1.3.2 iCAM502

Warning! For ATEX/IECEx GROUP II applications, Duracell Plus MN1500, Duracell
Procell MN1500, Duracell Procell PC1500, Energizer E91 or Panasonic
LR6XWA cells may be used with the iCAM502.
Warning! NOTE THE DIFFERENT TEMPERATURE CLASSSIFICATION of T3 at 60
when Duracell Procell PC1500, Energizer E91 or Panasonic LR6XWA
cells are used.
Warning! For ATEX/IECEx GROUP II applications ONLY, the user shall not carry
more than a maximum of 2 spares of the approved cells listed above into
the hazardous area. Precautions shall be taken to prevent short
circuiting of un-protected cell terminals. Discharged cells shall be
removed from the hazardous area.
Warning! For ATEX/IECEx GROUP I applications, ONLY Duracell Plus MN1500 or
Duracell Procell MN1500 cells may be used with the iCAM502.
Warning! For ATEX/IECEx GROUP I applications, the changing of cells in the
hazardous area, or the transportation of spare cells into the hazardous
area is NOT PERMITTED.
Warning! The user shall NOT mix different cells in ANY application
Note Duracell Plus MN1500 and Duracell Procell MN1500 cells are equivalent
Warning! For ATEX/IECEx GROUP II applications, note that the rated ambient
temperature range of the equipment is from -20
Warning! For ATEX/IECEx GROUP I applications, note that the rated ambient
temperature range of the equipment is from 0
Warning! Any connection to the iCAM502 USB port must NOT be made in a
hazardous area.
Warning! If any damage to the iCAM502 is found which may invalidate the required
safety minimum IP rating (IP54 for ATEX/IECEx Group I applications,
IP20 for ATEX/IECEx Group II applications) the iCAM502 shall be
removed from the hazardous area.
Important Any repairs or replacement of parts MUST be performed by the
manufacturer or its nominated sub-contractor or agent.
Important The iCAM502 contains no user serviceable parts. The main part of the
enclosure must not be opened under any circumstances.
Operating Manual
8
o o
C to 60 C.
o o
C to 60 C.
o
C
