- Page 1 Total Digital Connectivity Solutions User’s Manual 1x2 DVI Distribution Amplifier 1x5 DVI Distribution Amplifier DD-D12 / DD-D15 Cautions: 1. Digital Extender logo is our own trademark of RTcomUSA.,Inc. ® 2. Any of the products may be changed without any notice in order to improve the function of the product.
-
Page 2: Table Of Contents
Table of Contents Unpacking..........................3 Declaration of Conformity ..................... 3 Description, General Specification..................4 Main Features ......................... 6 Video Connection........................7 Mechanical Specification ....................... 8 Technical Specification ......................9 Warranty Information......................10 Troubleshooting........................11... -
Page 3: Unpacking
Unpacking Each Digital Extender DVI Distributor package includes the following items; • DD-D12 / DD-D15 DVI Distribution Amplifier Unit x 1 • 5V, 2A Power Supply Adapter x 1 • User’s manual x 1 Declaration of Conformity According to Council Directive 73/23/EEC (February 19, 1973) on the Harmonization of the Laws of Member States relating to Electrical Equipment;... -
Page 4: Description, General Specification
Description, General Specification Digital Extender DD-D12 and DD-D15, DVI Distribution Amplifiers, allow one digital video sources to be spilt into multiple digital displays. The built-in amplification function enables DVI signal distribution without signal loss ITEM DESCRIPTION DESCRIPTION Model Name DD-D12... - Page 5 Environmental and Reliability Specifications 1 Operating Conditions Temperature : 10℃~ 40℃ Humidity : 10% ~ 80%, non-condensing Altitude : maximum 3,000m 2 Transportation Conditions Temperature : -25℃~ 60℃ Humidity : 5% ~ 95%, non-condensing Altitude : maximum 15,000m 3 Storage Conditions Temperature : -20℃~ 45℃...
-
Page 6: Main Features
Main Features High Quality Picture - No Signal Loss and Digital Noise Free Our Distribution Amplifiers are built to deliver the highest quality picture preserving the native resolutions of the video sources without any signal loss. At the same time, the digital noises that may affect the picture quality will be eliminated. -
Page 7: Video Connection
6. Turn on your displays. 7. Turn on your video source. ** DDC On/Off Switch DD-D12/D15 is built in DDC on/off dip switches in the back for each DVI output port. DDC communication is required for some video sources and display (such as PC and LCD monitor) to correctly display the picture. -
Page 8: Mechanical Specification
Mechanical Specification Dimensions DD-D12 : 272x151x30 mm DD-D15 : 365x151x30 mm DC 5V : DC 5V Input DVI IN : DVI-D Input Signal DVI OUT CH1~5 : DVI-D Output Signals 1-6 Mechanical Specification... -
Page 9: Technical Specification
Supporting Graphic Resolution: Up to WUXGA(1920x1200) at 60Hz ATSC HDTV Signal: 480i/p, 720i/p , 1080i/p Inputs: DVI Female 1port Output: DVI Female ports (DD-D12/ 2 ports , DD-D15/ 5 ports) Power supply: DC 5V, 2A Adapter included. Connector Pin Assignment DVI-D Single Link Input, Output Part No. -
Page 10: Warranty Information
Warranty Information 1 (One) Year Warranty RTcomUSA. warrants this Digital Extender’s DD-D12 and DD-D15, DVI Distribution Amplifiers to be free from defects in workmanship and materials, under normal use and service, for a period of one (1) year from the date of purchase from RTcomUSA, Inc. -
Page 11: Troubleshooting
Troubleshooting Problem Solution Distribution Amplifier will Make sure the 5V power adapter is plugged in not operate the back of the unit. Check to see if the power LED light is on. No picture(or signal) 1. In case your video source is HDCP enabled, Or Poor picture make sure your video display(HDTV) is HDCP compliant. - Page 12 © 2002 RTcomUSA.Inc.. All Rights Reserved Revision 2 0806 RTcomUSA,. Inc. Locations RTcomUSA. Inc. 286 Houses Corner Road Sparta, NJ 07871 USA Tel: 973-383-4878 Fax: 973-383-1160 For order support, please contact your Distributor or Reseller. For technical support, check with the RTcomUSA,. Inc. info@digitalextender.com Web site www.digitalextender.com...
