USER MANUAL
™
By
POWER ASSISTED BICYCLES
!
WARNING: You are the only person responsible for your personal safety. Do not operate or ride any Power
Assisted Bicycle unless you are already a competent bicycle rider. The bike can quickly reach high
speeds, caution must be exercised when operating the Urban Ryder. Carefully read the following
information (even if you are an experienced rider), wear a helmet and safety equipment, and obey
all Provincial and Federal motor vehicle laws. An unprotected head is highly susceptible to injury,
even from the lightest contact, but wearing a helmet that meets UL or CSA testing standards may
help prevent injury.
10/09/13
Advertisement
Table of Contents
Related Manuals for Green Light Cycle Urban Ryder
Summary of Contents for Green Light Cycle Urban Ryder
- Page 1 Assisted Bicycle unless you are already a competent bicycle rider. The bike can quickly reach high speeds, caution must be exercised when operating the Urban Ryder. Carefully read the following information (even if you are an experienced rider), wear a helmet and safety equipment, and obey all Provincial and Federal motor vehicle laws.
-
Page 2: Table Of Contents
Assemble the Bike: Front Wheel & Pedals ......................7 Assemble the Bike: Seat Installation & Tire Pressure ..................8 Urban Ryder™ Operation: Battery Removal & Installation, Precautions, Charging, and Storage ......9 Removal & Install the Battery ..........................9 Charging the Battery ............................10 Long Term Battery Care ............................. -
Page 3: Parts Identification Diagram
USER MANUAL - URBAN RYDER™ PARTS IDENTIFICATION DIAGRAM Parts Identification Diagram 1. Tektro® Front Disc Brake 17. Battery 2. Tire Valve Stem 18. Rear Fender 3. Front Suspension 19. Rear Brake Calliper 4. Front Fender 20. Tektro® Rear Disc Brake 5. -
Page 4: Assembly Instructions
USER MANUAL - URBAN RYDER™ ASSEMBLY INSTRUCTIONS Assembly Instructions Congratulations on receiving your Urban Ryder™ Electric Bicycle! Open the box from the top by cutting the 3 bands and the packaging tape. Carefully remove the 3 styrofoam packing blocks. Remove the front wheel before removing the bicycle. -
Page 5: Assemble The Bike: Handlebars
Bolts Quick Release Lever on the Front Wheel Urban Ryder™ uses a quick release lever to lock the front wheel into the fork dropouts. Quick release levers are safe and convenient when adjusted properly. Before riding your bicycle you must understand how they work and how to use them properly to prevent serious injury or death from a fall. -
Page 6: Assemble The Bike: Front Wheel
USER MANUAL - URBAN RYDER™ ASSEMBLE THE BIKE: FRONT WHEEL Assemble the Bike: Front Wheel CAUTION: The full force of the cam action is needed to clamp the wheel securely. Holding the nut with one hand and turning the lever like a wing nut, is NOT a safe or effective way to close a quick release and will not clamp the wheel safely to the forks. -
Page 7: Assemble The Bike: Front Wheel & Pedals
USER MANUAL - URBAN RYDER™ ASSEMBLE THE BIKE: FRONT WHEEL Assemble the Bike: Front Wheel To tighten the Quick Release and axel into the fork dropout, ensure the Quick Release is in the open position with the lever parallel to the ground (the lever should be at a 90°... -
Page 8: Assemble The Bike: Seat Installation & Tire Pressure
USER MANUAL - URBAN RYDER™ ASSEMBLE THE BIKE: SEAT INSTALLATION Assemble the Bike: Seat Installation 4. Seat Installation Identify the “Minimum Insert Line” on the seat post. Insert the seat post into the seat tube so the Minimum Insert Line is not visible. -
Page 9: Urban Ryder™ Operation: Battery Removal & Installation, Precautions, Charging, And Storage
USER MANUAL - URBAN RYDER™ URBAN RYDER™ OPERATION: BATTERY Urban Ryder™ Operation: Battery - Removal & Installation, Precautions, Charging, and Storage 6. Remove and Install the Battery CAUTION: Fully charge the battery before the first use! Failure to do this can result in decreased battery performance for the life of the bike and void your battery warranty. -
Page 10: Charging The Battery
URBAN RYDER™ OPERATION: BATTERY Urban Ryder™ Operation: Battery - Removal & Installation, Precautions, Charging, and Storage As lithium batteries do not suffer from Memory Effect, it is not required for the battery to be empty to begin a charge. Top up charging every time you have completed your ride is recommended. -
Page 11: Long Term Battery Care
USER MANUAL - URBAN RYDER™ URBAN RYDER™ OPERATION: BATTERY Urban Ryder™ Operation: Battery - Removal & Installation, Precautions, Charging, and Storage • Turn the key to “OFF” and remove the key from the battery. • Locate the charging port on the battery (top right side) and remove the rubber dust cover. -
Page 12: Extending The Life Of Your Battery
USER MANUAL - URBAN RYDER™ URBAN RYDER™ OPERATION: BATTERY Urban Ryder™ Operation: Battery - Removal & Installation, Precautions, Charging, and Storage • Do not allow the battery to accumulate condensation such as dew, heavy fog or rain, as this could cause shorting. -
Page 13: Urban Ryder™ Operation: System And Battery Power "On/Off
USER MANUAL - URBAN RYDER™ URBAN RYDER™ OPERATION: BATTERY Urban Ryder™ Operation: Battery - Removal & Installation, Precautions, Charging, and Storage Introduction To ensure better performance of your E-Bike, please read through the J-LCD product introduction carefully before using or starting your bike. -
Page 14: Using The King Meter
USER MANUAL - URBAN RYDER™ URBAN RYDER™ OPERATION: SYSTEM Urban Ryder™ Operation: System - System and Battery Power “ON/OFF” 9. Using the King Meter® To turn the bike motor on and illuminate the King Meter® Display. Identify the “30 Button” on the handlebar, beside the King Meter®... -
Page 15: Display Units
Press the Up or Down Arrow to choose a corresponding wheel diameter to ensure the accurate display of speed and distance on the LCD. The Urban Ryder™ wheel size is 26 inches. Press the Mode button to confirm the setting. -
Page 16: Pedal Assist Level And Throttle Power Off/On Selection
USER MANUAL - URBAN RYDER™ URBAN RYDER™ OPERATION: SYSTEM Urban Ryder™ Operation: System - System and Battery Power “ON/OFF” 11. Pedal Assist Level and Throttle Power Off/On Selection When the King Meter® is illuminated, pressing the UP or DOWN Arrows will change the output power of the motor for the pedal assist, or turn off the power to the motor completely (set assist to “ASSIST 0”). -
Page 17: Malfunction Codes
USER MANUAL - URBAN RYDER™ URBAN RYDER™ OPERATION: SYSTEM Urban Ryder™ Operation: System - System and Battery Power “ON/OFF” Display Malfunction Codes Should there be something wrong with the electronic controls, motor, or battery, the King Meter® will automatically show... -
Page 18: Pre-Ride Checklist
The Urban Ryder™ can quickly reach high speeds; caution must be exercised when operating the bike. Green Light Cycle Ltd.™ is the producer of this Owner’s Manual and assumes no responsibility for your personal safety. The bike manufacturer assumes that you already know how to ride a bicycle and gives no instruction on basic riding skills, rules of the road, Federal and Provincial Laws, or Motor Vehicle Regulations. -
Page 19: Urban Ryder™ Operation: Usage
Ride defensively, keep alert, and have fun! The Urban Ryder™ Electric Assisted Bicycle has a 48 Volt battery at 10 amp hours, supplying the power to a 500 Watt electric brushless 8FUN rear hub motor. This is a powerful electric assisted bicycle in a mountain bike shaped frame and special care must be taken when getting to know it. -
Page 20: Urban Ryder™: Troubleshooting
Charger is plugged in, but will only show green light Battery is fully charged. illuminated: Charger fuse may be burnt. If the above symptoms do not relate to your malfunction, please call Green Light Cycle Ltd.™ or your local E-Bike shop for assistance. 1-855-GRN-RYDE www.greenlightcycle.com... -
Page 21: Urban Ryder™: Care & Maintenance
Caution: Make absolutely certain that the bike rack on your car is suitable for the increased weight and the frame style of your Urban Ryder™ E-Bike. A rack that is not suitable for the increased weight can be damaged or even break during the transport. -
Page 22: Care & Cleaning
USER MANUAL - URBAN RYDER™ URBAN RYDER™: CARE & CLEANING Urban Ryder™: Care & Cleaning Care and Cleaning Never use a high pressure washer or a garden hose to clean your bike. The force of the water jet could damage the electrical components. -
Page 23: Urban Ryder™: Warranty
Warranty Green Light Cycle Ltd.™, to the original purchaser, with proof of purchase, for a period of one year from the date of purchase, warrants all parts and assemblies as to workmanship and materials used in their manufacture. Green Light Cycle Ltd.™... -
Page 24: Warranty Registration Information Card
USER MANUAL - URBAN RYDER™ URBAN RYDER™: WARRANTY REGISTRATION Urban Ryder™: Warranty Registration Warranty Registration Please record the following information, should you ever require parts or service, or to begin a warranty claim. The frame serial number is located on the underside of the bike frame, where the crank arms attach. Keep this page in your manual for your own records.
