Air Live AirVideo-100v2 User Manual

Wireless presenter dongle
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AirVideo-100v2
Wireless Presenter Dongle
User's Manual
i
AirLive WL-1700USB User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AirVideo-100v2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Air Live AirVideo-100v2

Summary of Contents for Air Live AirVideo-100v2

  • Page 1 AirVideo-100v2 Wireless Presenter Dongle User’s Manual AirLive WL-1700USB User’s Manual...
  • Page 2 OvisLink Corp. has made the best effort to ensure the accuracy of the information in this user’s guide. However, we are not liable for the inaccuracies or errors in this guide. Please use with caution. All information is subject to change without notice All Trademarks are properties of their respective holders. AirLive AirVideo-100v2 User’s Manual...

  • Page 3: Fcc Statement

    IMPORTANT NOTE FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. AirLive AirVideo-100v2 User’s Manual...

  • Page 4: Table Of Contents

    2.3.4 System Status ..........................29 2.3.5 Network Setup ..........................30 2.3.6 OSD Setup...........................32 2.3.7 Projection Setup...........................33 2.3.8 Change Passwords........................34 2.3.9 Reset to Default ...........................35 2.3.10 Firmware Upgrade ........................35 2.3.11 Reboot System...........................37 2.3.12 Logout ............................37 2.3.13 Screen Image Background Maker .....................38 AirLive AirVideo-100v2 User’s Manual...
  • Page 5 Table of Contents 3. Smart phone .................... 42 3.1 Introduce..................... 42 3.2 PtG converter ..................42 3.2.1 PtG Converter ..........................42 3.2.2 Windows MobiShow via Smartphone ..................43 3.2.3 MobiShow via iOS........................48 4. Appendix....................54 Troubleshooting..................54 AirLive AirVideo-100v2 User’s Manual...

  • Page 6: Introduction

    1. Introduction Introduction 1.1 Overview The AirVideo-100v2 is the most cost-effective and efficient way to do conference presentation. With AirLive Wireless Presenter Dongle, you may now upgrade your projector instantly with Wi-Fi capability by simply plug-connect the AirVideo-100 v2 to your projector.
  • Page 7 AirVideo-100v2 works with AP mode and AP Client mode. • Connect to AirVideo-100v2 Directly (AP Mode) By the default, the AirVideo-100v2 will always work at AP mode and it acts as a central hub for different Wireless LAN Clients. • Connect to AirVideo-100v2 via Wireless Router (Client Mode) You can enable the AP-Client Mode function to let AirVideo-100v2 join the existing Access Point through Wi-Fi.
  • Page 8 AirVideo-100 v2 supports MobiShow function for windows mobile 5/6 system. By launching MobiShow utility, MobiShow brings your mobile screen to big screen and which can play photos and PTG files stored in your mobile phone for presentation. AirLive AirVideo-100v2 User’s Manual...
  • Page 9 Screen. Design the image with message you would like to present, upload it through web ontrol page, and you could have customized starting page. The AirVideo-100v2 will act as a Wireless Client to connect with the r emote AP, let irVideo-100v2 join an existing Access Point through Wi-Fi.

  • Page 10: Features

    Support Wireless Encryption WEP 64,128 /WPA/WPA2-PSK Customized stand by screen Web management including software download and device settings Power over VGA 1.3 Packing List 1. AirVideo-100 v2*1 . Power adapter (DC5V,1.2A)*1 . CD*1 . Quick Installation Guide*1 AirLive AirVideo-100v2 User’s Manual...

  • Page 11: Specification Table

    . Reset Button Power Mechanical Dimension: 92.3 x 40 x 22 mm Weight: 52.2 g Environmental . Operation Temperature: 0~ 40℃ conditions . Storage Temperature: -10℃ ~ 60℃ . Operating Humidity: ≦90% . Storage Humidity: ≦80% Certificate FCC/CE AirLive AirVideo-100v2 User’s Manual...

  • Page 12: Hardware Installation

    1.5.2 Button Definition Description Step1: Remove the power adapter from AirVideo-100v2. Step2: Push the reset button. Step3: Plug the power adapter back into AirVideo-100v2. Reset Step4: Till the power LED light turn to “Green”, and then release the reset button.

  • Page 13: Quick Start

    1. Introduction 1.5.3 Quick Start Step1: Please plug AirVideo-100v2 into projector VGA port, and open projector power to use. AirLive AirVideo-100v2 User’s Manual...
  • Page 14 (1) Make sure your WLAN PC is enabled already, and connect your PC with AirVideo-100v2. (2) Open your browser and enter the IP address to access the AirVideo-100v2 web home page. The default IP address of AirVideo-100v2 is 192.168.1.1 or refers to the IP address shown on the left corner of projector screen.
  • Page 15 1. Introduction (3) Download the client software. Please select the” Win7 / Windows Vista / XP” or” MAC” and execute the installation program. After installing the program, you will see the WPS shortcut on the PC screen. AirLive AirVideo-100v2 User’s Manual...
  • Page 16 1. Introduction (4) Making sure your personal firewall allows WPS software to pass through. (5) Select device that your want to projection AirLive AirVideo-100v2 User’s Manual...
  • Page 17 1. Introduction (6) Enter the Login Code and you can see the login code on the projector screen. (7) Click the “Play” button to start projection! AirLive AirVideo-100v2 User’s Manual...

  • Page 18: Getting Start

    Step1: Click WPS icon to execute the program. Step2: Program start to search for AirVideo-100v2 automatically. Step3: If AirVideo-100v2 founded then “Login Code” dialog box will be pop up on the PC screen. Searching for AirVideo-100v2 AirVideo-100v2 is founded and enters login code to start.

  • Page 19: Login

    “Stop” button to stop projecting your screen, by clicking speedy mode button, the projection will enter speedy mode for faster projection. 4-1 function will be disabled in speedy mode. To enable audio projection, you have to install provided audio driver first. AirLive AirVideo-100v2 User’s Manual...

  • Page 20: Menu Description

    2. Getting Start Button Description Full Screen projection Project to Split #1 Project to Split #2 Project to Split #3 Project to Split #4 Stop projecting Pause projecting 2.1.5 Menu Description Menu Login Code Exit Minimize AirLive AirVideo-100v2 User’s Manual...

  • Page 21: Show Login Code

    10 seconds. You can also click on the area to close this window manually. 2.1.7 Open Admin Web Page Click to open function menu and select “Web Admin” management web page. The web page detailed functions will be described on next chapter. AirLive AirVideo-100v2 User’s Manual...

  • Page 22: Wi-Fi Client Configuration

    2.1.8 Wi-Fi Client Configuration Click “Wi-Fi AP Client Configuration” to set AP client mode to join others Access Point via wireless, besides, the others user client also can login AirVideo-100v2 for presentation and join to others Access Point network, 2.1.9 Searching Server Click “Search Server”...

  • Page 23: Projection Source

    USB token, you can find out the VDD program in supplied CD. 2.1.11 Auto Wi-Fi Connect Click “Auto Wi-Fi Connect” to enable the auto Wi-Fi discovery and connection function for quick wireless set up. AirLive AirVideo-100v2 User’s Manual...

  • Page 24: Auto Power Manager

    “highest performance”, however, you can click the “Auto Power Manage” to enable or disable this function and restore you power scheme immediately. 2.1.13 Hide UI Click the “Hide UI”, you can choose to hide or display the application control panel from projection screen. AirLive AirVideo-100v2 User’s Manual...

  • Page 25: Advanced Screen Capture

    However, the mouse cursor may blink from time to time when you are projecting your PC screen! Disable “Advanced Screen Capture”. A tip window is not shown in projector. Enable “Advanced Screen Capture”. A tip window is shown in projector. AirLive AirVideo-100v2 User’s Manual...

  • Page 26: Make Wps Token

    2. Getting Start 2.1.15 Make WPS Token Click “Make WPS Token” to make a USB WPS Token, you can insert a USB thumb drive and follows the wizard to make the Token. AirLive AirVideo-100v2 User’s Manual...

  • Page 27: Copy Application To Desktop

    Click the “Copy Application to desktop”, it will copy the application to your desktop immediately even you don’t have the system privilege 2.1.17 Hot Key Click “Hot Key” to show Hot Key guide. You can use hot key to control the projection by keyboard. AirLive AirVideo-100v2 User’s Manual...

  • Page 28: About

    Click “About” - to show system information. It includes product model name, Client version, IP address and other information. 2.1.19 Exit Click “Exit” to exit this application. It will stop current playing status and close the application immediate. AirLive AirVideo-100v2 User’s Manual...

  • Page 29: Mac Client Utility

    2. Getting Start 2.2 Mac Client Utility 2.2.1 Launch Application This chapter guides how to use AirVideo-100v2 on MAC OS, the installation steps as below, Step1: Enable your Wi-Fi and connect to AirVideo-100v2 device. Step2: Execute WPS client software for Mac.

  • Page 30: Main User Interface

    Click the “Play” button for full or split screen, you can project the main screen on to the display immediately, click the “Pause” button, you can freeze you projection screen, and click the “Stop” button to stop projecting your screen. AirLive AirVideo-100v2 User’s Manual...

  • Page 31: Web Management

    Refresh Screen 2.3 Web Management 2.3.1 Home Page There are two way to manage AirVideo-100v2 via WPS utility and via Web Management. Here, we will introduce the Web Management. Step1: Make sure your PC connect to AirVideo-100v2 successfully. Step2: Open your browser, it will enter AirVideo-100v2’s home page automatically.

  • Page 32: Download Software

    Step2: Follow Installation Wizard instructions to proceed till the installation process complete. Step3: If pop up “Windows Security Alert” because Windows firewall block this program. You just press “Unblock” button to continue installation. Step4: Once installation complete, a utility shortcut come out on the screen. AirLive AirVideo-100v2 User’s Manual...

  • Page 33: Login Web Admin

    2. Getting Start 2.3.3 Login Web Admin 1. Click [Admin] and then enter password to login web page. 2. The password default value is “airlive”. AirLive AirVideo-100v2 User’s Manual...

  • Page 34: System Status

    3. Default Gateway：default gateway 4. Wireless MAC address：wireless MAC address 5. Wire MAC address：wire MAC address Connection Status: 1. Projecting status: which is “Waiting for projecting” or “Projecting” 2. Total Users: It shows how many users login into AirVideo-100v2. AirLive AirVideo-100v2 User’s Manual...

  • Page 35: Network Setup

    When the AirVideo-100v2 is connected to a LAN that already has a DHCP server • present, the AirVideo-100v2 takes an IP address assigned to it by the server. When the AirVideo-100v2 is connected to a LAN that does not have a DHCP server, • the AirVideo-100v2 becomes the DHCP server in the network.
  • Page 36 Encryption: you can select “Disable” or one of WEP/WPA/WPA2 64bit or 128bit in ASCII or HEX string. Key: If Encryption is enabled, you have to set key value according to the encryption mode you selected. AirLive AirVideo-100v2 User’s Manual...

  • Page 37: Osd Setup

    <Restore Initial>: Restore to default OSD standby image. <Image File Upload>: Upload the customized OSD standby image. (You need to convert the image to system defined format using provided IB Maker utility which is stored in the USB token.) AirLive AirVideo-100v2 User’s Manual...

  • Page 38: Projection Setup

    (800*600). The default value is XGA. HDMI: 720p (1280*720) <Login Code>: You can select “Disable”, “Random”, or “Use the following code” to set a specified 4-characters Number. <Apply>：Confirmation and Save modifications <Cancel>: Cancel all the modifications AirLive AirVideo-100v2 User’s Manual...

  • Page 39: Change Passwords

    Click [Change Password] button, to change password value. The length of password is up to 8 characters. <Enter New Password>: enter new password you want to change for each category. <Confirm New Password>: double confirm new password. <Apply>: Confirmation and Save modifications. AirLive AirVideo-100v2 User’s Manual...

  • Page 40: Reset To Default

    2. Click <Browse> to specify file name you want to upgrade. 3. Click <Upgrade> to start. 4. A warning message shown and countdown counter on the screen. 5. After a few minutes, a complete message shown on the screen. 6. Restart AirVideo-100v2 to take effect. AirLive AirVideo-100v2 User’s Manual...
  • Page 41 2. Getting Start     Please DON’T turn the AirVideo-100v2 power off while firmware Warning: upgrade in progress, otherwise it will cause your AirVideo-100v2 malfunction; you will have to return device for RMA. AirLive AirVideo-100v2 User’s Manual...

  • Page 42: Reboot System

    2. Getting Start 2.3.11 Reboot System To reboot the device-   Click [Reboot System] button, to restart system <Reboot>: reboot system automatically. 2.3.12 Logout To logout the device- AirLive AirVideo-100v2 User’s Manual...

  • Page 43: Screen Image Background Maker

    2.3.13 Screen Image Background Maker This chapter guides you how to change the Background Image. The installation steps as below, Step1: Run the “Screen Image Background Maker” and follows the wizard to convert the image file. AirLive AirVideo-100v2 User’s Manual...
  • Page 44 2. Getting Start Step2: Press “Open” to select a file to convert this image for background use. Step3: Press “Saver” to save this file. (*.ib) AirLive AirVideo-100v2 User’s Manual...
  • Page 45 2. Getting Start Step4: Please connect to AirVideo-100v2’s webpage, and then connect to OSD setup page. Step5: Press “Browser” to choose the *.ib file. AirLive AirVideo-100v2 User’s Manual...
  • Page 46 2. Getting Start Step6: Press “image file upload” to upload your background image, then it will show the message as below. ※ Note: You may find “Screen Image Background Maker” in the USB Token. AirLive AirVideo-100v2 User’s Manual...

  • Page 47: Smart Phone

    First, you need to your the PtG converter transfer the file into your mobile device. The PtG Converter program you can find out from the supplied CD. Open “MobiShow PtG Converter” in “MobiShow\MobiShow PtG Converter” folder from “Programs” in the Start menu. AirLive AirVideo-100v2 User’s Manual...

  • Page 48: Windows Mobishow Via Smartphone

    Step 1: Open “Programs” on your phone and find “MobiShow” application. Step 2: Select “MobiShow” icon to launch the client software. Step 3: MobiShow will turn on Wi-Fi on your phone and list available access points for you to choose. AirLive AirVideo-100v2 User’s Manual...
  • Page 49 When a MobiShow device is found, it will automatically login and the following main menu is shown on your phone. If more than one MobiShow devices are found, the following list will be displayed for you to select the one to use. AirLive AirVideo-100v2 User’s Manual...
  • Page 50 (such PowerPoint Viewer) or open any file (such as Word document or JPG image) and it will be projected to the projector. Do not exit MobiShow application while opening other application to ※ Note: keep screen projected. AirLive AirVideo-100v2 User’s Manual...
  • Page 51 Click “Open” to select another PtG file. You need to use “PtG converter.exe” to convert Powerpoint become ※ Note: PtG file first. You can find out “PtG converter.exe” in the USB Token. AirLive AirVideo-100v2 User’s Manual...
  • Page 52 When the file is open, the media will be projected, and the following screen is displayed on the phone for you to control your media playback. Te below table shown the support list for different mobile phones ※ Note: AirLive AirVideo-100v2 User’s Manual...

  • Page 53: Mobishow Via Ios

    After a little time of searching, you will see a list of available receivers. Touch to connect and the successfully connected receiver will be changed into See image below. AirLive AirVideo-100v2 User’s Manual...
  • Page 54 PtG file list on document folder. Currently we support files with two file extensions, which are '.ptg' and '.ptg2'. See image below. Touch to play PtG file on connected receiver. While playing PtG file, screen will changed into controller. See image below. AirLive AirVideo-100v2 User’s Manual...
  • Page 55 Touch to stop playing PtG file. 3.2.3.3 Start Media Player Touch on the tab bar to view media file on document folder. Currently we support files with extension '.mpeg', '.avi', '.mp3'. See image below. AirLive AirVideo-100v2 User’s Manual...
  • Page 56 These two functions are disabled in this version. Touch to decrease volume, and to increase volume. Touch to pause, and to play. Touch to stop playing media file. Touch to mute voice. AirLive AirVideo-100v2 User’s Manual...
  • Page 57 While playing photo file, screen will changed into controller. See image below. Touch to play previous photo, and for next one. Touch to pause playing photo, and to stop. Touch to rotate photo to left, and to rotate photo to right. AirLive AirVideo-100v2 User’s Manual...
  • Page 58 A few seconds later, you'll see what apps you have already installed are right on your iPhone. Click , and you can see everything you uploaded associated with MobiShow Lite. Click , and choose file to upload to your IPhone AirLive AirVideo-100v2 User’s Manual...

  • Page 59: Appendix

    Troubleshooting Q: Why can’t I connect to AirVideo-100v2’s Web Management even the wireless show I had connected to the AirViedo-100’s SSID. Do a Ping test to make sure that the AirVideo-100v2 is responding. Go to Start > Run. Type cmd.
  • Page 60 III. Disable all security settings such as WEP, WPA and WPA2-PSK. IV. Turn off the AirVideo-100v2 and the client, then restart it and then turn on the client again. Ensure that the LEDs are indicating normally. If not, make sure that the power and Ethernet cables are firmly connected.
  • Page 61 Q: What is Wireless Client AP mode and how to configure it? Generally, the AirVideo-100v2 support AP and AP Client Mode, by default the AP mode is always ON. It needs to enable the AP Client mode on Web Management to work as Client mode.
  • Page 62 • Wireless mode(IEEE 802.11b/g/n) • Then, the Local users can connect AirVideo-100v2 or Internet via Wired, via Wireless. Q: What to do if I forgot my encryption key? 1. Go back to advanced setting to set up your Encryption key again.
  • Page 63 4. Appendix Q: Does AirVideo-100v2 support Power over VGA, which printer can be supported? Yes, the AirVideo-100v2 supports Power over VGA and it can compatible with the following projectors: . Optoma EX542 . Optoma EX612 . Optoma EX615 . Optoma EX762 .
