ASSEMBLY –
Adjusting the Cutting Height
Follow these steps to adjust the cutting height
See Fig 8
1. The cutting height can be adjusted by raising
or lowering the cutting height roller.
2. Release the two adjustment knobs which are
on each side of the cutting height roller.
3. Set the height of the roller to give the
required height of cut.
4. It is important that when adjusting the
cutting height that each end of the roller is
adjusted by the same amount to keep the
roller level. If not done, an uneven cut will
result.
8
continued
Fig. 8
