Summary of Contents for Insignia NS-HDTUNE
- Page 1 User Guide HD Radio Tuner NS-HDTUNE...
-
Page 3: Table Of Contents
Legal notices..... .23 Introduction Congratulations on your purchase of a high-quality Insignia product. Your NS-HDTUNE represents the state of the art in HD radio tuner design and is designed for reliable and trouble-free performance. -
Page 4: Safety Information
Clean with a dry cloth only. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN ATTENTION RISQUE DE CHOC PRECAUCION RIESGO DE CHOQUE ELECTRICO NO ABRIR www.insignia-products.com NS-HDTUNE... - Page 5 NS-HDTUNE Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong.
-
Page 6: Features
If you use the wrong type battery, an explosion may occur. When you dispose of batteries, follow your local hazardous waste regulations. HD radio tuner FM antenna AM antenna Remote control with battery Right and left audio ouput cables User Guide www.insignia-products.com NS-HDTUNE... - Page 7 NS-HDTUNE Front Component Power button Number buttons HD logo Remote control sensor SEEK button HD SEEK button www.insignia-products.com Description Press to turn on your radio or put it into standby mode. Press a number button for more than two seconds to store the currently playing station to a preset number.
- Page 8 COAXIAL IN jack on a sound system to listen to your radio through the sound system. Connect an optical audio cable to this jack and to the OPTICAL IN jack on a sound system to listen to your radio through the sound system. NS-HDTUNE...
- Page 9 NS-HDTUNE Component LINE OUT jacks FM antenna connector Power cord AM antenna connector POWER ON/OFF switch www.insignia-products.com Description Connect a standard audio cable to these jacks and to the LINE IN or AV L and R audio jacks on a sound system to listen to your radio through the sound system.
-
Page 10: Remote Control
Press to turn on your radio or to put it into standby mode. Press a number button for more than two seconds to store the currently playing station to a preset number. Press to go to a stored (preset) station. www.insignia-products.com NS-HDTUNE... - Page 11 NS-HDTUNE Button SEEK PRESET AM/FM TUNE HD SEEK www.insignia-products.com Description Press to go to the next FM, AM, or HD radio station. The button will not tune to an HD radio multicast station. Press to go to the next or previous preset station.
-
Page 12: Lcd Display
When receiving an HD radio broadcast, the following information appears on the LCD. Description Shows the frequency band, AM, FM1, or FM2. Station call letters HD radio broadcast indicator Signal strength Broadcast frequency Artist Song title or radio show title www.insignia-products.com NS-HDTUNE... - Page 13 NS-HDTUNE RBDS radio broadcast display When receiving an RBDS radio broadcast, the following information appears on the LCD. Description Shows the frequency band, AM, FM1, or FM2 Station call letters Broadcast frequency Genre RBDS text Changing frequency examples Display www.insignia-products.com...
- Page 14 NS-HDTUNE Display Description Pressing SEEK in AM/FM mode (the frequency will go up or down step by step) Pressing HD SEEK (the frequency will go up or down step by step) www.insignia-products.com...
-
Page 15: Setting Up Your Radio
NS-HDTUNE Setting up your radio Installing the remote control battery To install the remote control battery: Press in and hold the battery release clip (1) on the back of the remote control while pulling the battery bracket (2) out of the remote control. -
Page 16: Connecting The Power Cord
The battery is a CR2025 3 V battery. • Dispose of used batteries by following your local hazardous waste regulations. Plug the power cord into a power outlet. www.insignia-products.com NS-HDTUNE Power cord... -
Page 17: Connecting The Antennas
NS-HDTUNE Connecting the antennas To connect the antennas: Connect the FM antenna to the FM connector on the back of your radio, then connect the AM antenna to the AM connector on the back of your radio. FM antenna Fully extend the antenna wires. You may need to adjust the antennas to get the best reception. - Page 18 IN jack on a sound system. Reconnect the power cables, then turn on your radio and the sound system. Select the audio input on your sound system that matches the audio output jack you connected your radio to. Coaxial audio cable www.insignia-products.com NS-HDTUNE...
- Page 19 NS-HDTUNE To connect to a sound system using an optical audio cable: Make sure that your radio and the sound system are turned off and the power cords are unplugged. Connect one end of a coaxial audio cable to the OPTICAL jack on the back of your radio.
- Page 20 AV AUDIO IN jacks on a sound system. Reconnect the power cables, then turn on your radio and the sound system. Select the audio input on your sound system that matches the audio output jack you connected your radio to. Standard AV audio cable www.insignia-products.com NS-HDTUNE...
-
Page 21: Using Your Radio
NS-HDTUNE Using your radio Turning on your radio To turn on your radio: Make sure that the POWER ON/OFF switch on the back of your radio is in the ON position. Press control. To put your radio in standby mode, press again. -
Page 22: Storing Stations In Memory
Press PRESET your radio or remote control to go to the next or previous preset station. Press a number button to tune to a stored (preset) station. www.insignia-products.com NS-HDTUNE on the remote or PRESET on the front of or PRESET... -
Page 23: Troubleshooting
NS-HDTUNE Troubleshooting Problem Radio does not turn on. Remote control does not turn on. No sound. Radio does not work at all. www.insignia-products.com Solution • Make sure that the power cord is fully inserted in the power outlet. • Make sure that you point... -
Page 24: Specifications
Specifications Audio outputs Power supply Maximum power consumption FM frequency AM frequency • Coaxial • Optical fiber • Standard AV ~110 V/60z 87.50 MHZ ~ 107.90 MHz 530 KHz ~ 1710 KHz www.insignia-products.com NS-HDTUNE... -
Page 25: Legal Notices
NS-HDTUNE Legal notices FCC Part 15 This device complies with Part 15 of the FCC Rules. Operation of this product is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 26 NS-HDTUNE www.insignia-products.com...
-
Page 27: Day Limited Warranty
Products and parts replaced under this warranty become the property of Insignia and are not returned to you. If service of Products or parts are required after the Warranty Period expires, you must pay all labor and parts charges. - Page 28 25 inches or larger, call 1-888-BESTBUY. Call agents will diagnose and correct the issue over the phone or will have an Insignia-approved repair person dispatched to your home. Where is the warranty valid? This warranty is valid only to the original purchaser of the product in the United States, Canada, and Mexico.
- Page 29 7601 Penn Avenue South, Richfield, Minnesota, U.S.A. 55423-3645 © 2008 Best Buy Enterprise Services, Inc. All rights reserved. INSIGNIA is a trademark of Best Buy Enterprise Services, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.
- Page 30 NS-HDTUNE www.insignia-products.com...
- Page 31 NS-HDTUNE www.insignia-products.com...
- Page 32 7601 Penn Avenue South, Richfield, MN USA 55423-3645 © 2008 Best Buy Enterprise Services, Inc. All rights reserved. INSIGNIA is a trademark of Best Buy Enterprise Services, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.
