the roof.
  • Page 29 ● Parts Needed For ● ● ● ● ● ● 7571 Roof Panel (2) Step 16 ● ● ● ● ● 8814 Ridge Cap (1) Ridge Cap & Panels WR29 Install the second ridge cap 8814 overlapping the first ridge cap while installing two roof panels 7571.
  • Page 30 ● ● ● ● ● 8742 Ridge Cap (1) ● Parts Needed For ● ● ● ● ● ● 7571 Roof Panel (2) Step 17 ● ● ● ● ● 10519 Left Roof Panel (1) Ridge Cap & Panels ● ● ● ● ● 10520 Right Roof Panel (1) WR30 Install the third ridge cap 8742 overlapping the second ridge cap...
  • Page 31 ● Parts Needed For ● Step 18 ● ● ● ● ● 8743 Side Roof Trim (4) Roof Trim ● ● ● ● ● 8811 Side Roof Trim (2) WR31 Attach the side roof trim pieces to the lower end of the roof panels on each side of the building using screws at each panel overlap.
  • Page 32 ● ● ● ● ● 3719 Door Handle Brace (2) ● Parts Needed For ● ● ● ● ● ● 10475 Right and Left Doors (2) Step 19 ● ● ● ● ● 10497 Horizontal Door Brace (4) Door Assembly ●...
  • Page 33 ● Parts Needed For ● ● ● ● ● ● Right Door Assembly (1) Step 20 ● ● ● ● ● Left Door Assembly (1) Door Installation & Adjustment SQ33 Horizontal Door Brace Gable Door Track Door Slide From inside the building, put the bottom of the right door assembly (on your left when you are inside the STEP...
  • Page 34 SOME FACTS ABOUT RUST SO34 SOME FACTS ABOUT RUST 1. Avoid nicking or scraping the coating surface, Rusting is a natural oxidizing process that occurs inside and out. when bare metal is exposed to moisture. Problem areas include screw holes, unfinished edges, or 2.
