- Page 1 BC- - - - 9 9 9 9 000 BATTERY CHARGER OPERATIONS MANUAL COFKO LLC. COPYRIGHT © 2011...
- Page 2 UNPACKING As you unpack your new BC-9000 battery charger, inspect the tester for signs of shipping damage. If shipping damage is present, stop and contact the shipping company for damage claims information. The box should contain the BC-9000 , operators instruction manual, DC charge cord , and battery connector assembly.
- Page 3 Before operating your new BC-9000 , familiarize yourself with this operators manual and the unit. Questions? Call: (909) 705-6267 Mon.-Fri.8:00 A.M. to 5:00 P.M. PST or support@cofko.com Thank you, COFKO Manual: BC-9000 Revision: A Date: 12/20/2011...
-
Page 4: Table Of Contents
BC-8000 History of Revisions ………………………………......................5 BC-9000 SAFETY NOTES ………………………………………………………………….……..............… 6,7 BC-9000 OPERATION …………………………………………..................…..……. 8,9,10 BC-9000 CARE …………………………………………....…………………..........…..…..….. 11 BC-9000 TECHNICAL DATA ………………………………………………………………………............…..….. 12 BC-9000 LIMITED WARRANTY ………………………………......................13 BC-9000 NOTES ………………………………......................14 BC-9000 CERTIFCATION OF FACTORY CALIBRATION ............................... 15... - Page 5 History of Revisions Revision # Effective Date Description of Change Approval By 12/20/2011 Initial issue M.C. 10/23/2012 Increase Maximum Operation Altitude from 6000’ to 6500’ 10/23/2012 Change Description of Box Contents M.C. 04/05/2013 Minimum and Maximum Charger Operation Temperature M.C.
- Page 6 SAFETY NOTES Your new BC-9000 battery charger has been designed with operator safety as a function of its design, construction, and operation. Understanding how to safely operate the BC-9000 is important. Failure to follow the operation and safety guidelines when using the BC-9000 can result in personal injury to the operator and damage to the BC-9000. Always review the battery manufacturer’s battery charging guidelines before recharging batteries.
- Page 7 12 DANGER: Never connect the BC-9000 to batteries with voltage or recharge charge currents outside the ratings of the charger. Any questions that arise about the battery or charger ratings, call (909)705-6267. 13 DANGER: Never obstruct the BC-9000 air intake or hot air exhaust openings. Obstructing either opening can cause the BC-9000 to overheat.
-
Page 8: Bc-9000 Operation
SAFETY FIRST 1. Set the BC-9000 on a stable suitable surface. Plug the AC cord located at the rear of the BC-9000 into an AC power outlet. ( Note: The BC-9000 comes with a NEMA 5 -15 connector ) Using the UP or DOWN button, select charge steps. - Page 9 Press the NEXT button to advance the display menu. b. The BC-9000 will display CHARGE Step 1 Volts? Use the UP or DOWN button to adjust the value from 3.0 to 36.0 volts. Press the NEXT button to advance the display menu.
- Page 10 The BC-9000 will display the message START CHARGING? Press NEXT. Pressing the next button will start the battery charging cycle. With the charger running the BC-9000 display will show all the entered settings under the flashing CHARGING/Step 1 heading on the left side of the display. The arrow on the far left points to the limiting item at the moment.
-
Page 11: Bc-9000 Care
BC-9000 CARE Your BC-9000 battery charger should be treated as precision equipment, misuse will shorten its ability to perform accurate battery charging. Some simple guidelines of care will insure trouble free operation. 1. Do not drop the BC-9000 or expose it to rough handling. -
Page 12: Bc-9000 Technical Data
BC-9000 TECHNICAL DATA AC Input Voltage………………………………..........90~264VAC 1PH AC Input Current………………………………..........15 Amps @ 115VAC / 7.5 Amps @ 230VAC AC Input Frequency………………………………......... 47-63 Hz DC Output Voltage Maximum………………………………......36VDC DC Output Voltage Minimum………………………………......3.0VDC DC Output Current Maximum………………………………......25ADC DC Output Current Minimum………………………………...... -
Page 13: Bc-9000 Limited Warranty
STATEMENT OF WARRANTY COFKO LLC warrants to the original purchaser (end user) of the BC-9000 that it will be free of defects in workmanship and materials. This warranty is void if COFKO LLC finds that the BC-9000 has been subjected to improper care, abnormal operation, or modification. -
Page 14: Bc-9000 Notes
BC-9000 NOTES 1. ___________________________________________________________________________ 2. ___________________________________________________________________________ 3. ___________________________________________________________________________ 4. ___________________________________________________________________________ 5. ___________________________________________________________________________ 6. ___________________________________________________________________________ 7. ___________________________________________________________________________ 8. ___________________________________________________________________________ 9. ___________________________________________________________________________ 10. ___________________________________________________________________________... - Page 15 COFKO LLC. CERTIFIES THAT THE ABOVE LISTED TEST EQUIPMENT MEETS OR EXCEEDS ALL SPECIFIED TOLERANCES. THE TESTER STATED ABOVE HAS BEEN CALIBRATED WITH NATIONAL INSTITUTE OF STANDARDS AND TECHNOLOGY(NIST) TRACEABLE EQUIPMENT LISTED ABOVE. DATE MANUFACTURED:____/____/_______ S/N: ________________________ SIGNATURE:__________________________ ----------------------------------------------------------------------------------------------------------------------------------------------------------------------- Date of First Use: ____/____/______ Signature:________________________ 1. BC-9000 serial number location- REAR of CASE..
