Pope Eco Mow 40 Operator's Manual

Hand push reel mower

Advertisement

Quick Links

Eco Mow 40
Hand Push Reel Mower
Model No. 101REEL40
Operator's Manual
WARNING
To reduce the risk of injury, the user must read and understand the
Operator's Manual. Save this manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Eco Mow 40 and is the answer not in the manual?

Questions and answers

Summary of Contents for Pope Eco Mow 40

  • Page 1 Eco Mow 40 Hand Push Reel Mower Model No. 101REEL40 Operator’s Manual WARNING To reduce the risk of injury, the user must read and understand the Operator’s Manual. Save this manual.
  • Page 2 Introduction Thank you for purchasing a Pope product. We would like you to be completely satisfied with your new product, so feel free to contact Pope for help with any information you require. Pope’s Customer Service centre number is 1300 134 880.
  • Page 3: Safety Rules

    SAFETY RULES WARNING Read and understand all instructions. Failure to follow all instructions may result in serious personal injury as well as damage to the product. • Physical Condition of the Operator. Do not operate this product when tired, ill or under the influence of alcohol, drugs or medication.
  • Page 4: Packing List

    Cutting grass, weeds and light undergrowth. The Pope ECO MOW 40 Hand Push Reel Mower is designed to be used around the home and should only be operated within its design limitations. Tools of this category which are designed for home and garden use and should only be operated in such settings.
  • Page 5: Specifications

    7. Lower handles 8. Handle extensions 9. Upper handle 10. Coach bolts Fig. 1 SPECIFICATIONS Name Pope ECO MOW 40 Hand Push Reel Mower Model Number 101REEL40 Cutting Width 400 mm Number of blades Cutting Heights 14 – 42 mm...
  • Page 6 ASSEMBLY Follow these steps to assemble the handles onto the mower See Figs 2, 3 and 4 1. Attach the lower handles to the mower Fig. 2 body (Fig. 2) by locating the handles over the two lugs on either side of the mower body.
  • Page 7: Attaching The Grass Catcher

    ASSEMBLY – continued Attaching the Grass Catcher Follow these steps to attach the Grass Fig. 5 Catcher See Fig. 5 and 6 1. Locate the lower end of the catcher over the attachments points located at the rear of the mower (Fig. 5). 2.
  • Page 8: Adjusting The Cutting Height

    ASSEMBLY – continued Adjusting the Cutting Height Follow these steps to adjust the cutting height See Fig 8 1. The cutting height can be adjusted by raising or lowering the cutting height roller. 2. Release the two adjustment knobs which are on each side of the cutting height roller.
  • Page 9: Operation

    OPERATION Follow these steps to get the best results from your mower. 1. Walk at a good, steady pace. A reel mower is powered by you, so move at a comfortably quick walking pace. This will provide the best results. The faster you walk, the faster the blade turns. Avoid slow or jerky movements as reel mowers can bind up and skid if you move too slowly.
  • Page 10: Maintenance

    MAINTENANCE Follow these general maintenance guidelines before each use. • Check that all nuts, bolts and screws are securely tightened in order to be sure that the mower is in a safe working condition. • Only use replacement cutters and blades of the correct type. •...
  • Page 11: Warranty

    You must keep your receipt as proof of purchase for return of the product under the terms of this warranty. Your Pope product is guaranteed to be free from defects in materials or workmanship for a period of 24 months from the date of purchase provided the product has been used in accordance with the manufacturer's recommendations.
  • Page 12 Pope is a Registered Trademark of Toro Australia Pty Ltd ® 53 Howards Rd Beverley South Australia 5009 Made in China to Pope's Specifications...
